Viessmann Vitodens 100-W Specifications
Gas fired condensing combination and system boiler, type wb1c, with modulating matrix cylinder burner and inox-radial heat exchanger for open flue and balanced flue operation. rated output range: 7.4 to 35 kw
Hide thumbs
Also See for Vitodens 100-W:
- Installation instructions manual (204 pages) ,
- Installation and service instructions manual (105 pages) ,
- Manual (84 pages)
Advertisement
Vitodens 100-W
Gas fired condensing Combination and
System boiler, type WB1C, with modulating
MatriX cylinder burner and Inox-Radial
heat exchanger for open flue and balanced
flue operation.
Rated output range: 7.4 to 35 kW
10 Year Warranty
on all stainless steel heat exchangers for
gas condensing boilers up to 105 kW
Advertisement
Table of Contents
Related Manuals for Viessmann Vitodens 100-W
Summary of Contents for Viessmann Vitodens 100-W
- Page 1 Vitodens 100-W Gas fired condensing Combination and System boiler, type WB1C, with modulating MatriX cylinder burner and Inox-Radial heat exchanger for open flue and balanced flue operation. Rated output range: 7.4 to 35 kW 10 Year Warranty on all stainless steel heat exchangers for...
- Page 2 Contents Viessmann Headquarters, Allendorf (Eder), Germany from page 2 Viessmann profile from page 6 Product features from page 10 Control technology from page 11 Ease of installation from page 14 Technical specification...
- Page 3 Leading heating technology from Europe's largest brand - manufactured in Germany's most sustainable factory Established in 1917, Viessmann draws on more than 90 years of experience in the development and manufacture of heating systems and due to its high commitment to quality, it is Europe's single largest brand in heating technology.
- Page 5 2007, also in all existing systems. is to add weather compensation controls. Viessmann feels a traditional obligation to The Vitodens 100-W range are designed to the basic requirement of using the best work with optional weather compensation technology available while aiming to protect controls, to achieve additional fuel savings the environment to the best of its ability.
- Page 6 Vitodens 100-W...
-
Page 7: Year Warranty
The compact dimensions and < 40 db(A) minimal operating noise mean it can be With the Vitodens 100-W, we have the easily integrated into the smallest of homes. solution. With a range of models and outputs to suit every application. - Page 8 Excellent self-cleaning depends on a smooth surface The smooth surface of stainless steel is perfect MatriX gas for condensing boilers. Viessmann builds on this burner advantage by designing heating surfaces which enhance the self-cleaning effect. This means 40°C the condensate drains off more quickly. Dirt...
- Page 9 Environment The MatriX cylinder burner was developed and manufactured by Viessmann in 1994 and due to the extremely low emissions the innovation was awarded the Business Award for the Environment. 1.5 million MatriX burners have been manufactured to date.
-
Page 10: Controls And Accessories
Ease of use Functions of the controller weather compensation All functions are easily operated by hand. The The Vitodens 100-W is supplied with a control adjustment user-friendly dials allow for fast adjustment unit, featuring a built-in diagnostics system On/off button with of the heating and domestic hot water and frost protection. - Page 11 10/11 Ease of installation : Optional accessories for commissioning Pre-plumbing jig (optional accessory) To help installation of the Vitodens 100-W, all connections are checked for leaks during the assembly process and only need to be tested again once the boiler is hung.
- Page 12 300 unvented cylinder are the perfect combination to meet G3 building regulations 100% compatible with solar thermal panels. The Vitodens 100-W has the added advantage without the need for an energy cut-off valve and of boiler suppression, when using Viessmann cylinder overheat thermostat;...
- Page 13 12/13 Vitodens 100-W from 7.4 to 35 kW 8 litre expansion vessel Modulating MatriX cylinder burner for permanently low emissions Inox-Radial stainless steel heat exchanger - for high reliability and long service life Modulating fan with air intake tube for low...
-
Page 14: Technical Specification
Vitodens 100-W Technical specification Abmessungen Abmessungen Dimensions A Heizungsvorlauf Ø 20 mm E Heizungsrücklauf Ø 20 mm Heating flow Ø 22 mm Heating return Ø 22 mm A Heizungsvorlauf Ø 20 mm E Heizungsrücklauf Ø 20 mm B Gas-Brennwertheizgerät: F Kondenswasserablauf/Ablauf Sicherheitsventil:... - Page 15 14/15 Model WB1C System Combination Mode Unit Rated CH Output At Tf/Tr 50/30 ºC (condensing) 6.5 - 19 6.5 - 26.0 8.8 - 30.0 8.8 - 35.1 6.5 - 26.0 8.8 - 30.0 8.8 - 35.00 At Tf/Tr 80/60 ºC (non-condensing) 5.9 - 17.3 5.9 - 23.7 8.0 - 26.6...
- Page 16 Vitodens 100-W Flue applications Flue applications Vertical, concentric roof Vitodens boilers can be installed in terminal – flat and pitched virtually all domestic applications, some Communal flue system – examples are illustrated. open flued Horizontal concentric The maximum flue length is the single Communal room biggest consideration.
-
Page 17: Balanced Flue Operation
16/17 Balanced flue operation Part no. 60/100 80/125 Boiler flue connection Standard shaft pack (PPS, flexible) comprising: 7248206 7248213 Support bend Support rail Shaft cover (PPS) Spacers (5 pce.) Standard shaft pack (metal/PPS, rigid) 7452173 7452179 For twin flue chimneys (one flue for solid fuel boilers). comprising: A Combustion air Support bend B Flue gas... - Page 18 Vitodens in wet areas, observe the safety zones and minimum wall clearances according to IEEE wiring regulation. The Vitodens may be installed in safety zone 1, if hosed water (e.g. through Viessmann trained installers can register for free through www.viessmanninstallerportal.co.uk massage showers) is prevented.
- Page 19 Corrosion is generally avoided in correctly installed and operated suitability, otherwise damage to gaskets and diaphragms may sealed heating systems. occur, as well as noise during heating operation. Viessmann Chemical anti-corrosion agents should be avoided where possible. accepts no liability for damage or consequential damage as a Some manufacturers of plastic pipes recommend the use of result.
