Nautilus Be Strong. NV915 Service Manual

Hide thumbs Also See for Be Strong. NV915:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Installation Manual
Be Strong.
™
NV 915 LCD Monitor
Service Manual
Model: NV915
P/N:
001-2032 Rev B ( 08/13/2007 )

Advertisement

Table of Contents
loading

Related Manuals for Nautilus Be Strong. NV915

Summary of Contents for Nautilus Be Strong. NV915

  • Page 1 Be Strong. ™ NV 915 LCD Monitor Service Manual Model: NV915 P/N: 001-2032 Rev B ( 08/13/2007 )

  • Page 2: Table Of Contents

    Table of Contents FCC Information ........... 3 Important Safety Precautions ......4 Product Specifications ........5 Location of Safety Warning Labels ..... 6 Exploded Views and Parts Lists ......7 Troubleshooting ...........13 Replacing Headphone Jack ........14 Replacing Keypad ..........15 Replacing LCD Monitor (M Series Bracket) ..17 Replacing LCD Monitor (T Series Bracket) ..23 Important Contact Numbers ......29...

  • Page 3: Fcc Information

    A T T E N T I O N • Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. Nautilus NV915 Service Manual ®...

  • Page 4: Important Safety Precautions

    Important Safety Precautions To reduce the risk of fire, electrical shock or IMportaNt! other injuries, follow these safety precautions when installing, using and maintaining your Save these instructions NV915 LCD TV Monitor. Read all instructions before using. This symbol appearing throughout this manual means: W A R N I N G Pay Attention! Be Alert! Your Safety Is Involved! W A R N I N G...

  • Page 5: Product Specifications

    For Customers in the European Union, Do not dispose of this product as refuse. this product is to be recycled. For information on the proper method of disposal contact a Nautilus Customer Service representative. Contact information is available in the Important Contact Numbers section in this manual.

  • Page 6: Location Of Safety Warning Labels

    Safety Warning Labels the following safety warnings are located on the NV915 LCD Monitor. please read all safety precautions and warning information prior to using your product.

  • Page 7: Exploded Views And Parts Lists

    M Series Bracket Kit REF# PART# DESCRIPTION 001-1915 M Series Bracket Kit Complete 001-1894 Console Spacer 001-1959 M Series Bracket Kit Installation Manual 001-1944 M Series Replacement Hardware Kit (Use if replacement Hardware is needed) Nautilus NV915 Service Manual ®...
  • Page 8 Exploded View LCD Monitor Kit REF# PART# DESCRIPTION 001-1924 LCD Monitor with Accessories (US) 001-1992 LCD Monitor with Accessories (Euro) 001-2013 LCD Monitor with Accessories (Australia) 002-3782 LCD Monitor, DT with Accessories (Digital) 001-1922 Power Cord (US) 001-2015 Power Cord (Continental) 001-2019 Power Cord (Australia) 001-2017...
  • Page 9 Exploded View LCD Monitor Components REF# PART# DESCRIPTION 001-2033 Front Keypad 001-1945 Earphone Jack 001-1997 Back Cover Nautilus NV915 Service Manual ®...
  • Page 10 Exploded View T Series Bracket Kit REF# PART# DESCRIPTION 001-1948 T Series Bracket Kit Complete 001-1960 T Series Bracket Kit Installation Manual 001-1955 T Series Replacement Hardware Kit (Use if replacement Hardware is needed)

  • Page 11: Remote Controls

    Exploded View Remote Controls Wireless Remote Wired Remote REF# PART# DESCRIPTION 001-1939 Wireless Remote Kit (US) 001-2081 Wireless Remote Kit (International) 002-3785 Wireless Remote Kit (US Digital) 001-2028 Universal Wired Remote Kit Nautilus NV915 Service Manual ®...
  • Page 12 Exploded View Free Stand Kit REF# PART# DESCRIPTION 001-2074 Stand Shroud Replacement Kit 001-1934 Upright Assembly 001-1851 Adjustable Mast Assembly 001-1935 Base Assembly 001-2049 Stabilizer B 001-2050 Stabilizer A 001-2036 Stand Assembly Instruction Manual 001-2035 Stand Hardware Kit 001-2037 Stand Wire Harness 001-4874...

  • Page 13: Troubleshooting

    • replace Headphone Jack Remote Doesn’t Work • try the remote on another LCD Display if available. • Make sure you have fresh batteries. • Check or replace the Headphone Jack on the front of the LCD Monitor. Nautilus NV915 Service Manual ®...

  • Page 14: Replacing Headphone Jack

    Replacing Headphone Jack over time the Headphone Jack may become worn and fail to function properly. replacing Headphone Jack Tools Needed: phillips Head Screwdriver Parts Needed: Headphone Jack Kit part# 001-195 1. remove the Decal covering the Headphone Jack. (Figure a) 2.

  • Page 15: Replacing Keypad

    . Gently lay the LCD on it’s back and peel off the old Keypad (Figure D). . remove the old Keypad from the slot it the plastic (Figure E). (Continued on next page) Ribbon Cable Ribbon Cable Figure a Figure B Figure C Keypad Figure E Figure D Nautilus NV915 Service Manual ®...
  • Page 16 Replacing Keypad replacing Keypad (Continued) 5. Insert the new Keypad ribbon cable through the slot with the adhesive side toward the bottom of the LCD (Figure F). 6. peel off the adhesive Backing (Figure G). 7. position the Keypad on the plastic and firmly press into place (Figure H & I). .

  • Page 17: Replacing Lcd Monitor (M Series Bracket)

    (Figure a) and the Bracket (Figure B). NOTE: Two longer screws used on the raised portion of the LCD Monitor Back cover (Detail a). Figure a Bracket Back Cover Longer screws used here Figure B Detail a Nautilus NV915 Service Manual ®...
  • Page 18 Replacing LCD Monitor Replacing M Series (mast mount) LCD Monitor (continued) Step 2 Disconnect Wires From Monitor 2-1 Disconnect the power, antenna and remote (if using optional wired remote) wires from the LCD Monitor. optional Wired remote wires. NOTE: International version will have Coaxial Connection adapter.
  • Page 19 Step 4 Prepare to install the new LCD Monitor Back Cover Tools Needed: phillips Head Screwdriver 4-1 Use a phillips Head Screwdriver to remove the Back Cover of the LCD monitor. (Figure a) Figure a Nautilus NV915 Service Manual ®...
  • Page 20 Replacing LCD Monitor Replacing M Series (mast mount) LCD Monitor (continued) LCD Monitor Bracket Step 5 Attach the LCD Monitor Tools Needed: 6mm allen wrench 5-1 position the LCD Monitor on the Bracket (Figure a) with the Metal tabs resting between the upright prongs (Detail a).
  • Page 21 International Coaxial Adapters Power Antenna Power Antenna These connections are not used in this configuration For alternative configurations please refer to the LCD Monitor owners manual. Antenna Power Connections are REVERSED for the NV915 LCD Digital Monitor. Nautilus NV915 Service Manual ®...
  • Page 22 Replacing LCD Monitor Replacing M Series (mast mount) LCD Monitor (continued) Step 7 Replace the Back Covers Tools Needed: Bracket Back Cover phillips Head Screwdriver 7-1 replace the Back Cover of the Bracket (Figure a) and the LCD Monitor (Figure B). NOTE: Use the two longer screws on the raised portion of the LCD Monitor Back cover (Detail a).

  • Page 23: Replacing Lcd Monitor (T Series Bracket)

    (Figure a) and the Bracket (Figure B). NOTE: Two longer screws used on the raised portion of the LCD Monitor Back cover (Detail A). Figure a Bracket Back Cover Use longer screws here Figure B Detail a Nautilus NV915 Service Manual ®...
  • Page 24 Replacing LCD Monitor Replacing T Series LCD Monitor (continued) Step 2 Disconnect Wires From Monitor 2-1 Disconnect the power, antenna and remote (if using optional wired remote) wires from the LCD Monitor. optional Wired remote wires. NOTE: International version will have Coaxial Connection adapter.
  • Page 25 Step 4 Prepare to install the new LCD Monitor Back Cover Tools Needed: phillips Head Screwdriver 4-1 Use a phillips Head Screwdriver to remove the Back Cover of the LCD monitor. (Figure a) Figure a Nautilus NV915 Service Manual ®...
  • Page 26 Replacing LCD Monitor Replacing T Series LCD Monitor (continued) Step 5 Attach the LCD Monitor LCD Monitor Tools Needed: 6mm allen wrench 5-1 position the LCD Monitor on the Bracket (Figure a) with the Metal tabs resting between the upright prongs (Detail a).
  • Page 27 International Coaxial Adapters Power Antenna Power Antenna These connections are not used in this configuration For alternative configurations please refer to the LCD Monitor owners manual. Antenna Power Connections are REVERSED for the NV915 LCD Digital Monitor. Nautilus NV915 Service Manual ®...
  • Page 28 Replacing LCD Monitor Replacing T Series LCD Monitor (continued) Bracket Back Cover Step 7 Replace the Back Covers Tools Needed: phillips Head Screwdriver 7-1 replace the Back Cover of the Bracket (Figure a) and the LCD Monitor (Figure B). NOTE: Use the two longer screws on the raised portion of the LCD Monitor Back cover (Detail a).

  • Page 29: Important Contact Numbers

    Important Contact Numbers If you need assistance, please have both the serial number of your machine and the date of purchase available when you contact the appropriate Nautilus office listed below. OFFICES IN THE UNITED STATES: INTERNATIONAL OFFICES: For technical assistance and a list of distributors in your area, E-mail: cstech@nautilus.com...
  • Page 30 , visit www.nautilusinc.com. ® © 2007 Nautilus, Inc. All rights reserved. Nautilus, the Nautilus logo, and Be Strong are either registered trademarks or trademarks of Nautilus, Inc. All other marks are either registered trademarks or trademarks of their respective companies.
