Page 1: User Manual
EN2C606-4L/D12 EN2C602-4L/D12 EN2C602/D12 EN2C606-4L EN2C602-4L EN2C602 User Manual Version 1.0 Published Jan 2013 Copyright©2013 ASRock INC. All rights reserved. -
Page 2: Copyright Notice
ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this manual. With respect to the contents of this manual, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warran- ties or conditions of merchantability or fitness for a particular purpose. -
Page 3: Table Of Contents
Contents 1 Introduction ............5 1.1 Package Contents ..........5 1.2 Specifications ............6 1.3 Motherboard Layout ..........14 1.4 I/O Panel ............. 32 1.5 Block Diagram ............. 38 2 Installation ............44 2.1 Pre-installation Precautions ........ 44 2.2 Screw Holes ............44 2.3 CPU Installation .......... - Page 4 3 UEFI SETUP UTILITY ......... 65 3.1 Introduction ............65 3.1.1 UEFI Menu Bar ........... 65 3.1.2 Navigation Keys ......... 66 3.2 Main Screen ............67 3.3 Advanced Screen ..........68 3.3.1 ACPI Configuration ........69 3.3.2 WHEA Configuration ........71 3.3.3 CPU Configuration ........
-
Page 5: Introduction
In case any modifications of this manual occur, the updated version will be available on ASRock’s web- site without further notice. You may find the latest VGA cards and CPU support list on ASRock’s website as well. -
Page 6: Specifications
1.2 Specifications EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C602/D12: Form Factor SSI EEB Physical Status Dimension 12'' x 13'' (30.5 cm x 33 cm) ® ® - Supports Intel Xeon E5-2400/1400* Series Processors - Supports Hyper-Threading Technology * E5-1400 only supports single socket. - Page 7 Interface Gigabit LAN 10/100/1000 Mb/s IPMI 1 x Realtek RTL8211E for dedicated dedicated management GLAN GLAN EN2C606-4L/D12 / EN2C602-4L/D12 ® - 4 x Intel 82574L - Supports Wake-On-LAN - Supports Energy Efficient Ethernet 802.3az Ethernet - Supports Quad LAN with Teaming function...
- Page 8 PS/2 mouse VGA port D-sub x 1 USB 2.0 port 2 EN2C606-4L/D12 / EN2C602-4L/D12 - 4 x RJ45 Gigabit Ethernet LAN ports - 1 x RJ45 Dedicated IPMI LAN port Rear Panel - LAN Ports with LED (ACT/LINK LED and...
- Page 9 Support OS R2 / Linux compliant Operation temperature: 10°C ~ 35°C / Non Temperature operation temperature: -40°C ~ 70°C Enviroment Non operation humidity: 20% ~ 90% ( Non Humidity condensing) * For detailed product information, please visit our website: http://www.asrock.com...
- Page 10 EN2C606-4L / EN2C602-4L / EN2C602: Form Factor SSI EEB Physical Status Dimension 12'' x 10.5'' (30.5 cm x 26.7 cm) ® ® - Supports Intel Xeon E5-2400/1400* Series Processors - Supports Hyper-Threading Technology * E5-1400 only supports single socket. Socket Dual Socket B2 (LGA1356) Processor Power Phase 4 +1 Power Phase Design...
- Page 11 Interface Gigabit LAN 10/100/1000 Mb/s IPMI 1 x Realtek RTL8211E for dedicated dedicated management GLAN GLAN EN2C606-4L / EN2C602-4L - 4 x Intel® 82574L - Supports Wake-On-LAN - Supports Energy Efficient Ethernet 802.3az Ethernet - Supports Quad LAN with Teaming function - Supports PXE Controller EN2C602...
- Page 12 PS/2 KB PS/2 mouse VGA port D-sub x 1 USB 2.0 port 2 EN2C606-4L /EN2C602-4L - 4 x RJ45 Gigabit Ethernet LAN ports - 1 x RJ45 Dedicated IPMI LAN port Rear Panel - LAN Ports with LED (ACT/LINK LED and SPEED LED) Lan port EN2C602...
- Page 13 Support OS R2 / Linux compliant Operation temperature: 10°C ~ 35°C / Non Temperature operation temperature: -40°C ~ 70°C Enviroment Non operation humidity: 20% ~ 90% ( Non Humidity condensing) * For detailed product information, please visit our website: http://www.asrock.com...
-
Page 14: Motherboard Layout
1.4 Motherboard Layout EN2C606-4L/D12 33cm (13 in) FRNT_FAN1 ATXPWR1 Keyboard Mouse ATX12V1 CPU_FAN1_2 CPU_FAN1_1 DDR3_A1 (64 bit, 240-pin module) DDR3_A2 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_B2 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) USB 2.0 Top: T: USB0 DDR3_C2 (64 bit, 240-pin module) - Page 15 ATX 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 3 x 240-pin DDR3 DIMM Slots (DDR3_G1, DDR3_F1, DDR3_E1, Blue) ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2, DDR3_C2,White)
- Page 16 System Panel Header (PANEL1) Front Lan LED Connector (FRONT_LED_LAN34) USB 2.0 Ports (USB_2_3) ME Recovery Jumper (ME_RECOVERY1) Speaker Header (SPEAKER1) USB 2.0 Ports (USB_4_5) Auxiliary panel header (AUX_PANEL1) Non Maskable Interrupt Button (NMI_BTN1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) UP ROM Header (UP_ROM1) BMC ROM...
- Page 17 EN2C602-4L/D12 33cm (13 in) FRNT_FAN1 ATXPWR1 Keyboard Mouse ATX12V1 CPU_FAN1_2 CPU_FAN1_1 DDR3_A1 (64 bit, 240-pin module) DDR3_A2 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_B2 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) USB 2.0 Top: T: USB0...
- Page 18 ATX 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 3 x 240-pin DDR3 DIMM Slots (DDR3_G1, DDR3_F1, DDR3_E1, Blue) ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2, DDR3_C2,White)
- Page 19 ME Recovery Jumper (ME_RECOVERY1) Speaker Header (SPEAKER1) USB 2.0 Ports (USB_4_5) Auxiliary panel header (AUX_PANEL1) Non Maskable Interrupt Button (NMI_BTN1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) UP ROM Header (UP_ROM1) BMC ROM USB 2.0 Ports (USB_6) PCI Slot (PCI1, White) Dr.
- Page 20 EN2C602/D12 33cm (13 in) FRNT_FAN1 ATXPWR1 Keyboard Mouse ATX12V1 CPU_FAN1_2 CPU_FAN1_1 DDR3_A1 (64 bit, 240-pin module) DDR3_A2 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_B2 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) USB 2.0 Top: T: USB0 DDR3_C2 (64 bit, 240-pin module) LAN2 B: USB1...
- Page 21 ATX 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 3 x 240-pin DDR3 DIMM Slots (DDR3_G1, DDR3_F1, DDR3_E1, Blue) ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2, DDR3_C2,White)
- Page 22 Speaker Header (SPEAKER1) USB 2.0 Ports (USB_4_5) Auxiliary panel header (AUX_PANEL1) Non Maskable Interrupt Button (NMI_BTN1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) UP ROM Header (UP_ROM1) BMC ROM USB 2.0 Ports (USB_6) PCI Slot (PCI1, White) Dr.
- Page 23 EN2C606-4L 26.7cm (10.5 in) FRNT_FAN1 ATXPWR1 ATX12V_1 PSUSMB1 Keyboard Mouse DDR3_A1 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) DDR3_C2 (64 bit, 240-pin module) USB 2.0 Top: T: USB0 LAN2 B: USB1 LAN4 LAN3 LAN1 IPMI DDR3_G2 (64 bit, 240-pin module)
- Page 24 ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V_1) PSU SMBus (PSUSMB1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 1 x 240-pin DDR3 DIMM Slots (DDR3_C2,White) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 1356-Pin CPU Socket (CPU_BSP1) Front Fan Connector (FRNT_FAN2) Front Fan Connector (FRNT_FAN3)
- Page 25 USB 2.0 Ports (USB_6) System Panel Header (PANEL1) Intel C606 Chipset Dr. Debug Auxiliary panel header (AUX_PANEL1) Thermal Sensor header (TR1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) BMC SMB Header (BMC_SMB1) PCI Express 2.0 x1 Slot (PCIE1, White) from PCH PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1 PCI Slot (PCI3, White) from PCH PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1...
- Page 26 EN2C602-4L 26.7cm (10.5 in) FRNT_FAN1 ATXPWR1 ATX12V_1 PSUSMB1 Keyboard Mouse DDR3_A1 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) DDR3_C2 (64 bit, 240-pin module) USB 2.0 Top: T: USB0 LAN2 B: USB1 LAN4 LAN3 LAN1 IPMI DDR3_G2 (64 bit, 240-pin module)
- Page 27 ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V_1) PSU SMBus (PSUSMB1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 1 x 240-pin DDR3 DIMM Slots (DDR3_C2,White) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 1356-Pin CPU Socket (CPU_BSP1) Front Fan Connector (FRNT_FAN2) Front Fan Connector (FRNT_FAN3)
- Page 28 Dr. Debug Auxiliary panel header (AUX_PANEL1) Thermal Sensor header (TR1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) BMC SMB Header (BMC_SMB1) PCI Express 2.0 x1 Slot (PCIE1, White) from PCH PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1 PCI Slot (PCI3, White) from PCH PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1 Rear Fan Connector (REAR_FAN1)
- Page 29 EN2C602 26.7cm (10.5 in) FRNT_FAN1 ATXPWR1 ATX12V_1 PSUSMB1 Keyboard Mouse DDR3_A1 (64 bit, 240-pin module) DDR3_B1 (64 bit, 240-pin module) DDR3_C1 (64 bit, 240-pin module) DDR3_C2 (64 bit, 240-pin module) USB 2.0 Top: T: USB0 LAN2 B: USB1 LAN1 IPMI DDR3_G2 (64 bit, 240-pin module) DDR3_G1 (64 bit, 240-pin module) DDR3_F1 (64 bit, 240-pin module)
- Page 30 ATX Power Connector (ATXPWR1) ATX 12V Power Connector (ATX12V_1) PSU SMBus (PSUSMB1) Front Fan Connector (FRNT_FAN1) 3 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, DDR3_C1, Blue) 1 x 240-pin DDR3 DIMM Slots (DDR3_C2,White) CPU Fan Connector (CPU_FAN1_2) CPU Fan Connector (CPU_FAN1_1) 1356-Pin CPU Socket (CPU_BSP1) Front Fan Connector (FRNT_FAN2) Front Fan Connector (FRNT_FAN3)
- Page 31 Dr. Debug Auxiliary panel header (AUX_PANEL1) Thermal Sensor header (TR1) Intelligent Platform Management Bus header (IPMB_1) TPM Header (TPM1) COM Port Header (COM2) BMC SMB Header (BMC_SMB1) PCI Express 2.0 x1 Slot (PCIE1, White) from PCH PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1 PCI Slot (PCI3, White) from PCH PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1 Rear Fan Connector (REAR_FAN1) from CPU_BSP1...
-
Page 32: I/O Panel
1.5 I/O Panel EN2C606-4L/D12 1 PS/2 Mouse Port (Green) * 6 LAN RJ-45 Port (LAN3) 2 Serial Port (COM1) * 7 LAN RJ-45 Port (LAN4) * 3 LAN RJ-45 Port (LAN2) 8 USB 2.0 Ports (USB01) * 4 IPMI LAN Port 9 D-Sub Port (VGA) * 5 LAN RJ-45 Port (LAN1) 10 PS/2 Keyboard Port (Purple) - Page 33 EN2C602-4L/D12 1 PS/2 Mouse Port (Green) * 6 LAN RJ-45 Port (LAN3) 2 Serial Port (COM1) * 7 LAN RJ-45 Port (LAN4) * 3 LAN RJ-45 Port (LAN2) 8 USB 2.0 Ports (USB01) * 4 IPMI LAN Port 9 D-Sub Port (VGA)
- Page 34 EN2C602/D12 1 PS/2 Mouse Port (Green) * 5 LAN RJ-45 Port (LAN1) 2 Serial Port (COM1) 6 USB 2.0 Ports (USB01) * 3 LAN RJ-45 Port (LAN2) 7 D-Sub Port (VGA) * 4 IPMI LAN Port 8 PS/2 Keyboard Port (Purple) * There are two LEDs on each LAN port.
- Page 35 EN2C606-4L 1 PS/2 Mouse Port (Green) * 6 LAN RJ-45 Port (LAN3) 2 Serial Port (COM1) * 7 LAN RJ-45 Port (LAN4) * 3 LAN RJ-45 Port (LAN2) 8 USB 2.0 Ports (USB01) * 4 IPMI LAN Port 9 D-Sub Port (VGA) * 5 LAN RJ-45 Port (LAN1) 10 PS/2 Keyboard Port (Purple) * There are two LEDs on each LAN port.
- Page 36 EN2C602-4L 1 PS/2 Mouse Port (Green) * 6 LAN RJ-45 Port (LAN3) 2 Serial Port (COM1) * 7 LAN RJ-45 Port (LAN4) * 3 LAN RJ-45 Port (LAN2) 8 USB 2.0 Ports (USB01) * 4 IPMI LAN Port 9 D-Sub Port (VGA) * 5 LAN RJ-45 Port (LAN1) 10 PS/2 Keyboard Port (Purple) * There are two LEDs on each LAN port.
- Page 37 EN2C602 1 PS/2 Mouse Port (Green) * 5 LAN RJ-45 Port (LAN1) 2 Serial Port (COM1) 6 USB 2.0 Ports (USB01) * 3 LAN RJ-45 Port (LAN2) 7 D-Sub Port (VGA) * 4 IPMI LAN Port 8 PS/2 Keyboard Port (Purple) * There are two LEDs on each LAN port.
-
Page 38: Block Diagram
1.6 Block Diagram EN2C606-4L/D12 VRD 12 VRD 12 on Board on Board CH E Intel Processor Intel Processor DDR3 1066/1333/1600 DDR3 1066/1333/1600 CH A SNB-EN / IVB-EN QPI PORT : 8.0GT/s SNB-EN / IVB-EN CH F DDR3 1066/1333/1600 CH B DDR3 1066/1333/1600 LGA-1356 Pin Socket LGA-1356 Pin Socket... - Page 39 EN2C602-4L/D12 VRD 12 VRD 12 on Board on Board CH E Intel Processor Intel Processor DDR3 1066/1333/1600 DDR3 1066/1333/1600 CH A SNB-EN / IVB-EN SNB-EN / IVB-EN QPI PORT : 8.0GT/s CH F DDR3 1066/1333/1600 CH B DDR3 1066/1333/1600 LGA-1356 Pin Socket...
- Page 40 EN2C602/D12 VRD 12 VRD 12 on Board on Board CH E Intel Processor Intel Processor DDR3 1066/1333/1600 DDR3 1066/1333/1600 CH A SNB-EN / IVB-EN QPI PORT : 8.0GT/s SNB-EN / IVB-EN CH F DDR3 1066/1333/1600 CH B DDR3 1066/1333/1600 LGA-1356 Pin Socket LGA-1356 Pin Socket CPU_BSP1 CPU_AP1...
- Page 41 EN2C606-4L VRD 12 VRD 12 on Board on Board Intel Processor Intel Processor CH E DDR3 1066/1333/1600 SNB-EN / IVB-EN QPI PORT : 8.0GT/s SNB-EN / IVB-EN DDR3 1066/1333/1600 CH F DDR3 1066/1333/1600 CH A LGA-1356 Pin Socket LGA-1356 Pin Socket CH B CPU_BSP1 CPU_AP1...
- Page 42 EN2C602-4L SNB-EN / IVB-EN SNB-EN / IVB-EN 100MHz PCIE Gen3 BUS 100MHz 100MHz 100MHz INTEL 100MHz C602 100MHz 100MHz 100MHz PCI SLOT SPI FLASH 64Mb Nuvoton SPI FLASH NCT6776...
- Page 43 EN2C602 SNB-EN / IVB-EN SNB-EN / IVB-EN 100MHz PCIE Gen3 BUS 100MHz 100MHz INTEL C602 100MHz 100MHz 100MHz PCI SLOT SPI FLASH 64Mb Nuvoton SPI FLASH NCT6776...
-
Page 44: Installation
Chapter 2: Installation Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C602/D12 / EN2C606-4L / ® EN2C602-4L / EN2C602 are dual socket motherboards that support Intel ®... -
Page 45: Cpu Installation
2.3 CPU Installation Load Plate For the installation of Intel 1356-Pin CPU, please follow the steps below. Socket Body Contact Array Load Lever 1356-Pin Socket Overview Before you insert the 1356-Pin CPU into the socket, please check if the CPU surface is unclean or if there are any bent pins in the socket. - Page 46 1. It is recommended to use the cap tab to handle and avoid kicking off the PnP cap. 2. This cap must be placed if returning the motherboard for after service. Step 3. Insert the 1356-Pin CPU: Step 3-1. Hold the CPU by the edge which is marked with a black line.
- Page 47 Step 4. Close the socket: Step 4-1. Flip the load plate onto the IHS. Step 4-2. Press down the load lever, and secure it with the load plate tab under the retention tab.
-
Page 48: Installation Of Cpu Fan And Heatsink
2.4 Installation of CPU Fan and Heatsink This motherboard is equipped with 1356-Pin socket that supports Intel 1356-Pin CPUs. Please adopt the type of heatsink and cooling fan com- pliant with Intel 1356-Pin CPU to dissipate heat. Before you install the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dissipation. -
Page 49: Installation Of Memory Modules (Dimm)
2.5 Installation of Memory Modules (DIMM) This motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. For dual channel configuration, you always need to install two identical (the same brand, speed, size and chip-type) memory modules in the DDR3 DIMM slots to activate Dual Channel Memory Technology. - Page 50 The DIMM only fits in one correct orientation. It will cause per- manent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation. Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends fully snap back in place and the DIMM is properly seated.
-
Page 51: Expansion Slots (Pci And Pci Express Slots)
2.6 Expansion Slots (PCI and PCI Express Slots) EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C602/D12: There are 2 PCI slots and 5 PCI Express slots on the motherboard. PCI slot: The PCI1 and PCI2 slot are used to install expansion cards that have 32-bit PCI interface. -
Page 52: Installing An Expansion Card
In single VGA card mode, it is recommended to install a PCI Express x16 graphics card on PCIE6 slot. Installing an expansion card Step 1. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation. -
Page 53: Jumpers Setup
2.7 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”... -
Page 54: Onboard Headers And Connectors
2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Plac- ing jumper caps over the headers and connectors will cause permanent damage to the motherboard! Serial ATA2 Connectors These four Serial ATA2 (SATA2) connectors sup- (SATAII_2_3) - Page 55 SCU Connectors These eight SCU connec- (SCU_PORT_0) tors support SAS/SATA data SCU_PORT_0 SCU_PORT_2 SCU_PORT_4 SCU_PORT_6 (SCU_PORT_1) cables for internal storage (SCU_PORT_2) devices. The current SAS2/ (SCU_PORT_3) SATA3 interface allows up SCU_PORT_1 SCU_PORT_3 SCU_PORT_5 SCU_PORT_7 (SCU_PORT_4) to 6.0 Gb/s data transfer (SCU_PORT_5) rate.
- Page 56 TPM Header This connector supports (17-pin TPM1) Trusted Platform Module (see p.16,19, 22, 25, 28, 31) (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network se- curity, protects digital identi- ties, and ensures platform integrity.
- Page 57 PWRBTN (Power Switch): Connect to the power switch on the chassis front panel. You may configure the way to turn off your system using the power switch. RESET (Reset Switch): Connect to the reset switch on the chassis front panel. Press the reset switch to restart the computer if the computer freezes and fails to perform a normal restart.
-
Page 58: Speaker Header
B. Internet status indicator (2-pin LAN1_LED, LAN2_LED) These two 2-pin headers allow you to use the Gigabit internet indicator cable to connect to the LAN status indicator. When this indicator flickers, it means that the internet is properly connected. C. Chassis intrusion pin (2-pin CHASSIS) This header is provided for host computer chassis with chassis intrusion detection designs. -
Page 59: Cpu Fan Connectors
CPU Fan Connectors Please connect the CPU fan (4-pin CPU_FAN1_1) cable to the connector and (see p.15, 18, 21) match the black wire to the ground pin. (see p.24, 27, 30) +12V CPU_FAN_SPEED FAN_SPEED_CONTROL (4-pin CPU_FAN2_1) (see p.15, 18, 21) FAN_SPEED_CONTROL CPU_FAN_SPEED +12V... - Page 60 ATX Power Connector Please connect an ATX pow- er supply to this connector. (24-pin ATXPWR1) (see p.15, 18, 21, 24, 27, 30) Though this motherboard provides a 24-pin ATX power connector, it can still work if you adopt a traditional 20-pin ATX power supply. To use a 20-pin ATX power supply, please plug your power supply along Pin 1 and Pin 13.
- Page 61 Serial port Header This COM2 header supports (9-pin COM2) a serial port module. (see p.16, 19, 22, 25, 28, 31) Intelligent Platform This 4-pin connector is used Management Bus header to provide a cabled base- board or front panel connec- (4-pin IPMB_1) (see p.16, 19, 22, 25, 28, 31) tion for value added features...
- Page 62 SAS_CLOCK Serial General Purpose This header supports Serial SAS_LOAD Input/Output Header Link interface for onboard SAS / SATA connections. (SCU_SGPIO1) (see p.15, 18, 21, 24, 27, 30) SAS_DATAIN (SCU_SGPIO2) SAS_DATAOUT (see p.15, 24) SCLOCK (SATA_SGPIO1) SLOAD This header supports Serial (SATA_SGPIO2) Link interface for onboard (see p.15, 18, 21, 24, 27, 30)
-
Page 63: Driver Installation Guide
2.9 Driver Installation Guide To install the drivers to your system, please insert the support CD to your optical drive first. Then, the drivers compatible to your system can be auto- detected and listed on the support CD driver page. Please follow the order from top to bottom to install those required drivers. -
Page 64: Hot Plug For Hard Disk Drives
2.10 Hot Plug for Hard Disk Drives This motherboard supports Hot Plug for HDDs in AHCI / RAID mode. What is Hot Plug? If the HDDs are NOT set for RAID, it is called “Hot Plug” for the action to insert and remove the HDDs while the system is still powered on and in working condition. -
Page 65: Uefi Setup Utility
Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. -
Page 66: Navigation Keys
3.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen. -
Page 67: Main Screen
3.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. -
Page 68: Advanced Screen
3.3 Advanced Screen In this section, you may set the configurations for the following items: ACPI Configuration, WHEA Configuration, CPU Configuration, North Bridge Con- figuration, South Bridge Configuration, USB Configuration, ME Subsystem, Clock Generator Configuration,Storage Configuration,Super IO Configura- tion, Serial Port Console Redirection and Voltage Control. Setting wrong values in this section may cause the system to malfunction. -
Page 69: Acpi Configuration
3.3.1 ACPI Configuration Suspend Mode Use this item to enable or disable the highest ACPI Sleep state (S1). If enabled, the system enters S1 level when the SUSPEND button is pressed. ACPI HPET Table Use this item to enable or disable ACPI HPET Table. The default value is [Enabled]. - Page 70 USB Mouse Power On Use this item to enable or disable USB Mouse to turn on the sys- tem from the power-soft-off mode.
-
Page 71: Whea Configuration
3.3.2 WHEA Configuration WHEA Support Use this option to enable or disable Windows Hardware Error Architecture. The default value is [Enabled]. -
Page 72: Cpu Configuration
3.3.3 CPU Configuration CPU_BSP1 Information Display information regarding the primary processor (BootStrap Processor). CPU_AP1 Information Display information regarding the non-primary processor (Applica- tion Processors). Intel Hyper Threading Technology To enable this feature, a computer system with an Intel processor that supports Hyper-Threading technology and an operating sys- tem that includes optimization for this technology is required. - Page 73 No-Execute Memory Protection No-Execution (NX) Memory Protection Technology is an enhance- ment to the IA-32 Intel Architecture. An IA-32 processor with “No Execute (NX) Memory Protection” can prevent data pages from being used by malicious software to execute codes. This option will be hidden if the current CPU does not support No-Excute Memory Protection.
-
Page 74: North Bridge Configuration
This allows you to select a graphics device as the primary display. The default value is [PCI Express]. Onboard VGA Enable or disable the onboard VGA. For EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C602/D12: PCIE3 Link Speed This allows you to select PCIE3 Link Speed. PCIE5 Link Speed This allows you to select PCIE5 Link Speed. - Page 75 For EN2C606-4L / EN2C602-4L / EN2C602: PCIE2 & PCIE4 Link Width This allows you to select PCIE2 & PCIE4 Link Width. PCIE2 & PCIE4 Link Speed This allows you to select PCIE2 & PCIE4 Link Speed. PCIE5 Link Speed This allows you to select PCIE5 Link Speed. PCIE6 Link Speed This allows you to select PCIE6 Link Speed.
- Page 76 QPI ( Intel Quickpath Interconnect) Configuration Isoc Use this to enable/disable Isoc. It is recommended to select [En abled]. QPI Link Speed Mode This allows you to select QPI Link Speed Mode. It is recommend- ed to select [Auto]. QPI Link Frequency Select This allows you to select QPI Link Frequency.
- Page 77 Numa Enable or disable the support of Non-Uniform Memory Access. MPST Support Enable or disable the support of Memory Power StateTable. DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency auto matically.
-
Page 78: South Bridge Configuration
This allows you to enable or disable the Onboard LAN1. Onboard LAN2_USB01 This allows you to enable or disable the Onboard LAN2_USB01. Onboard LAN3 (For EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C606-4L / EN2C602-4LOnly) This allows you to enable or disable the Onboard LAN3. -
Page 79: Usb Configuration
3.3.6 USB Configuration USB 2.0 Controller Use this item to enable or disable the use of USB 2.0 controller. Legacy USB Support Use this option to select legacy support for USB devices. There are four configuration options: [Enabled], [Auto], [Disabled] and [UEFI Setup Only]. -
Page 80: Intel Me Subsystem
® 3.3.7 Intel ME Subsystem ® Intel ME Subsystem ® Display information regarding Intel Management Engine. -
Page 81: Clock Generator Configuration
3.3.8 Clock Generator Configuration Spread Spectrum It is recommended to disable this option for better system stability. -
Page 82: Storage Configuration
Use this to enable or disable S.M.A.R.T. (Self-Monitoring, Analy- sis, and Reporting Technology). Marvell 9230 SATA3_M0~M3 Operation (For EN2C606-4L/D12 / EN2C602-4L/D12 / EN2C602/D12 Only): This item is for SATAIII_M0_M1 and SATAIII_M2_M3 ports. Use this to enable or disable Marvell SATA3 operation mode. - Page 83 Onboard SCU Oprom/Driver Use this to enable or disable Onboard Marvell SATA3 Option ROM. If Option ROM is disabled, you cannot use the SATA de- vices connected to the Marvell SATA3 controller as Boot Device. Marvell 9220 SATA3_M0~M1 Operation (For EN2C606-4L / EN2C602-4L / EN2C602 Only): This item is for SATAIII_M0_M1 ports.
-
Page 84: Super Io Configuration
3.3.10 Super IO Configuration Serial Port 1 Configuration Use this item to configure the onboard serial port 1. Serial Port 2 Configuration Use this item to configure the onboard serial port 2. -
Page 85: Serial Port Console Redirection
3.3.11 Serial Port Console Redirection Console Redirection Use this option to enable or disable Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings. -
Page 86: Voltage Control
3.3.12 Voltage Control CPU 1 Core voltage Use this to select CPU 1 Core voltage. The default value is [Auto]. CPU 2 Core voltage Use this to select CPU 2 Core voltage. The default value is [Auto]. VCCSA 1 Voltage Use this to select VCCSA 1 Voltage. -
Page 87: Hardware Health Event Monitoring Screen
3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature and the critical voltage. CPU_Fan1_1 Setting This allows you to set the speed of CPU_Fan1_1. The default value is [Full On]. - Page 88 FRNT Fan2 Setting This allows you to set the speed of FRNT Fan2. The default value is [Full On]. FRNT Fan3 Setting This allows you to set the speed of FRNT Fan3. The default value is [Full On]. FRNT Fan4 Setting This allows you to set the speed of FRNT Fan42.
-
Page 89: Server Management
3.5 Server Management System Event Log Enter to configure System Event Logging features during boot. BMC Network Configuration Enter to configure BMC Network parameters. -
Page 90: Boot Screen
3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Select boot option #1. Boot Option #2 Select boot option #2. Boot Option #3 Select boot option #3. - Page 91 Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled]. AddOn ROM Display Use this option to adjust AddOn ROM Display. If you enable the option “Full Screen Logo” but you want to see the AddOn ROM information when the system boots, please select [Enabled].
-
Page 92: Security Screen
3.7 Security Screen In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. -
Page 93: Exit Screen
3.8 Exit Screen Save Changes and Exit When you select this option, the following message “Save con- figuration changes and exit setup?” will pop-out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”... -
Page 94: Event Logs
3.9 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. View Smbois Event Log This allows you to view the Smbios Event Log. -
Page 95: Software Support
Click on a specific item then follow the installation wizard to install it. 4.2.4 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. -
Page 96: Troubleshooting
Chapter 5: Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries to you and damages to motherboard components. 1. - Page 97 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock’s FAQ page: http://www.asrock.com/support/faq.asp 2. Try downloading and updating the latest UEFI on ASRock’s website:...
-
Page 98: Technical Support Procedures
