User Instructions
2/12
RGBW4C
Unpacking: Thank you for purchasing the RGBW4C by American DJ
Every RGBW4C has been thoroughly tested and has been shipped in
perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your fixture for any damage and be
sure all equipment necessary to operate the unit has arrived intact. In
the event damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Please
do not return this unit to your dealer without contacting customer sup-
port first.
Introduction: The RGBW4C is a 32-channel RGB, RGBW or RGBA
LED controller. Up to 8 LED fixtures or fixture groups can indepen-
dently be controlled via four fixture buttons. The units control panel
includes; 9 "Static Color/Chase" buttons, which contain pre-pro-
grammed colors and chase programs, 3 programmable color preset
buttons, 4 multi function faders that control RGBW intensities, as well
as program speed, fade time, and master dimmer. There are 8 but-
tons used to select the operation mode, including RGB Fade, Auto
Run, Color Macro, Chase, Sound Active, Strobe, Manual RGBW and
Blackout modes. The RGBW4C is one of the simplest and most ver-
satile LED controllers available today. It is ideal for D.J.'s, nightclubs,
lounges, bars, and anyone that wants easy control of LED Par's, Bar's,
Flood's, or Panel's.
Customer Support: American DJ
port line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2941
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
American DJ® www.americandj.com - RGBW4C
General Information
provides a toll free customer sup-
®
Page 2
.
®
Advertisement
Table of Contents
Related Manuals for American DJ RGBW4C
Summary of Contents for American DJ RGBW4C
- Page 1 RGB Fade, Auto Run, Color Macro, Chase, Sound Active, Strobe, Manual RGBW and Blackout modes. The RGBW4C is one of the simplest and most ver- satile LED controllers available today. It is ideal for D.J.’s, nightclubs, lounges, bars, and anyone that wants easy control of LED Par’s, Bar’s,...
-
Page 2: General Instructions
To ensure proper DMX data transmission, when using several DMX fixtures try to use the shortest cable path possible. The order The RGBW4C carries a 1 year (365 days) limited warranty. Please fill in which fixtures are connected in a DMX line does not influence the out the enclosed warranty card to validate your purchase and war- DMX addressing. - Page 3 3-PIN XLR to connect a DMX terminal, (Resistance 120 Ohm 1/4 W) between PIN 2 (DMX-) Figure 4 and PIN 3 (DMX +) of the last fixture. American DJ® www.americandj.com - RGBW4C Page 5 American DJ® www.americandj.com - RGBW4C Page 6...
-
Page 4: Controls And Functions
Controls and Functions RGBW4C Controls and Functions 1. FIXTURE SELECTION - The RGBW4C can control up to 8 LED fixtures. Press one of the buttons and the corresponding LEDs above the button will light indicating which LED fixture can be controlled. -
Page 5: Controls And Functions - Rear Panel
14. COLORS/CHASES/PRESETS - Press the COLOR buttons to activate desired COLOR MACROS, or when in CHASE MODE the color buttons will activate chases. See the built-in chases on page 10. American DJ® www.americandj.com - RGBW4C Page 9 American DJ® www.americandj.com - RGBW4C... -
Page 6: Operation
WHITE button Yellow/Purple chase time, and chase speed. Manual RGBW Color Mode: 1. Press the MANUAL RGBW button and the corresponding LED above the button will light. American DJ® www.americandj.com - RGBW4C Page 11 American DJ® www.americandj.com - RGBW4C Page 12... -
Page 7: Year Limited Warranty
American DJ, Inc. concludes, after inspection, affects the reliability of the product; if the product has been repaired or serviced by anyone other than the American DJ, Inc. factory unless prior written authorization was issued to purchaser by American DJ, Inc.; if the product is damaged because not properly maintained as set forth in the instruction manual. -
Page 8: Specifications
Tel: 323-582-2650 / Fax: 323-725-6100 Web: www.americandj.com / E-mail: info@americandj.com American DJ Europe Junostraat 2 6468 EW Kerkrade Netherlands service@adjgroup.eu / www.americandj.eu Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99 American DJ® www.americandj.com - RGBW4C Page 15...
