Summary of Contents for Alpine Multimedia Manager PXA-H900
- Page 1 PXA-H900 Multimedia Manager English Guide for Installation and Connections Français Guide d’installation et de connexions Español Guía de instalación y conexiones Español Italiano Svenska...
-
Page 2: Precautions
GUIDE FOR INSTALLATION AND CONNECTIONS • Please read this GUIDE FOR INSTALLATION AND CONNECTIONS and the OWNER’S MANUAL thoroughly to familiarize yourself with each control and function. We at ALPINE hope that your new PXA-H900 will give you many years of listening enjoyment. - Page 3 DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES. When drilling holes in the chassis for installation, take precautions so as not to contact, damage or obstruct pipes, fuel lines, tanks or electrical wiring. Failure to take such precautions may result in fire. DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.
- Page 4 If the fuse(s) blows more than once, carefully check all electrical connections for shorted circuitry. Also have your vehicle’s voltage regulator checked. Do not attempt to repair the unit yourself; return it to your Alpine dealer or nearest Alpine Service Station for servicing. Temperature In order to ensure proper performance, be sure the temperature in your vehicle is above 14 F (–10 C) and below 140 F (60 C) before turning your unit on.
-
Page 5: Table Of Contents
• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors. Contact them for further information. • Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information. -
Page 6: Accessories
Accessories Terminal board Ai-NET cable Display cable Stand Microphone cover (6m) (6m) Connection Spacer Bracket Spare fuse Hexagonal Cable (7.5A) wrench (M2.6) Velcro tape for Velcro tape for Battery (AAA) Flanged self- Hexagon screw mounting mounting stand tapping screw (M4 x 10) remote control (M4 x 14) unit holder... -
Page 7: Installation
Installation • Mounting the display 1. Remove the face plate. Face plate 2. Use a screwdriver, etc., to remove the lock pin, then take out the inner case. Inner case Lock pin 3. Mount the display using the included screws. Bracket Spacer Display... - Page 8 < JAPANESE CAR> 1. After step 2 on page 7, remove the included side bracket. Side bracket Side bracket 2. Mount the display using the included screws. Bracket Spacer Display Pan screw (M3 x 5) x 2 3. Once the spacer and bracket are mounted on the display, securely mount the bracket that was removed from the vehicle to the display.
- Page 9 • Mounting with the flush mount 1. Make holes approximately 178 (width) by 50 (height) mm in size in the dashboard, etc. WARNING: When making holes, be careful not to damage pipes, tanks, electric wires, etc. Doing so could lead to accidents or fire. 2.
- Page 10 • Mounting the base unit 1. Decide on the place of installation. • The trunk room, etc., is the best place. 2. Mark the positions of the mount screws at the place of installation. 3. Use a drill to make holes 3 mm in diameter or smaller. WARNING: When making holes, be careful not to damage pipes, tanks, electric wires, etc.
- Page 11 • Mounting the remote control unit holder • If the remote control unit is exposed to direct sunlight, remove it from the holder and store it in the glove compartment. • If the holder cannot be securely fastened in place with the Velcro, install it using screws. Remote Control Remote Control Holder Screw for mounting...
-
Page 12: Connections
Computer terminal PC CONTROL Used to make settings and adjustments with a computer. A special cable and computer software are required. For details, contact your store of purchase or an Alpine Information Center. MIC. MEMORY LOCK Reset switch Microphone jack Memory on/off selector switch Use this to connect a microphone. - Page 13 < Side Panel > Cord specifications Connect to: • Head unit input terminal (optical digital input) Connect to an Ai-NET product Used for system expansion (Ai-NET head unit, etc.). using an optical fiber cable. • Changer input terminal (optical digital input) Connect to an Ai-NET product Used for system expansion (Ai-NET changer, etc.).
-
Page 14: Examples Of System Expansion
Examples of system expansion • PXA-H900 + CDA-7990 Head Unit + CD Changer + External Amplifier Fiber Optic Cable (Sold Separately) Input Side CHANGER DIGITAL1 DIGITAL2 DIGITAL3 RCA INPUT ANALOG 1 INPUT Ai-NET IN CHANGER IN DISPLAY ANALOG2 ANALOG3 Fiber Optic Cable (Sold Separately) Ai-NET Cable (Included with CD Changer) Ai-NET Compatible CD Changer... - Page 15 • PXA-H900 + Ai-NET Compatible Head Unit + CD Changer + External Amplifier Fiber Optic Cable (Sold Separately) Input Side CHANGER DIGITAL1 DIGITAL2 DIGITAL3 RCA INPUT ANALOG 1 INPUT CHANGER IN Ai-NET IN DISPLAY ANALOG2 ANALOG3 Fiber Optic Cable (Sold Separately) Ai-NET Cable (Included with CD Changer) Ai-NET Cable (Included) Ai-NET Compatible...
- Page 16 The PXA-H900 can then be turned on using this switch. The PXA-H900 can be used with any head unit. However, only an Alpine Ai-NET compatible head unit will be able to take full advantage of all the features and functions of this processor.
- Page 17 Also refer to the operating instructions of the KCE-900E. For details, the CD Changer to “2” (Digital Output) contact your store of purchase or an Alpine Information Center. For the guide control cord, use guide Please observe the following when using Fiber Optic Cable.
-
Page 18: Installing With Wires Only (No Terminals)
Wire sizes usable with the PXA-H900 are AWG8 to AWG10. • If you do not know the thickness of the wires, contact your store of purchase, a service shop or/and Alpine service center. 2. Peel of 7 to 10 mm of the cord’s sheathing (the insulation in vinyl or other material) and expose the core (the conductor). - Page 19 Tel.: 1-800-ALPINE-1 (1-800-257-4631) ALPINE ELECTRONICS OF CANADA, INC. Suite 203, 7300 Warden Ave. Markham, Ontario L3R 9Z6, Canada Tel.: 1-800-ALPINE-1 (1-800-257-4631) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH...
