cable clip x 2
cam lock x 4
barrel
nut x 4
lower handle x 2
pivot block x 2
spring x 2
electric cable
with moulded
on plug
IMPORTANT !
Please check the contents of the carton are correct BEFORE assembling your new Flymo product.
The Loose Parts Pack is packaged underneath the deck of the product.
IF ANY PARTS ARE MISSING CONTACT:-
Husqvarna UK Ltd. Customer Service Department direct
Telephone : 0844 844 4558 UK
If not used properly this product can be dangerous! This product can cause serious injury to the
operator and others, the warnings and safety instructions must be followed to ensure reasonable safety
and efficiency in using this product. The operator is responsible for following the warning and safety
instructions in this manual and on the product. Never use the product unless the grassbox or guards
provided by the manufacturer are in the correct position.
Explanation of Symbols on your product
Warning
Read the user instructions carefully to
make sure you understand all the controls
and what they do.
Always keep the product on the ground when
operating. Tilting or lifting the product may cause
stones to be thrown out.
Keep bystanders away. Do not mow whilst
people especially children or pets are in
the area.
Carton Contents
lock off
button
start/stop
lever
washer
x 4
bolt
roller
half x 2
mulching
plug
1800 882 350 ROI
switchbox
grassbox
handle
upper
handle
Safety
Beware of sharp blades - remove plug from
mains before maintenance or if cable is
damaged.
Blades continue to rotate after the machine
is switched off.
Keep the cable supply away from the
blade.
PAGE 2
Multimo 360XC
Multimo 420XC
Easi-Reel
cable spool
grassbox
upper
grassbox
half x 2
instruction
manual
Fax : 01325 302530
