Wolf IG15/S Use & Care Manual
Grill module
Hide thumbs
Also See for IG15/S:
- User manual (120 pages) ,
- Use & care information manual (18 pages) ,
- Installation manual (12 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Wolf IG15/S
Summary of Contents for Wolf IG15/S
- Page 1 USE & CARE GUIDE Grill Module...
-
Page 2: Table Of Contents
Service Information ....18 Wolf Warranty ..... 19 Features and specifications are subject to change at any time without notice. -
Page 3: Wolf Grill Module
Wolf electric grill module. Your Wolf grill module is protected by a warranty that is one of the finest in the industry. Take a moment to read the warranty statement at the end of this guide and refer to it should service become necessary. -
Page 4: Safety Instructions
Have the installer show you the location of the circuit breaker or fuse so that you know where to turn off power. Warranty service must be performed by Wolf factory • certified service. Before performing any service, disconnect the power •... -
Page 5: Important Instructions
• included with this appliance. All service is to be not be put to any other use. referred to Wolf factory certified service. Use sturdy, properly insulated gloves or pot holders. • Do not line the drip pan or radiator plates or cover •... -
Page 6: Grill Module Features
Countdown timer with 1 to 99 minute range. • CSA certified for US and Canada. • Two and five year residential warranty—exclusions apply, see warranty at the end of this guide. GRILL MODULE Model IG15/S Cast iron grilling Two 1,400-watt grate heating elements Illuminated touch controls... - Page 7 For proper operation, the electric grill module must be Optional accessories are avail able through your authorized assembled in the correct alignment. Refer to the illustration Wolf dealer. For local dealer information, visit the find a below. showroom section of our website, wolfappliance.com.
-
Page 8: Grill Module Operation
Modes of Operation Grill Module Operation LOCK MODE The Wolf electric grill module operates by automatically cycling the heating elements between zero power and full In lock mode, all touch pad operations on the control panel power. As the heat is increased on the control panel, the are disabled and the heating elements are deenergized. - Page 9 Grill Module Operation wolfappliance.com Grill Module Operation SETTING CONTROLS To change the power level setting once the module is activated and the power bar indicator remains steadily lit: The control panel of your electric grill module is illumi- nated and features touch controls with graduated control •...
- Page 10 Grill Module Operation Grill Module Operation HEAT SETTING GUIDE SELECT FEATURE The select feature allows each of the two 1400-watt SETTING USES elements to be operated at the same power level or inde- LOW to MEDIUM Holding food to keep warm pendently.
- Page 11 Grill Module Operation wolfappliance.com Grill Module Operation SELECT FEATURE To change individual power level settings to the same setting, touch the SELECT touch pad until the BOTH To change the power level setting of the elements indicator light is illuminated. individually, touch the SELECT touch pad to select either the front or rear element.
- Page 12 Grill Module Operation Grill Module Operation TIMER – TOUCH PADS The grill module features a countdown timer located in the control panel. Refer to the illustration. The timer may be set in one-minute increments up to 99 minutes. Once set, the remaining time will be illuminated in the control panel as it counts down.
- Page 13 Grill Module Operation wolfappliance.com Using the Grill Module GRILLING GRILLING TIPS IMPORTANT NOTE: Before operating, make sure the • Never leave food unattended while grilling. grill module is assembled correctly. Refer to grill module • Trim excess fat from meats and notch the remaining fat assembly on page 7.
-
Page 14: Wolf Grilling Guide
Wolf Grilling Guide Grilling Guide FOOD THICK/WT SETTING INT TEMP TIME COMMENTS BEEF Hamburgers " " HIGH 160°F 16–20 min Grill, turning once when juices rise to – (13–19) (70°C) thick Medium the surface. Steaks, rare 1" thick HIGH 140°F 11–13 min... -
Page 15: Grilling Guide
Wolf Grilling Guide wolfappliance.com Grilling Guide FOOD THICK/WT SETTING INT TEMP TIME COMMENTS VEGETABLES Bell peppers, whole HIGH 15–18 min Turn every 4 minutes. Bell peppers, quartered HIGH 10–12 min Turn every 3 minutes. Corn on cob, husked HIGH 25–30 min... -
Page 16: Grill Module Care
Grill Module Care Care Recommendations IMPORTANT NOTE: Make sure the grill module is GENERAL CLEANING off and all surfaces are cool before cleaning any part of the Control panel. unit. • Use a spray degreaser to remove fingerprints and greasy spatters. Spray on a cloth and wipe the surface. STAINLESS STEEL SURFACES Do not spray directly on the control panel. -
Page 17: Troubleshooting Guide
Troubleshooting Guide wolfappliance.com Troubleshooting If your Wolf grill module is not operating properly, use the following troubleshooting guide before calling Wolf factory certified service. This guide will save you time and trouble and may help you avoid the expense of a service call. -
Page 18: Service Information
Wolf Appliance, Inc. ©Wolf Appliance, Inc. all rights reserved. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. -
Page 19: Wolf Warranty
LIMITED FIVE YEAR WARRANTY For five years from the date of original installation, Wolf Appliance will repair or replace the following parts that prove to be defective in materials or workmanship: gas burners (excluding appearance), electric heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and induction generators. - Page 20 WOLF APPLIANCE, INC. P. O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820 817488 REV-A 7/2011...
