With its unmatched versatility and high-tech styling, Sharp's new C45 LCD projector offers an exceptional feature set
that makes every presentation unforgettable. Whether it's ceiling-installed, transported to training venues and classrooms,
or your mobile presentation solution on the road, the NotevisionC45 consistently delivers unsurpassed data and video
image quality that will keep your toughest audiences engaged. The Sharp NotevisionC45 is a powerful presenter, and an
intelligent investment, that will take your next presentation to an unforgettable level.
General Specifications
Resolution
PG-C45X: XGA (1024 x 768)
PG-C45S: SVGA (800 x 600)
TV Lines
PG-C45X: 750 TV Lines (DTV 720p input)
PG-C45S: 500 TV Lines (S-Video)
Panel Type
3 – 0.99" Polysilicon TFT LCD
H & V Frequency
PG-C45X: fH 15-126 kHz/fV 43-200 Hz
PG-C45S: fH 15-102 kHz/fV 43-160 Hz
Dot Clock
PG-C45X: 230 MHz
PG-C45S: 120 MHz
PC Compatibility
PG-C45X: Up to UXGA (1600 x 1200) w/ImageACE Resizing
PG-C45S: Up to SXGA (1400 x 1050) w/ImageACE Resizing
Mac Compatibility
PG-C45X: 21" up to 1280 x 1024 w/ImageACE Resizing
PG-C45S: 21" up to 1152 x 870 w/ImageACE Resizing
WS Compatibility
1280 x 1024 (various modes w/ImageACE Resizing)
Video System
NTSC/DTV/PAL/SECAM – Interlaced or Progressive
Scan DTV/HD Compatible 480i/480p/540p/580i/
580p/720p/1035i/1080i
Resizing
PG-C45X: Advanced ImageACE Resizing – up to UXGA
PG-C45S: Advanced ImageACE Resizing – up to SXGA
Brightness
PG-C45X: 2500 ANSI Lumens w/90% CCR;
2000 ANSI Lumens in Low Power Mode
PG-C45S: 2400 ANSI Lumens w/90% CCR;
1900 ANSI Lumens in Low Power Mode
Contrast Ratio
400:1
PC Control
RS-232C – 9 pin DIN
Remote Control
IR Remote w/wired capability (3.5mm connector)
IR Carrier Frequency
38 kHz
Audio System
3 Watt Monaural
Lamp
AC 250 Watt UHP
Lamp Life
1500 hours Standard Mode/2000 hours Low Power Mode
Lamp Module No.
BQC-XGC50X//1 end user replaceable*
Fan Noise
36 dBStandard Mode/33 dB Low Power Mode
Power Source
100-240V AC, 50/60Hz
Power Consumption
340 Watt Standard Mode/290 Watt Low Power Mode/
0.8 Watt Standby Mode
Heat Dissipation
1280 BTU/hour Standard Mode
1090 BTU/hour Low Power Mode
Dimensions
15.4" x 3.9" x 11.6" (main body)
Weight
11.3 lbs.
Limited Warranty
3 yrs. Parts/Labor & 2 Yrs. Sharp Express Repair,
Lamp 90 Days
*Available through authorized parts distributor/dealer.
Design and specifications subject to change without notice.
SHARP is a registered trademark of SHARP Corporation. All
other trademarks are property of their respective owners.
P G - C 4 5 X / S
Inputs/Outputs
Input 1 – (1) Computer – RGB/Component, (Audio L/R shared 1 & 2)
Input 2 – (1) Computer – RGB/Component, (Audio L/R shared 1 & 2)
Input 3 – Composite Video (RCA), (Audio L/R shared 3 & 4) RCA (L/R)
Input 4 – S-Video (4 pin DIN), (Audio L/R shared 3 & 4) RCA (L/R)
Output 1– (1) Computer – RGB/Component, Audio (fixed or variable)
Output 2– Variable Audio Output (3.5mm stereo minijack)
Other – (1) RS-232C Serial Port (9pin D-sub)
Included Accessories
Remote Control, 11' RGB Signal Cable, 12' Grounded AC Cord, USB Cable,
Computer Audio Cable, DIN D-Sub RS-232C Adapter, Lens Cap, Sharp Advanced
Presentation Software (S.A.P.S.), Quick Reference Label, CD-ROM Manual,
Two AA Batteries, Air Filter
Optional Accessories
AN-C300WCC
AN-C300SC
AN-C300BAG
AN-GYR01
AN-XGCM55
AN-EP101B
AN-CMCSS16
AN-CMCSS46
AN-JT200
AN-C3CP
Lens Chart
Model
AN-C12MZ
AN-C27MZ** Telephoto Zoom
AN-C41MZ** Telephoto Zoom
Standard Lens
included with
projector
**Available 6/03
Projection Distances:
Screen Diagonal
Min/Max Projection Distance
Download Sharp's free lens calculator software from www.sharplenscalculator.com
L C D
P R O J E C T O R
15 PIN HD/3.5mm minijack
15 PIN HD/3.5mm minijack
(1) USB Port
(1) Wired Remote (3.5mm minijack)
Hard-sided Carry Case w/wheels (projector only)
"ATA" Shipping Case w/wheels (projector only)
Soft-sided Carry-on Bag (projector only)
RF Wireless Mouse System
Ceiling Mounting Bracket
Extension Tube for Ceiling Mount
16" Security Cable System
46" Security Cable System for use with AN-EP101B
Angle Mount Joint for Ceiling Mount
Component (3 RCA) to 15 pin HD Cable 10'
Focal
Lens
Aperture (F)
Length (f)
Short Throw
2.2-2.7
24.5-30.7mm
2.0-2.8
53.8-82.9mm
2.1-2.8
83.5-117.2mm
Standard Zoom
1.7-2.2
36.5-46.3mm
PG-C45X and PG-C45S
40" to 300"
4'8" to 46'4"
Approx. Min /Max Projection Distance
from Screen to Front of Lens
SHARP ELECTRONICS CORPORATION
LCD Products Group, Sharp Plaza, Mahwah, NJ 07430-2135
E-mail:ProLCD@SharpSEC.com
1-888-GO-SHARP
www.SharpLCD.com/Notevision
Printed in USA
LC-02-261
Zoom
Throw
Ratio
Ratio
1.25X
1.2-1.5
1.6X
2.7-4.2
1.4X
4.1-5.7
1.27X
1.8-2.3
02/03
Rev 1.0
