Perfect Image Centering Every time—Only From Sharp.
Sharp's unrivaled quest for easy, perfect projections continues with another innovative
industry first—Image Alignment Control. This exclusive Sharp feature assures perfect
image centering at the touch of a button. Simply adjust the optical lens shifter to
easily position your projection—horizontally, vertically, and diagonally. And unlike
digital correction, Image Alignment Control ensures your picture remains undistorted
thanks to automatic optical correction. No more relying on stacks of books. No more
moving the projector back, forth and sideways. Just perfect image placement every
single time. Sharp's Image Alignment Control— your image, where you want it.

General Specifications

Resolution SVGA (800 x 600) up to SXGA+ (1400 x 1050)
TV Lines 520 TV Lines (DTV 720p)
Device Type 0.55" p-si x 3 LCD
H & V Frequency fH 15-70 kHz/fV 43-85 Hz
Dot Clock 12 - 108 MHz
Compatibility PC, Mac and Workstation
Video System NTSC 3.58, 4.43/PAL50, 60 M,N/SECAM
Brightness 1200 ANSI Lumens Standard Mode
1080 ANSI Lumens Low Power Mode
Lens Shift Variable Lens Shift (Horizontal, Vertical, and Diagonal)
Contrast Ratio 350:1
Lens Type Recessed 1:1.25x Manual Zoom and Focus
Aspect Ratio 4:3
Remote Control IR
IR Carrier Frequency 38 kHz
Audio System 1.0 Watt Monaural
Lamp 130W AC; User Replaceable
Lamp Life 2000 hours Standard Mode
4000 hours Low Power Mode
Lamp Module BQC-PGB10S//1*
Fan Noise 35 dB Standard Mode
32 dB Low Power Mode
Power Source 100-240 VAC, 50/60Hz
Power Consumption 185W Standard Mode
170W Low Power Mode
Heat Dissipation 695 BTU/hour Standard Mode
640 BTU/hour Low Power Mode
Dimensions (w x h x d) 11.6" x 3.6" x 8.7"
Weight 6.0 lbs.
Limited Warranty 3 yrs. Parts/Labor & 2 Yrs. Sharp Express Repair,
Lamp 90 Days

Projection Distances

Screen Diagonal 40" to 300"
Min/Max Projection 3'11" to 37'1"
Distance Approx. Min /Max projection distance
from screen to front of lens
*Available through authorized parts distributor/dealer.
Design and specifications subject to change without notice.
SHARP is a registered trademark of SHARP Corporation. All
other trademarks are property of their respective owners.
Value Series
P G - B 1 0 S
L C D

Included Accessories

Remote control, two AA batteries, AC cord, extra air filter, 9'10" RGB
signal cable, operation manual, CD-ROM manual, "Quick Guide" label,
soft-sided projector carry bag

Optional Accessories

AN-C400CC Hardshell carry-on case (projector only)
AN-M300WB Soft-sided carry-on bag w/wheels (projector & PC)
AN-C400SL Hard-sided shipping case w/wheels & handle
AN-M100WB Hard-sided bag w/wheels (projector & PC)
AN-C3BN 5 BNC to 15 pin D-sub cable (10')
AN-C3CP 3 RCA to 15 pin D-sub cable (9'10")
AN-C10RS RS-232C serial control cable (32'10")
AN-MR1EL Remote IR receiver (for presentation control)
AN-GYRO1 RF wireless remote mouse system
AN-LS1 Ethernet to RS-23C network converter
AN-A1RS RS-232C adaptor
Inputs/Outputs
(1) Computer RGB/Component (15 pin HD)
(1) S-Video (4 pin DIN)
(1) Composite (RCA)
(1) Audio Input (shared) 3.5mm stereo minijack
(1) Computer RGB/Component Output (15 pin HD)
(1) RS-232C (9 pin DIN)
SHARP ELECTRONICS CORPORATION
LCD Products Group
Mahwah, NJ 07430-2135
E-mail:ProLCD@SharpSEC.com
1-866-4-VISUAL
www.SharpLCD.com/Notevision
Printed in USA
P R O J E C T O R
Image Alignment Control
LC-02-277 09/03 Rev 1.0
