- Page 1 USER MANUAL...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING: When using electric products, basic cautions should always be followed, including the following. 1. Read all safety and operating instructions before using this product 2. The product should be powered by a three pin `grounded (or earthed) plug connected to a power socket with a grounded earth outlet. 3.
- Page 3 Page 3 /12...
-
Page 4: Before Switching On
For a description of the function of each control feature, simply check the number with the explanations adjacent to each panel. Your Laney amplifier has undergone a thorough two stage, pre-delivery inspection, involving actual play testing. When you first receive your Laney guitar amplifier, follow these simple procedures: (i) Ensure that the amplifier is the correct voltage for the country it is to be used in. - Page 5 Laney endorsees that includes some of the world’s most famous and respected musicians. At the same time we believe we have not lost sight of the reason Laney was founded in the first place - a dedication to building great sounding amplification for working musicians.
-
Page 6: Front Panel Controls
Laney OPERATING INSTRUCTIONS FRONT PANEL CONTROLS This socket should be used for connecting your instrument to the amplifier. Only use a good quality screened cable. Controls the volume level of the clean channel. Controls the amount of bass or bottom end present on the clean channel. - Page 7 Controls the amount of signal returned from the onboard effects processor. The onboard digital effects have been custom designed by Laney to complement the LX120H with a choice of Delays, Flange, Rotary, Octave Down, Chorus, Reverb and combinations of these. Select your chosen effect here, and control the level with Fancy playing along with a backing track? Connect your CD/MP3 player here.
- Page 8 Laney OPERATING INSTRUCTIONS Power inlet socket. Connect to your power source. Make sure the specified voltage is correct for your country! This drawer contains the main safety fuse for the unit. USE ONLY THE CORRECT SIZE AND RATING OF FUSE AS SPECIFIED ON THE PANEL The mains fuse ratings are detailed in the specs section at the rear of this manual Displays the model number, power requirements and serial number of the unit.
-
Page 9: Operating Instructions
Laney OPERATING INSTRUCTIONS QUICK START SETTINGS - Suggestions only, experiment! LX120H FFECTS RIVE QUALISATION RIVE LEAN Dly+Ch Delay Rev+Ch Octave Chorus Rotary Flange CD/L OWER OOTSWITCH INE IN FFECT EVEL REBLE ASTER RUNCH REBLE OLUME NPUT CLEAN SETTINGS LX120H FFECTS... -
Page 10: Sample System
Laney OPERATING INSTRUCTIONS SAMPLE SYSTEM General Notes Amplifier connection: In order to avoid damage, it is advisable to establish and follow a pattern for turning on and off your equipment. With all system parts connected, turn on source equipment, tape decks, cd players, mixers, effects processors etc. BEFORE turning on your guitar amplifier. -
Page 11: Specifications
Laney OPERATING INSTRUCTIONS SPECIFICATIONS Supply Voltage ~100V, ~120V, ~220V, ~230V, ~240V 50/60Hz Factory Option Mains Fuse ~220V>~240V = T1A L. ~100>~120V = T2A L Power Consumption 300W Output Power Rating 120W Features Rugged construction TEC Tube Emulating Technology XTS eXtreme Tone Shaping... -
Page 12: Block Diagram
DRIVE LOUDSPEAKERS through your FX unit. FOOTSWITCH Laney POWER TO THE MUSIC BLUES METAL JAZZ ROCK AMPICONS ARE HERE TO HELP! In the interest of continued product development, Laney Reserves the right to amend product specification without prior notification.
