Summary of Contents for Fisher-Price Camera
- Page 1 www.fisher-price.com...
- Page 2 GConsumer Information EServicio de atención al consumidor GREAT BRITAIN Mattel UK Ltd, Vanwall Business Park, Maidenhead SL6 4UB. Helpline: 01628 500303; www.service.mattel.com/uk. ESPAÑA Mattel España, S.A., Aribau 200. 08036 Barcelona. cservice.spain@mattel.com. Tel: 902.20.30.10; http://www.service.mattel.com/es.
- Page 3 • Tool required for battery installation: Phillips screwdriver (not included). Loosen and tighten screws with a Phillips screwdriver. Do not over-tighten the screws. • When your camera is connected to your computer, you can delete or copy pictures by accessing your camera as a removable storage device.
- Page 4 E • Guardar estas instrucciones para futura referencia, ya que contienen información de importancia acerca de este producto. • Funciona con cuatro pilas alcalinas AA/LR6 (no incluidas) y una pila de botón de litio CR2032 (incluida). • La colocación de las pilas debe ser realizada por un adulto. •...
- Page 5 Do not place your picture subject in front of the light source since the picture subject will look dark in your photo. . Hold Still Make sure the picture taker and the picture subject aren’t moving. Also be sure your child holds the camera with two hands. . Proper Distance Centre the picture subject on the LCD screen.
- Page 6 E Pila de botón de litio CR0 (Debe ser colocada por un adulto.) EContenido de la caja del juguete G Camera E Cámara fotográfica G USB Cable (This is not a toy.) E Cable USB (Atención: el cable USB no es un juguete.)
- Page 7 G The Kid Tough™ Digital Camera is picture-perfect for your little one! It’s a real digital camera with a durable, drop resistant design. It’s a perfect way for kids to get creative by taking, viewing and even printing their own digital pictures! E ¡”Mi Primera Cámara Digital”...
- Page 8 E Puerto USB (abrir la tapa para acceder al puerto) G Power Button E Botón de encendido G Your Camera E La cámara G Viewfinder E Visor G LCD Screen E Pantalla de cristal líquido G Back View E Vista desde atrás...
- Page 9 E Compartimento de las pilas “AA” (LR6) G Battery Tray E Bandeja de la pila GYour Camera ELa cámara G SD Card Slot (SD Card not included and sold separately.) E Ranura de tarjeta SD (Tarjeta SD no incluida; se vende por separado.)
- Page 10 Flash Range ... 1,22 m - 2,23 m (4 ft. - 7,5 ft.) Camera Dimensions ... W - 14 cm (5,5”) x D - 7,6 cm (3.0”) x H - 8,57 cm (3,375”) Camera Weight ... 296 g (10,44 oz.) (without batteries or SD card) E Resolución de imagen ...
- Page 11 G“AA“ (LR) Battery Installation EColocación de las pilas “AA” (LR) G • Make sure the camera is turned off. • Locate the battery compartment door on the bottom of the camera. • Loosen the screws in the battery compartment door 1/4 turn. Remove the battery compartment door.
- Page 12 G“AA“ (LR) Battery Installation EColocación de las pilas “AA” (LR) E • La cámara debe estar apagada. • Localizar la tapa del compartimento de las pilas en la parte inferior de la cámara. • Desatornillar los tornillos de la tapa del compartimento de las pilas (girarlos 1/4 de vuelta) y retirarla. •...
- Page 13 GCR0 Battery Installation E Colocación de la pila CR0 G Battery Tray E Bandeja de la pila G Battery Compartment Door E Tapa del compartimento de las pilas CR0...
- Page 14 G The CR2032 lithium button cell battery provides power to your camera when you change the “AA” (LR6) batteries to ensure no pictures are lost. If you find that your camera loses pictures when you change the “AA” (LR6) batteries, it’s time to change the CR2032 lithium button cell battery.
- Page 15 GBattery Safety Information EInformación de seguridad acerca de las pilas G In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your toy. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
- Page 16 • To turn power off, press and hold the power button until you hear a tone. Hint: If you have not used the camera for a while, it shuts off automatically. To turn it back on, simply press the power button.
- Page 17 G • Have your child look through the viewfinder or look at the LCD screen to the picture subject. • While holding the camera steady, press the shutter button on the front of the camera. Listen for a “shutter sound” and the look for the camera •...
- Page 18 Hint: The flash works best when your picture subject is about 1,22 m - 2,23 m (4 ft. - 7,5 ft.) from the camera. • When the batteries are getting weak, the flash will not fully charge and the no flash lightning bolt screen.
- Page 19 G • Press the image forward or image back buttons to review the pictures you have taken. • When you are finished reviewing, the camera switches back to normal picture taking mode in a few seconds. E • Pulsar los botones “foto siguiente” o “foto anterior” para ver las fotos que se han tomado.
- Page 20 GDeleting Pictures E Cómo borrar fotos G • If you decide you do not want a picture, locate it by using the image forward or back buttons. • Then press the image delete button X . A trash can with a question mark •...
- Page 21 ECómo cambiar la resolución de las imágenes G Your camera comes set up to take normal quality pictures (standard resolution). If you’d like to take higher quality pictures (high resolution), follow these steps. • Press the image back and image forward at the same time and hold (1 and 2).
- Page 22 GSystem Requirements Operating System ...Windows 200, XP, Vista Hardware ...Pentium Class 500 MHz processor or better Input Port ...USB (version 1,1 or higher) Note: Use any image editing software to manage or edit your photos. Sistema operativo ...Windows 200, XP, Vista Hardware ...procesador Pentium Class de 500 MHz o superior Puerto de entrada ...USB (versión 1,1 o posterior) Nota: usar cualquier software de edición de imágenes para gestionar o retocar las fotos.
- Page 23 • Insert the larger end of the USB cord into a USB port on your computer, generally marked with this symbol • The camera turns on automatically and USB appears on the LCD screen Note: Do not disconnect the camera or computer while pictures are importing.
- Page 24 G • To disconnect your camera, click “eject disk” • Select the “USB Mass Storage Device” (your camera) and click “stop.” • Click “OK” to confirm. • A message will appear on your computer screen advising you to remove your device (camera).
- Page 25 • Loosen the screws in the battery compartment door 1/4 turn. Remove the battery compartment door. • Gently insert an SD card into the slot in the camera bottom, as shown. Gently press the SD card. You will feel a click when the SD card is in place.
- Page 26 GUsing an Optional SD Card EUso de una tarjeta SD opcional G Your Kid Tough™ Digital Camera has an internal memory that stores approximately 60 pictures (standard resolution setting) or 20 pictures (high resolution setting). If you’d like to be able to take and store more pictures, we recommend purchasing and using an SD card (sold separately and not included).
- Page 27 To see them again, simply remove the SD card. • When using an SD card from another camera, pictures already on the SD card may be lost when inserted into the Kid Tough™ Digital Camera. We recommend using a new SD card with this camera.
-
Page 28: Gtroubleshooting
“AA” (LR6) alkaline batteries. Press the power button on the back of the camera to turn it on. Download images to your computer or use the delete button on the camera to remove some of them. - Page 29 CR2032 lithium button cell battery is weak or exhausted Solution Clean the lens with a soft cloth. Try to keep the camera steady when you take pictures. Wait for flash to fully charge before you take a picture The focus range is from about 1,2 m (4 ft.) –...
- Page 30 E Guía de problemas y soluciones Problema La cámara no hace fotos Las fotos salen oscuras Las fotos salen sobreexpuestas. El flash tarda mucho en cargarse Causa Las pilas están gastadas o a punto de gastarse La cámara está apagada La memoria de la cámara o la tarjeta SD está...
- Page 31 Problema Las fotos salen borrosas Las fotos no se transfieren al ordenador La cámara no reconoce la tarjeta SD (no incluida; se vende por separado) Se han borrado las fotos de la cámara después de sustituir las pilas AA/LR6 E Guía de problemas y soluciones Causa El objetivo está...
- Page 32 • Wipe the camera with a soft, clean cloth. Do not immerse the camera. • This camera has no consumer serviceable parts. Please do not take this toy apart. • Protect the environment by not disposing of this product with household waste (2002/96/EC). Check your local authority for recycling advice and facilities (Europe only).
