- Page 1 ShoreTel 210 IP Phone Quick Install Guide & Warranty (Model S1A)
-
Page 2: Document And Software Copyrights
ShoreTel, Inc. ShoreTel, Inc. reserves the right to make changes without notice to the specifications and materials contained herein and shall not be responsible for any damage (including consequential) caused by reliance on the materials presented, including, but not limited to, typographical, arithmetic, or listing errors. -
Page 3: Package Contents
Installing Your ShoreTel 210 IP Phone This section shows how to install a ShoreTel 210 IP Phone. Instructions are provided for connecting phones with and without the AC power adapter. (This adapter may be necessary for networks that do not support the IEEE 802.3af standard for Power-over- Ethernet). - Page 4 Attach phone to base Connect the base to the larger of the Rotate the two pillars down onto the three tabs on the back of the phone. smaller tabs and snap into place.
- Page 5 Connect to powered network (no AC adapter required) If the LAN to which this phone will be connected supports power-over-Ethernet, no AC adapter is needed. The phone draws power from the Ethernet network. Connect the network cable between the LAN port on the back of the phone and an Ethernet jack in the workspace (or on a...
- Page 6 Connect to power & network (Non-powered Ethernet network requires AC power adapter) Connect the second network cable to the DATA port** on the adapter and an Ethernet jack in the workspace (or on a data switch/router). Connect the AC power cable between the adapter and an electrical socket.
- Page 7 Connect handset For optimal use, attach the longer end of the handset cable to the handset. Connect the short end of the handset cable to the jack on the phone body.
-
Page 8: Important Safety Instructions
Important Safety Instructions For IP TELEPHONE, MODELS 210, 530, & 560 This symbol is to alert you to important operating or servicing instructions that may appear in this owner’ s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. -
Page 9: Features And Functions
Features and Functions Handset LCD Display 2 x 24 characters Indicator LED Alerts the user to incoming calls and new voice messages. Function Keys overlay Vinyl overlay imprinted with international symbols Audio Control Keys Microphone Volume sets handset, speaker, and ring volume. - Page 10 12 AUG 2004 0096E 027D91 A label indicating the model number is affixed to the rear panel of each ShoreTel IP phone. Note that the newer S1A models have two Ethernet ports while the older S1 models have only one port.
-
Page 11: Warranty And Limitation Of Liability
ShoreTel or its authorized reseller. ShoreTel's sole obligation under this express warranty shall be, at ShoreTel's option and expense, to repair... - Page 12 This ShoreTel IP Phone has been marked with the CE mark. This mark indicates compliance with EEC directories 89/336/EEC and 73/23/EEC. A full copy of the Declaration of Conformity can be obtained from ShoreTel Inc., 960 Stewart Drive,...
- Page 13 ShoreTel® IP is a trademark of ShoreTel, Inc. in the United States, and various countries. Do not remove (or allow any third party to remove) any product identification, copyright, or other notices. The software contained within this product is protected by United States copyright laws and international treaty provisions.
