- Page 1 Hoshizaki Hoshizaki America, Inc. Stackable Crescent Cuber Models KM-1601SAH/3 KM-1601SWH/3 KM-1601SRH/3 INSTRUCTION MANUAL “A Superior Degree of Reliability” www.hoshizaki.com ™ Issued: 10-24-2005 Revised: 4-18-2011...
- Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.
-
Page 3: Table Of Contents
CONTENTS Important Safety Information ....................4 I. Specifications ........................5 A. Electrical Data ....................... 5 1. KM-1601SAH (air-cooled) ..................5 2. KM-1601SAH3 (air-cooled) ..................6 3. KM-1601SWH (water-cooled) .................. 7 4. KM-1601SWH3 (water-cooled) ................8 5. KM-1601SRH (remote air-cooled) ................9 6. -
Page 4: Important Safety Information
Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which could result in death or serious injury. CAUTION Indicates a situation which could result in damage to the unit. -
Page 5: Specifications
I. Specifications A. Electrical Data 1. KM-1601SAH (air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-1601SAH SERIAL NUMBER AC SUPPLY VOLTAGE 208-230/60/1 (3 WIRE WITH NEUTRAL FOR 115V) COMPRESSOR 230V 12.1RLA 96LRA PUMP 120V 1.2FLA 60W 115V 0.85FLA 50W OTHER 115V 0.3A... -
Page 6: Km-1601Sah3 (Air-Cooled)
2. KM-1601SAH3 (air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-1601SAH3 SERIAL NUMBER AC SUPPLY VOLTAGE 208-230/60/3 COMPRESSOR 230V 9.3RLA 75LRA PUMP 120V 1.2FLA 60W 115V 0.85FLA 50W OTHER 115V 0.3A MAXIMUM FUSE SIZE 20 AMPS MAX. HACR BREAKER (USA ONLY) 20 AMPS MAX. -
Page 7: Km-1601Swh (Water-Cooled)
3. KM-1601SWH (water-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-1601SWH SERIAL NUMBER AC SUPPLY VOLTAGE 208-230/60/1 (3 WIRE WITH NEUTRAL FOR 115V) COMPRESSOR 230V 12.1RLA 82LRA PUMP 120V 1.2FLA 60W --- --- --- OTHER 115V 0.3A MAXIMUM FUSE SIZE 20 AMPS MAX. -
Page 8: Km-1601Swh3 (Water-Cooled)
4. KM-1601SWH3 (water-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-1601SWH3 SERIAL NUMBER AC SUPPLY VOLTAGE 208-230/60/3 COMPRESSOR 230V 7.3RLA 65.5LRA PUMP 120V 1.2FLA 60W --- --- --- OTHER 115V 0.3A MAXIMUM FUSE SIZE 20 AMPS MAX. HACR BREAKER (USA ONLY) 20 AMPS MAX. -
Page 9: Km-1601Srh (Remote Air-Cooled)
MINIMUM CIRCUIT AMPACITY 20 AMPS DESIGN PRESSURE HI-467PSI LO-230PSI REFRIGERANT 404A TOTAL REFRIGERANT CHARGE WITH HOSHIZAKI REMOTE CONDENSER UNIT URC-21F R-404A 24 LB. 15 OZ. URC-22F R-404A 22 LB. 15 OZ. MOTOR-COMPRESSOR THERMALLY PROTECTED NOT INTENDED FOR OUTDOOR USE! Hoshizaki America, Inc. -
Page 10: Km-1601Srh3 (Remote Air-Cooled)
MINIMUM CIRCUIT AMPACITY 20 AMPS DESIGN PRESSURE HI-467PSI LO-230PSI REFRIGERANT 404A TOTAL REFRIGERANT CHARGE WITH HOSHIZAKI REMOTE CONDENSER UNIT URC-21F R-404A 24 LB. 15 OZ. URC-22F R-404A 22 LB. 15 OZ. MOTOR-COMPRESSOR THERMALLY PROTECTED NOT INTENDED FOR OUTDOOR USE! Hoshizaki America, Inc. -
Page 11: Dimensions/Connections
B. Dimensions/Connections 1. KM-1601SAH/3 (air-cooled) Note: The storage bin opening must match the bottom opening as in the illustration. -
Page 12: Km-1601Swh/3 (Water-Cooled)
2. KM-1601SWH/3 (water-cooled) Note: The storage bin opening must match the bottom opening as in the illustration. -
Page 13: Km-1601Srh/3 (Remote Air-Cooled)
3. KM-1601SRH/3 (remote air-cooled) Note: The storage bin opening must match the bottom opening as in the illustration. -
Page 14: Urc-21F, Urc-22F
4. URC-21F, URC-22F Units: mm [in.] TOP VIEW 1205 [47-7/16] 1120 [44-1/16] AIR FLOW AIR FLOW 1230 [48-7/16] FRONT VIEW 1178 [46-3/8] URC FAN MOTOR CONNECTION 7/8" DIA OPENING [2-15/16] [17-1/2]... -
Page 15: Installation And Operating Instructions
• Check that the compressor is snug on all mounting pads. • See the nameplate on the rear panel, and check that your voltage supplied corresponds with the voltage specified on the nameplate. • This icemaker can be installed on a storage bin 48" wide or wider. The recommended storage bin is Hoshizaki Ice Storage Bin, Model B-800 series. For further options, contact your local Hoshizaki distributor. • On remote air-cooled model, a remote condenser unit is needed. Hoshizaki Remote Condenser Unit, Model URC-21F or URC-22F is recommended. B. How to Remove Panels Top Panel See Fig. -
Page 16: Location
For best operating results: • Icemaker should not be located next to ovens, grills, or other high heat producing equipment. • Location should provide a firm and level foundation for the equipment. • For KM-1601SAH/3, allow 9" (23 cm) clearance at rear, sides, and top for proper air circulation and ease of maintenance and/or service should they be required. • For KM-1601SWH/3 and KM-1601SRH/3, allow 6" (15 cm) clearance at rear, sides, and top for proper air circulation and ease of maintenance and/or service should they be required. D. Setup... - Page 17 6) Install the bin control thermostat as follows: a. Remove the baffle from the storage bin. b. Remove the tie securing the bin control thermostat assembly. Remove the 2 thumbscrews below the bin control thermostat assembly. c. Remove the bin control thermostat assembly from the shipping hook by lifting it up and shifting it to the right.
-
Page 18: Installation Of Upper Unit
g. Remove the 2 screws from the lower part of the thermostat bracket (plastic) and use them to attach the thermostat extension bracket (stainless) to the thermostat bracket (plastic). See Fig. 5. Thermostat Extension Bracket (stainless) Thermostat Bracket (plastic) Thermostat Bulb Attachment (plastic) Fig. - Page 19 7) Remove the tie securing the upper unit's bin control thermostat assembly. 8) Remove the bin control thermostat assembly from the shipping hook by lifting it up and shifting it to the right. 9) Remove the thermostat bulb attachment (plastic) of the upper unit from the thermostat extension bracket (stainless).
-
Page 20: Electrical Connection
F. Electrical Connection WARNING For All Models 1. Electrical connection must be hard-wired and must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or severe damage to equipment. - Page 21 • On three phase models, the transformer’s voltage tap switch must be positioned to match incoming voltage at startup. See Fig. 8b. • CAUTION! On three phase models, connect the highest incoming voltage supply ("stinger leg") to the red power supply wire (red common wire to the compressor). • The opening for the power supply connection is 7/8" DIA to fit a 1/2" trade size conduit. KM-1601SAH KM-1601SAH3 KM-1601SWH KM-1601SWH3 KM-1601SRH KM-1601SRH3 WARNING...
-
Page 22: Installation Of Remote Condenser Unit
G. Installation of Remote Condenser Unit WARNING 1. Installation of the remote condenser unit must be performed by properly trained and EPA-certified service personnel. 2. The remote condenser unit must be installed in accordance with applicable national, state, and local codes and regulations. 3. -
Page 23: Setup
4. Line Set Mounting Holes CAUTION The icemaker, line set, and remote condenser unit must contain the same type of refrigerant. Mixing of refrigerants will result in improper operation and possible damage to the refrigeration system. • Precharged factory line sets, available as optional equipment from Hoshizaki America, are recommended. For details, see "II.G.4.a) Factory Line Set Installation." Field fabricated line sets are allowed. For details, see "II.G.4.b) Field Fabricated Line Set Installation." • The maximum line length for the standard refrigerant charge is 66 feet. With additional refrigerant, the maximum line length is 100 feet. For details, see "II.G.5. Refrigerant Charge (Line Set Exceeding 66 Feet)."... - Page 24 2) Insulate the two copper tubes separately. 3) Install Parker quick connect couplings on each end. OS-QUICK, a universal quick connect coupling kit available as optional equipment from Hoshizaki America, is recommended. CAUTION! Before brazing, remove the Schrader valve core from the access port.
- Page 25 6) Evacuate through the Schrader access ports on the Parker quick connect couplings and charge with R-404A refrigerant vapor to a pressure of 15 to 30 PSIG. 7) Connect the refrigerant lines to the appropriate male fittings on the remote condenser unit first and then at the icemaker.
-
Page 26: Refrigerant Charge (Line Set Exceeding 66 Feet)
The maximum line length for the standard refrigerant charge is 66 feet. Should an installation require a longer line length, additional refrigerant must be added. Add 0.4 oz. of R-404A for each foot over 66 feet to a maximum of 100 feet. Hoshizaki Technical Support is available at 1-800-233-1940 for recommendations. -
Page 27: Stacking Condenser Unit
1) Remove the louver panel. See Fig. 15. 2) Remove the junction box cover on the remote condenser unit. Remove the fan motor junction box cover on the icemaker. 3) Install a ground wire from the icemaker to the remote condenser unit. Use wire of an appropriate gage and outdoor rating. -
Page 28: Water Supply And Drain Connections
10 PSIG. Do not run the icemaker until the proper water pressure is reached. • A plumbing permit and services of a licensed plumber may be required in some areas. • External filters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki distributor for recommendations. • Water supply pressure should be a minimum of 10 PSIG and a maximum of 113 PSIG. If the pressure exceeds 113 PSIG, the use of a pressure reducing valve is required. • The icemaker and condensation drain line(s), storage bin drain line, and water-cooled condenser drain line (if applicable) must be run separately. -
Page 29: Icemaker
Separate piping to approved drain. Leave a 2-inch (5-cm) vertical air gap between the end of each pipe and the drain. Vent Tube Bin Drain Outlet 3/4" FPT Minimum 3/4" 2-inch (5-cm) air gap Nominal ID Hard Pipe Floor Drain KM-1601SAH/3 Fig. 17 KM-1601SRH/3... -
Page 30: Water-Cooled Condenser
2. Water-Cooled Condenser a) Connection to an Open Drain System • Condenser water supply inlet is 1/2" female pipe thread (FPT). A minimum of 3/8" nominal ID copper water tubing or equivalent is required for the condenser water supply line. • A condenser water supply line shut-off valve and drain valve should be installed. • Condenser drain outlet is 3/8" FPT. A minimum of 3/8" nominal ID hard pipe or equivalent is required for the condenser drain line. • In some areas, a back flow preventer may be required in the cooling water circuit. • In order to maintain the proper high side pressure, the condenser water supply inlet temperature should not drop below 45°F (7°C) and the condenser drain outlet temperature must be in the 104°F to 115°F (40°C to 46°C) range. - Page 31 b) Connection to a Closed Loop System • Condenser water supply inlet is 1/2" female pipe thread (FPT). A minimum of 3/8" nominal ID copper water tubing or equivalent is required for the condenser water supply line. • Condenser return outlet is 3/8" FPT. A minimum of 3/8" nominal ID copper water tubing or equivalent is required for the condenser return line. • Shut-off valves and drain valves should be installed at both the condenser water supply inlet and condenser return outlet. • The water supply to the condenser should not drop below 4 GPM. • The pressure differential between the condenser water supply inlet and condenser return outlet must be no less than 10 PSIG. • When using a glycol blend, the solution mixture should be less than 30% glycol.
-
Page 32: Final Checklist
2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3a) For KM-1601SAH/3, is there at least 9" (23 cm) clearance at sides, rear, and top of the icemaker for proper air circulation and ease of maintenance and service? 3b) For KM-1601SWH/3 and KM-1601SRH/3, is there at least 6" (15 cm) clearance at sides,... -
Page 33: Startup
J. Startup WARNING 1. All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. 2. If the icemaker is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. 3. -
Page 34: Cleaning And Maintenance
3. The storage bin is for ice use only. Do not store anything else in the storage bin. A. Cleaning and Sanitizing Instructions Hoshizaki recommends cleaning and sanitizing this unit at least once a year. More frequent cleaning and sanitizing, however, may be required in some existing water conditions. -
Page 35: Cleaning Procedure
1. Cleaning Procedure 1) Dilute 27 fl. oz. (800 ml) of Hoshizaki "Scale Away" with 5 gal. (19 l) of warm water. 2) Remove all ice from the evaporator and the storage bin. Note: To remove cubes on the evaporator, turn off the power supply and turn it back on after 3 minutes. The harvest cycle starts and the cubes will be removed from the evaporator. -
Page 36: Sanitizing Procedure - Following Cleaning Procedure
21) Remove the front panel and fully open the cleaning valve. 22) Move the control switch to the "WASH" position. 23) Replace the front panel in its correct position. 24) Turn on the power supply to rinse off the cleaning solution. 25) Turn off the power supply after 5 minutes. 26) Remove the front panel and the insulation panel. -
Page 37: Maintenance
B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. WARNING 1. Only qualified service technicians should service this icemaker. 2. Move the control switch to the "OFF" position and turn off the power supply before servicing. Lockout/Tagout to prevent the power supply from being turned back on inadvertently. - Page 38 5) Attach a compressed air or carbon dioxide supply to the icemaker water supply line drain valve. 6) Move the control switch to the "ICE" position. 7) Replace the front panel in its correct position, then turn on the power supply. 8) Blow the icemaker water supply line out using the compressed air or carbon dioxide supply.
- Page 39 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com 91A1GJ10F...
