Sunfire SDG-1 Parts List

Gas convection ovens
Hide thumbs Also See for SDG-1:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
Table of Contents
CLICK
Gas Convection Ovens
SDG-1, SDG-2
models
UP TO
12052300xxxxx
31-May-12
(serial#)
(date)
Phone (US & Canada): 1 800 427 6668
Fax (US & Canada): 1 800 361 7745
www.Garland-Group.com
U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)

Advertisement

Table of Contents
loading

Related Manuals for Sunfire SDG-1

Summary of Contents for Sunfire SDG-1

  • Page 1 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models UP TO 12052300xxxxx 31-May-12 (serial#) (date) Phone (US & Canada): 1 800 427 6668 Fax (US & Canada): 1 800 361 7745 www.Garland-Group.com U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)
  • Page 2 Quality Factory Replacement Parts for the World’s Finest Foodservice Equipment Solutions This parts list is updated regularly. Please find the most current revision www.Garland-Group.com on our website @...

  • Page 3: Table Of Contents

    Gas Convection Ovens SDG-1, SDG-2 models UP TO 12052300xxxxx 31-May-12 (serial#) (date) Table of Contents � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5...
  • Page 4 Blank Page...
  • Page 5 Table of Contents CLICK Rating Plate Location The Rating Plate (Product Identification Plate) contains important information on the unit’s configuration. Units Built UPTO 31-MAR-2011 Units Built FROM 01-APR-2011 Door Motor Rating Plate Rating Plate (On the Inside of Lower Front Cover) (On the Outside of Left Body Side Panel) Serial# (Year/Month Information) The Serial Number is 13 Digits long and is stamped on the Rating Plate.
  • Page 6 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models MANUAL CONTROL PANEL COMPONENTS COOK HIGH POWER 12 & 11 (For Timer Item# 14A) COOL DOWN TIMER 13 (For Timer Item# 14B) TEMP 500F 450F 200F 400F 250F 350F 300F 11 &...
  • Page 7 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 MANUAL CONTROL PANEL COMPONENTS ITEM PART # DESCRIPTION Control Panel - S/S, Manual 1719805 Note: Control Panel with P/N 1719801 is No Longer Available. 1657913 Overlay - Manual Control, 2SP, Sunfire...
  • Page 8 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models ELECTRONIC CONTROL PANEL COMPONENTS (IM300 SERIES) IM300 Series Control: Used FROM March-1999 UP TO March-2003 LIGHT HIGH COOL DOWN LOAD PROBE AUTO COOL ERROR DOWN F° C° TEMPERATURE TIMER IM300 Control Panel...
  • Page 9 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 ELECTRONIC CONTROL PANEL COMPONENTS (IM300 Series - Used FROM March-1999 UP TO March-2003) ITEM PART# DESCRIPTION Control Panel Assembly CK1946693 Note: Assembly includes an overlay (1908517), a control panel SDG IM300 (1946693), and a Fast Control keypad (1911701).
  • Page 10 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models BURNER AND GAS LINE COMPONENTS Gas Components Page 10 U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)
  • Page 11 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 BURNER AND GAS LINE COMPONENTS ITEM PART# DESCRIPTION 1467200 Burner Pan 1467400 Burner 1467100 Cross-over Bracket 1265504 Cross-over Angle (alt p/n: G03065-1-9) 1265548 Orifice Fitting - Natural Gas, 48F 1265556 Orifice Fitting - Propane Gas, 56F Tail Pipe Assembly, 37-1/2”...

  • Page 12: Table Of Contents

    Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models DOOR COMPONENTS & ASSEMBLIES Left Door Assembly Right Door Assembly Chain Assembly Door Switch Left Door Right Door Components Components Door Page 12 U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)
  • Page 13 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 DOOR COMPONENTS & ASSEMBLIES ITEM PART# DESCRIPTION 1534500 Seal - Door, Bottom TOP - 3’ G03269R Seal - Door, Top / Left / Right (sold by the foot) L/R - 2’ EACH...

  • Page 14: Table Of Contents

    SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 DOOR COMPONENTS & ASSEMBLIES ITEM PART# DESCRIPTION Door Frame Assembly - Left 1011895 Note: Used UP TO 26-Mar-2003 Door Frame Assembly - Left CK4515197 Note: Used From 27-Mar-2003 Liner - Left Door...
  • Page 15 NOTES U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18) Page 15...
  • Page 16 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models OVEN COMPONENTS Oven Components Page 16 U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)

  • Page 17: Oven Components

    SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 OVEN COMPONENTS ITEM PART# DESCRIPTION G02952-01P Blower Wheel Assembly - Nickle Plated 1011902 Motor Mount Plate 1915921 Insulation, Motor Pocket 1012000 Motor Mount Pocket CK1012498 Motor Mount Brace Assembly - Side...
  • Page 18 Table of Contents CLICK Gas Convection Ovens SDG-1, SDG-2 models MAIN ExTERIOR COMPONENTS Back View DOUBLE STACK SINGLE UNIT Double Deck Front View with Top Combustion Cover Removed 4A, 4B, 4C Double Deck Back View Main Exterior Components Page 18...
  • Page 19 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 MAIN ExTERIOR COMPONENTS ITEM PART# DESCRIPTION 1300600 Top, SS 1300503 Left Boday Side Panel, SS 1300509 Right Body Side Panel, SS (Deep) CK1721001 Combustion Chamber Front Assembly CK4515638 Combustion Chamber Cover...
  • Page 20 SUNFIRE PARTS IDENTIFICATION Gas Convection Ovens models SDG-1, SDG-2 LIST OF WIRING DIAGRAMS, CASTER AND VENTILATIO KITS WIRING DIAGRAMS - GAS PART# DESCRIPTION 1266738 Wiring Diagram - SDG, 120V, 60Hz, Gas CASTER KITS PART# DESCRIPTION CK1129 Single Deck Caster Kit...
  • Page 21 SUNFIRE PARTS LIST - REVISION hISTORY (SDG) PAGE# ITEM# NOTES DATE Part# was 1657913. Description was thermostat. OCT 31/02 Quantity changed, was 1. New part number added New drawing NOV 12/02 8, 9 Part# deleted APR 29/03 12, 13 26, 27...
