- Page 1 User’s Manual POE-1200 POE-2400 IEEE 802.3af 12 / 24-Port Power over Ethernet Web Management Injector Hub...
-
Page 2: Fcc Warning
Trademarks Copyright © PLANET Technology Corp. 2008. Contents subject to which revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. -
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ............................1 1.1 P ..........................1 ACKAGE ONTENTS 1.2 P ..........................1 RODUCT ESCRIPTION 1.3 H ......................... 2 OW TO ANUAL 1.4 P ..........................3 RODUCT EATURES 1.5 P .......................... 4 RODUCT PECIFICATIONS 2. INSTALLATION ............................5 2.1 H ........................... -
Page 4: Introduction
48VDC power for any remote IEEE802.3af powered device (PD) like Wireless LAN Access Point, IP phone, LAN Camera or any other network devices. With support for 130 / 260 watts power supply, POE-1200 / POE-2400 should provide the sufficient power to the 12 / 24 remote devices. -
Page 5: How To Use This Manual
This section contains the Power over Ethernet compatibility information of the POE-1200 / POE-2400. In the following section, terms “PoE Injector Hub” with upper case mean the two injectors, i.e. POE-1200 or POE-2400. Terms with lower case “injector” means any 802.3af power injectors. “PD” means the abbreviated from 802.3af powered... -
Page 6: Product Features
1.4 Product Features Interface 24 / 48-Port RJ-45 STP 12 / 24-Port “Data input” 12 / 24-Port “Data + Power output” 1 10/100Base-TX Management port Complies with IEEE 802.3af Power over Ethernet Mid-Span PSE Up to 12/24 IEEE 802.3af devices powered Support PoE Power up to 15.4 watts for each PoE ports Auto detect powered device (PD) Circuit protection prevent power interference between ports... -
Page 7: Product Specifications
1.5 Product Specifications Product POE-1200 POE-2400 Hardware Specification “Data” 12 x RJ-45 STP 24 x RJ-45 STP Input Ports Interface “Data+Power” 12 x RJ-45 STP 24 x RJ-45 STP Output Ports Management Port 1 x RJ-45; 10/100Base-TX, auto-negotiation, auto-MDI System: Power x 1 Per PoE Port: PoE in Use x 1 •... -
Page 8: Installation
2.1 Hardware Description The section describes the hardware of the POE-1200 / POE-2400 and gives a physical and functional overview. 2.1.1 Injector Front Panel The unit front panel provides a simple interface monitoring the PoE Injector Hub . -
Page 9: Led Indicators
Lights to indicate that the port is in use and supplying 48V DC power 2.1.3 Injector Rear Panel The rear panel of the PoE Injector Hub indicates an AC inlet power socket, which accepts input power from 100 to 240V AC, 50/60Hz. Figure 2-3 POE-1200 Rear Panel... -
Page 10: Installing The Poe Injector Hub
2.2 Installing the PoE Injector Hub This section describes how to install your POE-1200 / POE-2400 802.3af Power over Ethernet Injector Hub and make connections to the PoE Injector Hub. Please read the following topics and perform the procedures in the order being presented. -
Page 11: Rack Mounting
Step5: Supply power to the PoE Injector Hub. Connect one end of the power cable to the PoE Injector Hub. Connect the power plug of the power cable to a standard wall outlet. When the PoE Injector Hub receives power, the Power LED should remain solid Green. 2.2.2 Rack Mounting To install the PoE Injector Hub in a 19-inch standard rack, follow the instructions described below. -
Page 12: Network Application Installation
Figure 2-6 Mounting thePoE Injector Hub in a Rack Step6: Proceeds with the steps 4 and steps 5 of session 2.2.1 Desktop Installation to connect the network cabling and supply power to your PoE Injector Hub. 2.2.3 Network Application Installation The PoE Injector Hub is not equipment with data switching function between data ports. -
Page 13: Power Over Ethernet Powered Device
“DATA” port and “DATA+PoE” port can still be transmitted without data loss. The POE-1200 / POE-2400 Mid-Span Injector Hub doesn’t support Gigabit data rate. The Ethernet switches or PoE PDs with Gigabit interface will operate at 100Mpbs Full Duplex mode when connect to the Mid-Span Injector Hub. -
Page 14: Management
3 MANAGEMENT This chapter describes how to manage the Web Smart PoE Injector Hub. Topics include: - Overview - Management method - Logging on to the Web Smart PoE injector Hub 3.1 Overview The Web Smart PoE injector Hub provides a user-friendly, Web interface. Using this interface, you can perform various device configuration and management activities, including: System Power over Ethernet... - Page 15 Figure 3-1 Web Management over Ethernet When the following login screen appears, please enter the default username "admin" and password “admin” (or the password you have changed via console) to login the main screen of PoE Injector Hub. The login screen in Figure 3-12 appears.
-
Page 16: Planet Smart Discovery Utility
3.3.2 PLANET Smart Discovery Utility For easily list the PoE Injector Hub in your Ethernet environment, the Planet Smart Discovery Utility from user’s manual CD-ROM is an ideal solution. The following install instructions guiding you for run the Planet Smart Discovery Utility. Deposit the Planet Smart Discovery Utility in administrator PC. - Page 17 This utility show all necessary information from the devices, such as MAC Address, Device Name, firmware version, Device IP Subnet address, also can assign new password, IP Subnet address and description for the devices. After setup completed, press “Update Device”, “Update Multi” or “Update All” button to take affect. The meaning of the 3 buttons above are shown as below: Update Device: use current setting on one single device.
-
Page 18: Web Configuration
4 WEB CONFIGURATION The PoE Injector Hub provide Web interface for PoE smart function configuration and make the PoE Injector Hub operate more effectively - They can be configured through the Web Browser. A network administrator can manage and monitor the PoE Injector Hub from the local LAN. -
Page 19: Web Panel
4.2 Web Panel At the top of the Web management page, the active panel displays the link status of management port and PoE ports. Figure 4-2 Main menu screen Green lit is the network data send or receiver, Orange lit is the PoE in use. 4.3 System The System function allows viewing system information, IP Configuration and Password Setting. -
Page 20: System Information
4.3.1 System Information The System information allows viewing system MAC Address, Software Version, Hardware Version, IP Address, Subnet Mask and Gateway.. As showed in Figure 4.4 Figure 4-4 System Information screen The page includes the following fields: Object Description MAC Address Specifies the PoE Injector Hub MAC address. -
Page 21: Password Setting
The page includes the following configurable data: Object Description DHCP Client Choose what the PoE Injector Hub should do following power-up: transmit a DHCP request, or manual setting (Disable). The DHCP client function only works if you haven't assigned a static IP address that different than the PoE Injector Hub default IP. -
Page 22: Poe
Total Limit. Set limit value of the total POE port provided power to the PDs. For POE-1200, the total PoE power reservation from Port-1~12 is up to 110W For POE-2400, the total PoE power reservation from Port-1~24 is up to 220W Power reservation Show the total watts usage of PoE Injector Hub. - Page 23 PoE Function Can enable or disable the PoE function. Priority Set port priority for the POE power management It can choose the “port priority”, value is “1~4”. High priority is “1”. Device class Class 0 is the default for PDs. However, to improve power management at the PSE, the PD may opt to provide a signature for Class 1 to 3.
-
Page 24: Tools
4.5 Tools This function displays the PoE Injector Hub tools; include “System Reboot”, “Configuration Setting”, “Alert trap Configuration” and “Firmware upgrade”. As showed in Figure 4-8. Figure 4-8 Tools screen Object Description System Reboot Allow to reboot the PoE Injector Hub . Explained in section 4.5.1. -
Page 25: Configuration Setting
4.5.2 Configuration Setting This function allows backup and restore the current configuration of PoE Injector Hub, or reset the converter to factory default. The description of the three items as follow and screen in Figure 4-10 appears. ■ Backup - To backup/save the current configuration to the storage block on this converter. ■... -
Page 26: Factory Reset
Restore ■ The PoE Injector Hub will restore to previous backup/saved configuration while the “Restore” button be pressed. And please note that once the Restore button be pressed, Web interface will disconnected for a while. Reload the Web browser to re-login the system. Figure 4-13 Configuration restore screen Factory Reset ■... -
Page 27: Alert Trap Configuration
4.5.3 Alert Trap Configuration This function displays the PoE Injector Hub alert trap configuration; include “enable” or “disable” the trap mode and set the alert IP address. As showed in Figure 4-16. Figure 4.16 Alert Trap Configuration screen Object Description Trap mode Can choose enable/disable to get the trap Alert IP address... -
Page 28: Firmware Upgrade
4.5.4 Firmware Upgrade This section provides firmware upgrade of PoE Injector Hub, after choose this function and the following screen appears in Figure 4-17. Please press “Update” button to continue following firmware upgrade process. Figure 4-17 Firmware Upgrade screen Please wait for two seconds and the page will show to next firmware upgrade web page, the screen in Figure 4-18 appears. -
Page 29: Logout
Figure 4-19 Firmware Upgrade screen Do not power off the PoE Injector Hub until the update progress is complete. Do not quit the Firmware Upgrade page without press the “Upgrade” button - after the image is loaded. Or the system won’t apply the new firmware. Users have to repeat the firmware upgrade processes again. - Page 30 Figure 4-21 Login screen...
-
Page 31: Power Over Ethernet Overview
5. POWER OVER ETHERNET OVERVIEW What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords. - Page 32 The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer. In this mode of operation the pair on pins 3 and 6 and the pair on pins 1 and 2 can be of either polarity.
-
Page 33: The Poe Provision Process
6. THE POE PROVISION PROCESS While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing CAT-5 cables. Without proper preparation, doing so may result in damage to devices that are not designed to support provision of power over their network interfaces. -
Page 34: Start-Up
6.3 Start-up Once line detection and optional classification stages are completed, the PSE must switch from low voltage to its full voltage capacity (44-57 Volts) over a minimal amount of time (above 15 microseconds). A gradual startup is required, as a sudden rise in voltage (reaching high frequencies) would introduce noise on the data lines. -
Page 35: Troubleshooting
Solution: Please check the cable type of the connection from POE-1200 / POE-2400 to the other end. The cable should be an 8-wire UTP, Category 5/5e, EIA568 cable within 100 meters. A cable with only 4-wire, short loop or over 100 meters, all will affect the power supply. -
Page 36: Mdi Settings
APPENDIX A A.1 MDI Settings The Medium-Dependant Interface (MDI or RJ-45) serves as the data/power interface between Ethernet elements. As such, it has two optional connection methods, to carry the power. named Alternative A & B. Table 1 details the two power feeding alternatives. -
Page 37: Data Out Poe Injector Rj-45 Port Pin Assignments
A.3 DATA OUT PoE Injector RJ-45 Port Pin Assignments PIN NO RJ-45 SIGNAL ASSIGNMENT Output Transmit Data + Output Transmit Data - Receive Data + Power + Power + Receive Data - Power - Power - A.4 RJ-45 pin assignment of non-802.3af standard PD with PD with Mid-Spain POE Mid-Span RJ-45 assignment Pin out of Cisco non-802.3af standard PD PIN NO... - Page 38 Before you powered PD, please check the RJ-45 connector pin assignment follow IEEE 802.3af standard, otherwise you may need change one of the RJ-45 connector pin assignment, which attacted with the UTP cable.
-
Page 39: Power Over Ethernet Compatibility Test
APPENDIX B B.1 Power over Ethernet Compatibility test PoE Output Note [PLANET POE-151S-12V] + [PLANET ICA-500] 9.6W [PLANET POE-151S-12V] + PLANET ICA310 6.4W Standby [PLANET POE-152S-12V] + [PLANET ICA-500] 7.3W [PLANET POE-151S-5V] + [Sparklan A+G AP] 5.7W~7.6W [PLANET POE-151S-12] + IR338 5.1W LED Off [PLANET POE-151S-12] + IR338... -
Page 40: Ec Declaration Of Conformity
EC Declaration of Conformity For the following equipment: *Type of Product: 12-Port IEEE 802.3af Injector Hub *Model Number: POE-1200 * Produced by: Manufacturer‘s Name : PLANET Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road Hsin Tien, Taipei, Taiwan , R.O.C. - Page 41 24-Port IEEE 802.3af Injector Hub *Model Number:POE-2400 * Produced by: Manufacturer‘s Name : PLANET Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road Hsin Tien, Taipei, Taiwan , R.O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC).
