La Crosse Technology WS-9124TWC-IT Instruction Manual

Wireless 915 mhz temperature station
Hide thumbs

Advertisement

Table of Contents

Contents
Language
_______________________________________________
English
French
Spanish
WIRELESS 915 MHz TEMPERATURE STATION
INTRODUCTION:
Congratulations on purchasing this compact 915MHz Wireless
Temperature Station which displays time, indoor temperature,
outdoor temperature and indoor humidity readings. With two easy to
use keys, this product is ideal for use in the home or office.
This product offers:
Instruction Manual
INSTANT TRANSMISSION is the state-
of-the-art new wireless transmission
technology, exclusively designed and
developed by LA CROSSE
TECHNOLOGY. INSTANT
TRANSMISSION offers you an
immediate update (every 16 seconds!)
of all your outdoor data measured
from the transmitters: follow your
climatic variations in real-time!
1
Page
1
47

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology WS-9124TWC-IT

Summary of Contents for La Crosse Technology WS-9124TWC-IT

  • Page 1 INSTANT TRANSMISSION is the state- This product offers: of-the-art new wireless transmission technology, exclusively designed and developed by LA CROSSE TECHNOLOGY. INSTANT TRANSMISSION offers you an immediate update (every 16 seconds!) of all your outdoor data measured...
  • Page 2 FEATURES: Hanging Hole Display Battery compartment cover Function Keys Removable stand The Temperature Station • Quartz clock in 12 or 24-hour time display (hour and minute, manually set) • Indoor and outdoor temperature reading in Fahrenheit (°F) or Celsius (°C) •...
  • Page 3 • Wall mounting case (Mount in a sheltered location. Avoid direct rain and sunlight) SETTING UP: When one sensor is used First, insert the battery into the temperature sensor. (see “Install and replace batteries in the temperature sensor“). Immediately after and within 30 seconds, insert the batteries into Temperature Station (see “Install and replace batteries in the Temperature Station”).
  • Page 4 place, all segments of the LCD will light up briefly. Following time as 12:00 and the indoor temperature will be displayed. If they are not shown in LCD after 60 seconds, remove the batteries and wait for at least 60 seconds before reinserting them. The outdoor temperature from the first sensor (channel 1) should then be displayed on the Temperature Station.

  • Page 5: How To Install And Replace Batteries In The Temperature Station

    If the signal reception is not successful on the first frequency (915MHz) for 45 seconds, the frequency is changed to 920MHz and the learning is tried for another 45 seconds. If still not successful the reception is tried for 45 seconds on 910MHz.

  • Page 6: Battery Change

    Insert the batteries, observing the correct polarity (see marking). Replace the battery cover on the unit. Note: In the event of changing batteries in any of the units, all units need to be reset by following the setup procedures. This is because a random security code is assigned by the sensor at start-up and this code must be received and stored by the Temperature Station in the first few minutes of power supplying.

  • Page 7: Lcd Screen And Settings

    SET/CH key (Setting/Channel) • Press and hold for approximately 3 seconds to enter the Manual setting mode. • Press and release to toggle between different channel readings. MIN/MAX/+ key (Min/ Max temperature) • Used to toggle between the minimum and maximum recorded readings of indoor &...
  • Page 8 (“OFF” icon). On the other hand, the short blinking of the icon shows that a reception is being done at that time. For a better display clarity, the LCD screen is split into 3 sections, showing the information of time, indoor temperature and humidity, and outdoor data.

  • Page 9: Manual Time Setting

    MANUAL TIME SETTING User shall manually set the time of the Temperature Station by the following steps: The hour digit of the time display will be flashing. Press the “MIN/MAX/+” key to adjust the hour (press and hold to allow fast advance). Press “SET/ CH” key to confirm and go to the minute setting.

  • Page 10: Temperature Sensor

    Maximum icon RESETTING THE MINIMUM AND MAXIMUM READINGS: User may reset the minimum and maximum temperature / humidity data to the current value by the following steps: Press the “min/max/+” key once to display the minimum data. Press and hold the “min/max/+” key for about 3 seconds to reset all the minimum / maximum data to the current values in a single action.
  • Page 11 received about 2 minutes after setup (the signal reception icon does not appear), please check the following points: The distance of the Temperature Station or sensor should be at least 1.5 to 2 meters away from any interfering sources such as computer monitors or TV sets. Avoid positioning the Temperature Station onto or in the immediate proximity of metal window frames.

  • Page 12: Positioning The Temperature Sensor

    POSITIONING POSITIONING THE TEMPERATURE STATION: The Temperature Station comes attached with a table stand, which provides the option of table standing the unit in addition to wall mounting. Before wall mounting, please check that the outdoor temperature values can be received from the desired locations.

  • Page 13: Care And Maintenance

    using the bracket which doubles as a stand or wall mount base. To wall mount: Secure the bracket onto a desired wall using the screws and plastic anchors. Clip the temperature sensor onto the bracket. Note: The mounting surface can affect the transmission range. If, for instance, the unit is attached to a piece of metal, it may then either reduce or increase the transmitting range.

  • Page 14: Specifications

    • Do not submerge the units in water. Place units in locations that are adequately protected against moisture and rain. • Immediately remove all low powered batteries to avoid leakage and damage. Replace only with new batteries of the recommended type (alkaline). •...

  • Page 15: Warranty

    Warranty service can only be performed by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center.
  • Page 16 Crosse Technology, Ltd will pay ground return shipping charges to the owner of the product to a USA address only. Your La Crosse Technology, Ltd warranty covers all defects in material and workmanship with the following specified exceptions: (1) damage caused by accident, unreasonable use or neglect (including the lack of reasonable and necessary maintenance);...
  • Page 17 For warranty work, technical support, or information contact: La Crosse Technology, Ltd 2809 Losey Blvd. S. La Crosse, WI 54601 Phone: 608.782.1610 Fax: 608.796.1020 e-mail: support@lacrossetechnology.com (warranty work) sales@lacrossetechnology.com (information on other products) web: www.lacrossetechnology.com Question? Instructions? Please visit: www.lacrossetechnology.com/9124 All rights reserved.
