Indesit IDVA 735 Instruction Manual
Hide thumbs
Also See for IDVA 735:
- Instruction manual (80 pages) ,
- Instruction manual (16 pages) ,
- Instruction manual (21 pages)
Table of Contents
Advertisement
Quick Links
Instruction manual
EN
English, 1
IDVA 735
IDVA 735 S
!
This symbol reminds you to read this instruction manual.
!
Keep this manual at hand for immediate reference whenever
necessary. Always store this manual close to the tumble dryer and
remember to pass it on to any new owners when selling or tran-
sferring the appliance, so they may familiarise with the warnings
and suggestions herein contained.
!
Read these instructions carefully: the following pages contain
important information on installation and useful suggestions for
operating the appliance.
Contents
IInstallation, 2-3
Special programmes
Laundry, 10-11
Saving energy and respecting the environment
Troubleshooting, 14
Assistance and Guarantee, 15-16-17
TUMBLE DRYER
EN
1
Advertisement
Table of Contents
Related Manuals for Indesit IDVA 735
Summary of Contents for Indesit IDVA 735
-
Page 1: Table Of Contents
How to carry out a drying cycle, 6 Starting and selecting a programme Programmes and options, 7-8-9 Programme chart Special programmes IDVA 735 Options Opening the door IDVA 735 S Laundry, 10-11 Sorting laundry Care labels Special items Drying times Warnings and suggestions, 12 General safety... -
Page 2: Iinstallation
Installation Where to install the tumble dryer Wall ventilation hole 1. Leave an opening in the wall • Install the dryer far from gas to the left of the tumble dryer ranges, stoves, radiators or hobs, installation site. as flames may damage it. 2. -
Page 3: Electrical Connections
Electrical connections Levelling the tumble dryer Before plugging the appliance into the socket, check the The tumble dryer should be installed level in order to following: operate correctly. • Make sure your hands are dry. • The socket must have an earth connection. After installing the tumble •... -
Page 4: Description Of The Tumble Dryer
Description of the tumble dryer Front side Rear side Control panel Drum Air inlet Rating Plate Serial number and model Caution, high number Filter Connection for temperature ventilation hose Control panel Options On/Off buttons and Start/Pause button button indicator lights and indicator light Programme Clean filter... -
Page 5: Indicator Lights
ON/OFF/Reset button Pressing the button normally will cause the machine to switch on or off. If the button is pressed for 3 seconds while the dryer is in function, the machine will switch off and the running cycle will reset. Programme selection knob Allows for setting the programme: turn until the indicator points towards the desired programme (see Starting and selecting a programme). -
Page 6: How To Carry Out A Drying Cycle
How to carry out a drying cycle Starting and selecting a programme 1. Plug the dryer into the power supply socket. 2. Select the programme according to the type of laundry (see Laundry). 3. Open the door, ensure that the filter is clean and securely placed. 4. -
Page 7: Programme Chart
Programmes and options Programme chart Max. load Cycle Programme Compatible options (kg) duration Daily 1 Ready to wear Max. Pre anti-crease – Post anti-crease – Delay start 130’ 2 Cotton Cupboard dry Max. Pre anti-crease – Post anti-crease – Delay start 120’... - Page 8 Sport Intensive Programme This programme is designed for safely drying garments such as tracksuits and shorts bearing the symbol. It is ideal for clothes which do not need to be dried fully. We suggest turning garments inside out before drying them. ! The duration of this program will depend on the size of the load and the spin speed used in your washer.
-
Page 9: Options
Options The options allow for customising the selected programme according to one’s own needs. Delay start The start of some programmes (see Programmes and options) may be delayed up to 9 hours. Press the button repeatedly to enter the desired delay time. Before setting a delayed start, make sure that the filter is clean. Post Anti-Crease When this option is selected, the drum rotates garments at intervals after the COOL TUMBLE cycle has ended, in order to avoid creases forming on garments if they cannot be immediately removed at the end of the programme. -
Page 10: Laundry
Laundry Sorting laundry Care labels • Check the symbols on the care labels of the various gar- Always check the care labels, especially when placing ments to verify whether the garments can be safely tumble garments in the tumble dryer for the first time. Below are the most commonly used symbols: dried. -
Page 11: Special Items
Special items • Amount of laundry: single items and small loads may take longer to dry. Blankets and bedcovers: acrylic items (Acilian, Courtelle, • Drying: if items are to be ironed, they can be removed Orion, Dralon) must be dried with great care at low heat. from the dryer while still slightly damp. -
Page 12: Warnings And Suggestions
Warnings and suggestions • Do not dry garments that have been treated with chemical This appliance has been designed and built according to products. international safety standards. These warnings are given for safety reasons and must be followed carefully. • Do not tumble dry items that have been spotted or soaked with vegetable or cooking oils, this General safety constitutes a fire hazard. -
Page 13: Care And Maintenance
Care and maintenance Disconnecting the power supply Disconnect the dryer when not in use or during cleaning and maintenance operations. Cleaning the filter after each cycle The filter is a fundamental component of the dryer: its fun- ction is to collect lint and fluff that form during drying. Clean the filter once drying is completed, by rinsing it under running water or cleaning it with a vacuum cleaner. -
Page 14: Troubleshooting
Troubleshooting If you feel that the dryer is not working properly, consult the following troubleshooting suggestions before contacting the Technical Assistance Centre (see Assistance). Problem: Possible causes / Solutions: The dryer does not start. • The plug has not been inserted far enough into the socket to make contact. •... -
Page 15: Spare Parts
Assistance Spare parts Before contacting the Technical Assistance Centre: • Follow the troubleshooting guide to check whether pro- This dryer is a complex machine. Attempting to repair it per- blems can be solved personally (see Troubleshooting). sonally or having an unqualified person may put the safety or •... - Page 16 Excessive usage versus that expected of a domestically situated appliance 5 Year Parts Guarantee Indesit also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers.
- Page 17 224 224 (Republic of Ireland 0818 313 413) for telephone assistance, or, where necessary, to arrange for an engineer to call. After Sales Service No one is better placed to care for your Indesit appliance during the course of its working life than us – the manufacturer. Essential Contact Information...
- Page 20 09/2012 - Xerox Fabriano...
