Summary of Contents for QSC MHV-1090F
- Page 8 LF-4215-8F Cinema Loudspeaker User Manual Low–Frequency Loudspeaker TD-000295-00-A *TD-000295-00*...
-
Page 9: Important Safety Precautions And Explanation Of Symbols
Periodically, this warranty is updated. To obtain the most recent version of QSC’s warranty statement, please visit www.qscaudio.com. Contact us at 800-854-4079 or visit our website at www.qscaudio.com. The QSC limited warranty is valid for a period of three (3) years from date of purchase in the United States and many (but not all) other countries. - Page 10 Introduction The LF-4215-8F dual 15" (381 mm) low-frequency enclosure is designed specifically for large format cinema applications. Meeting cinema requirements for extended low-frequency response differentiates the LF-4215-8F from more conventional “rock-and-roll” woofer systems. The LF-4215-8F covers the frequency range from 35 Hertz to 1000 Hertz, depending upon the high-frequency system requirements. The LF-4215-8F is an 8 ohm version of the standard 4 ohm LF-4215 that is designed for safe and easy suspension via M10 fly points.
- Page 11 Ensure all attachment points are installed and correctly tightened in order to maintain enclosure’s rated strength. Additionally, air leaks resulting from missing hardware will degrade the loudspeaker’s performance. Use only QSC’s M10 forged shoulder eye bolts. Contact QSC Technical Services department for complete information.
-
Page 12: Normal Connection
Recommended Processing Subsonic filter below 30 Hz, >18 dB per octave, maximum recommended crossover frequency is 1000 Hz. QSC DSP configurations are available at www.qscaudio.com. Parameters for alternative processing hardware are available upon request. Nominal Coverage 135°... - Page 13 SPL and Impedance vs. Frequency SPL 2 Pi (half space) Impedance Frequency (Hertz) Dimensions 2 x 13" (2 x 330.2 mm) 2 x 3" (2 x 76.2 mm) 2 x 37" (2 x 939.8 mm) 40" (1016 mm) 31.5" 19" 2 x 1.5"...
-
