Managing Ethernet Services
4 When you are done, click Add (for a new bandwidth profile) or Modify (for an existing bandwidth
profile).
5 After you create a bandwidth profile, you can apply it to the UNI ports in Ethernet services. See
"Modifying an Ethernet Service" on page

Viewing Ethernet Services Information

You can display information about E-Line and E-LAN services from the All map or All table, or from the
Services view under Network Views.

Using the All Table and All Map View

To view information about the E-Line and E-LAN services known to Ridgeline, click a device group or
the All map or All table group under the Network Views folder, then click the Services tab. A table listing
the E-Line and E-LAN services in the group is displayed, as shown in
Figure 60: Services Table in Network Views
If you also have enabled the map view of a device group, you can select a row in the table and display
an overlay view highlighting all of the devices and UNI ports in the map where the selected E-Line or
E-LAN service is configured, as shown in
98
94.
Figure 60.
Figure 60.
Ridgeline Concepts and Solutions Guide
