Focusrite LiquidControl Manual

Please visit www.focusrite.com to download the latest version of the free LiquidControl™
software application, for Mac OS X or Windows XP. The application allows you to edit The
Liquid Channel™ remotely, plus load, save and archive the mic-pre and compressor replicas
and programs. The LiquidControl™ user guide is also available to download in PDF format.
Contents
Introduction............................................................................ 1
Important Safety Instructions............................................. 1
Power Connections.............................................................. 1
Liquid Channel™ Architecture ......................................... 2
Rear Panel Connections ...................................................... 3
Front Panel Controls............................................................ 3
Mic-Pre and A/D.................................................................... 4
Session Saver .......................................................................... 4
Clock Select and Synchronisation ..................................... 5
Main LCD and Controls ...................................................... 5
Harmonics ............................................................................... 6
Compressor Settings............................................................ 6
3-Band EQ ............................................................................... 7
Comp & EQ Settings ............................................................ 8
Data Select .............................................................................. 8
Linking Multiple Units.........................................................10
Connections and Applications .........................................11
Frequently Asked Questions............................................16
Specifications ........................................................................21
Disclaimer .............................................................................22
Accuracy ................................................................................22
Copyright ..............................................................................22
Warranty ...............................................................................22

Introduction

Thank you for purchasing The Liquid Channel™
brought to you by the Focusrite team - Ian, Trevor,
Peter, Martin, Tom, Mick A'C, Phil, Chris G, Micky,
Pauline, Melissa, Chris W, Rob J Snr, Simon J, Vernon,
Giles, Rob J Jnr, Mick G, Tim, Dave, Nick, Paul, Peter
and Simon.
The chaps at Focusrite are a jolly hard working bunch
and take a great deal of pride in designing, building and
delivering products which are considered the best
audio units around; we hope your new Focusrite unit
lives up to that reputation and that you enjoy many
years of productive recording. If you would like to tell
us about your recording experiences then email us at:
sales@focusrite.com
The Focusrite Team
LiquidControl™ Software
1

Important Safety Instructions

Please read all of these instructions and save them for future
reference. Follow all warnings and instructions marked on
the unit.
Do not obstruct air vents in the rear panel. Do not
•
insert objects through any apertures. Ensure adequate
ventilation at all times.
Do not use a damaged or frayed power cord.
•
Unplug the unit before cleaning. Clean with a damp
•
cloth only. Do not spill liquid on the unit.
Unplug the unit and refer servicing to qualified service
•
personnel under the following conditions: if the power
cord or plug is damaged; if liquid has entered the unit; if
the unit has been dropped or the case damaged; if the
unit does not operate normally or exhibits a distinct
change in performance. Adjust only those controls that
are covered by the operating instructions.
Do not defeat the safety purpose of the polarised or
•
grounding type plug. A polarised plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wider
blade or the third prong are provided for your safety.
When the plug provided does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
This unit is capable of operating over a range of mains
voltages as marked on the rear panel. Ensure correct mains
voltage setting and correct fuse before connecting mains
supply. Do not change mains voltage settings while mains
supply is connected. To avoid the risk of fire, replace the
mains fuse only with the correct value fuse, as marked on
the rear panel. The internal power supply unit contains no
user serviceable parts. Refer all servicing to a qualified
service engineer, through the appropriate Focusrite dealer.
WARNING:
THIS UNIT MUST BE EARTHED BY THE
POWER CORD. UNDER NO
CIRCUMSTANCES SHOULD THE MAINS
EARTH BE DISCONNECTED FROM THE
MAINS LEAD.

Power Connections

There is an IEC mains lead supplied with the unit, which
should have the correct moulded plug for your country. The
wiring colour code used is:
For units shipped to the USA, Canada, Taiwan and Japan:
Live Black; Neutral White; Earth Green
For units shipped to any other country:
Live Brown; Neutral Blue; Earth Green & Yellow
ENGLISH
