UT2000_3000 Series Digital Storage Oscilloscopes
User Manual and Installation Notes
. All right reserved 2007
__________________________________________________________________________________________
User Manual for UT2000_3000 Series Computer Testing & Control Software
Document No. SYSC-0-070606
June 2007
1
UNI-T
Advertisement
Table of Contents
Related Manuals for UNI-T UT2000 series
Summary of Contents for UNI-T UT2000 series
- Page 1 UNI-T Uni-Trend Group Limited UNI-T UT2000_3000 Series Digital Storage Oscilloscopes User Manual and Installation Notes Document No. SYSC-0-070606 June 2007 . All right reserved 2007 __________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 2 Information contained in this manual supercedes all information in previously published versions. The Company reserves the right to change specifications and prices. Note: UNI-T is the registered trademark of Uni-Trend Group Limited. . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 3 UNI-T ® Uni-Trend Group Limited UT2000_3000 Series Digital Storage Oscilloscopes Introduction The UT2000_3000 Series Digital Storage Oscilloscope software is written for UT2000_3000 Series digital storage oscilloscopes. With this software you can carry out communication between a computer and an oscilloscope through serial or USB, and in turn perform remote control.
-
Page 4: Table Of Contents
UNI-T Uni-Trend Group Limited Chapter One: Software Structure Basics ………………………………..... 5 Notes on operation interface ……………………………………………....5 Notes on menu ……………………………………………………………....5 Notes on front panel …………..…………………………………………....7 Chapter Two: Operation Guide ……..………………………………....9 USB interface controls ………………..…………………………………..... 9 Serial interface controls ……..……………………………………………..... 11 Chapter Three: Installation guide for UT2000_3000 Series Computer Testing &... -
Page 5: Chapter One: Software Structure Basics
UNI-T ® Uni-Trend Group Limited Chapter One: Software Structure Basics Notes on operation interface Notes on menu: Document: Load waveform, save waveform, load intersection, print preview, print preview, print, exit. Function: Mathematics function: User can select the calculation method of the channels or window function. - Page 6 UNI-T ® Uni-Trend Group Limited Remote control: Control of the serial interface can be performed from a remote point. Data form: How the voltage changes with time . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 7 UNI-T ® Uni-Trend Group Limited Parameter testing: The current parameters are displayed Refresh waveform: single refresh; waveform time interval setup Help: Content; About Notes on front panel Channel status: Current status of the oscilloscope is displayed. When transmitting data, this status bar displays the current status. When the oscilloscope’s status changes, so will this status bar, but you cannot use this bar to control the current status of the oscilloscope.
- Page 8 UNI-T ® Uni-Trend Group Limited Sampling method; Random; Real-time; SCAN Interpolation (Yes, NO) Current activated channel (MATH; CH1; CH2) Channel selection: CH1; CH2; MATH Deviation factor adjustment: Vertical; Horizontal Range adjustment: Voltage range; Time base range Real-time Control: Equipment selection (Serial, USB); ON/OFF (when the indicator lights up the function is ON, when the indicator lights off the function is OFF);...
-
Page 9: Chapter Two: Operation Guide
UNI-T ® Uni-Trend Group Limited Chapter Two: Operation Guide After reading Chapter One you may now have a basic understanding of how this system works. The following are more specific instructions for using the software. We recommend you to read this chapter carefully to familiarize with application. - Page 10 UNI-T ® Uni-Trend Group Limited Click the [Data Interface] knob to pop up the following screen. Click Series on the above screen so the oscilloscope can transmit continuously as indicated below. You can now control the oscilloscope. When operation is complete press [CLOSE] to close this screen.
- Page 11 UNI-T ® Uni-Trend Group Limited Serial Interface Controls Follow the following steps: 1. Select Serial with the equipment selection knob of the real-time control panel. The following screen appears: Press OK. Click the [Equipment ON/OFF] knob to turn it on. When the indicator lights up the function is ON.
- Page 12 UNI-T ® Uni-Trend Group Limited Note: This process may take several seconds. 4. Click the [Function] knob on the menu bar than select remote control. The following screen will appear. You can now control the oscilloscope. Important: The above screen will not display waveform. Operation of this screen will be indicated in the oscilloscope.
-
Page 13: Chapter Three: Installation Guide For Ut2000_3000 Series Computer Testing & Control Software
UNI-T ® Uni-Trend Group Limited Chapter Three: Installation guide for UT2000_3000 Series Computer Testing & Control Software 1. Hardware There are one USB device communication port and one RS-232 communication port for computer connection on the rear panel of the UT2000_3000 Series digital storage oscilloscope. - Page 14 UNI-T ® Uni-Trend Group Limited Set up as follows: Step 1: Select [Yes, this time only] and click [Next] once. Step 2: In the “Found New hardware Wizard” wizard select [Install from a list or specific location (Advanced)], then click [Next].
- Page 15 UNI-T ® Uni-Trend Group Limited The following screen will appear. Select [Browse]. In the popped up [Browse Folder] box, select the DSO directory in the directory where you intend to install UT2000_3000, then click [Next]. (As shown below). Step 3: Enter the search-in-progress waiting screen.
- Page 16 UNI-T ® Uni-Trend Group Limited The dialogue box below will appear but it will not affect the software or your computer. Click [Continue Anyway]. The system will automatically jump to the [System Restore Setup] screen and the document is copied.
- Page 17 UNI-T ® Uni-Trend Group Limited The following screen will appear while the document is being copied. Click the left arrow of [Browse…] to select the directory you have defined in Step 2. If you have not defined any, find one in [Browse…].
- Page 18 UNI-T ® Uni-Trend Group Limited Click [OK] again to confirm. Document copy will continue. Click [Finish] to complete installation of the driver. . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 19 UNI-T ® Uni-Trend Group Limited At the right bottom corner of the screen, you will see: Display of the [Device Manager] is as follows: Note: If no [Found New Hardware] wizard pops up on your computer screen when the computer is properly connected to the oscilloscope and the latter is powered on normally, right click [My Computer] and select [Attribute].
- Page 20 UNI-T ® Uni-Trend Group Limited Right click your mouse and select [Update Driver Application] to pop up the [Found New Hardware] wizard. Follow step 1 to install the driver. . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 21 You can install from the installation CD-Rom supplied with th e oscilloscope or ownload the computer software directly from the UNI-T website. Step 1: Find the suitable operating system “UT2000_3000 VI (For WinXP) or UT2000_3000 VI (For Win2000)” folder in the supplied CD-Rom or unzipped path.
- Page 22 UNI-T ® Uni-Trend Group Limited Note: The Ultra scope for UT2000_3000 Computer Testing & Control Software installation kit downloaded online must first be unzipped. This software supports Windows 2000 and Windows XP. Step 2: Begin installation. The software installation wizard pops up as shown below .
- Page 23 UNI-T ® Uni-Trend Group Limited Step 3: Confirm that you wish to install this software. Click the [Next] button. Step 4: Read the installation licensing agreement carefully. Select “I agree with the terms and conditions of the licensing agreement”, then click [Next].
- Page 24 UNI-T ® Uni-Trend Group Limited Step 5: Enter your user name and company name, then click [Next] once. Step 6: Enter the installation path in the installation path field or click [Change ( )H…..] to select an alternative installation path. Then click [Next] once.
- Page 25 UNI-T ® Uni-Trend Group Limited Step 7: Depending on your specific requirement, select [Quick installation for the current user only] or [Make quick installation applicable to all users], then click [Next] once. . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 26 UNI-T ® Uni-Trend Group Limited Step 8: After confirming all information is correct, click [Next] once. Step 9: The successful installation screen appears. . All right reserved 2007 ___________________________________________________________________________________________ User Manual for UT2000_3000 Series Computer Testing & Control Software...
- Page 27 UNI-T ® Uni-Trend Group Limited Step 10: When installation is complete as shown above, click [Finish (F)] once on the screen. The software has been installed in your host. If you wish to change any setup, simply click [Back (B)] once during any stage of the wizard.
-
Page 28: Chapter Four: System Prompts And Troubleshooting
UNI-T ® Uni-Trend Group Limited Chapter Four: System Prompts and Troubleshooting System Prompts Time out prompt: Check the serial configuration or check whether the equipment is properly connected. Time out prompt: Check the USB configuration or check whether the equipment is properly connected. -
Page 29: Thank You
UNI-T Uni-Trend Group Limited Copyright Statement Uni-Trend Group Limited owns copyright of this User Manual. Unless with prior written authorization from the company, no individual or firm may release, publish or change any contents contained in any way whatsoever. Thank you.
