Floor clearances, DKC and three DKUs

Figure 7 Floor clearances, DKC and three DKUs
Table 9 Overall floor clearance by floor load rating for a DKC and three DKUs
Floor load
rating
(kg/m2)
500
450
400
350
300
NOTE:
The clearance diagram shows a typical configuration. Other configurations are possible. Consult your HP
representative for help with equipment arrangements that differ from the one shown.
If If C=20 cm (7.9
C=0A+B= in)A+B=
160
230
320
460
660
If C=40 cm
(15.8 in)A+B=
120 80
180 140
260 210
380 320
570 490
XP12000 Disk Array Site Preparation Guide
If C=60 cm If C=100 cm (39.4
(23.6 in)A+B= in)A+B=
50
100
170
270
420
0
50
100
190
320
35
