Specifications

Product type
Video system
Display method
LCD panel
Projection lamp
Contrast ratio
Video input signal
S-video input signal
Horizontal resolution
Audio output
Computer RGB input signal
Pixel clock
Vertical frequency
Horizontal frequency
Computer control signal
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Operating temperature
Storage temperature
I/R carrier frequency
Laser pointer of remote control
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
This SHARP projector uses LCD (Liquid Crystal Display) panels. These
very sophisticated panels contain 786,432 pixels (
Film Transistors). As with any high technology electronic equipment
such as large screen TVs, video systems and video cameras, there
are certain acceptable tolerances that the equipment must conform
to.
55
LCD Projector
Model PG-C30XE
PAL/SECAM/NTSC 3.58/NTSC 4.43/DTV 480P/DTV 720P/DTV 1080I
LCD panel 3, RGB optical shutter method
Panel size: 22.9 mm (0.9 ) (13.9 [H]
Display method: Translucent TN liquid crystal panel
Drive method: TFT (Thin Film Transistor) Active Matrix panel
No. of dots: 786,432 dots (1,024 [H]
Lens 1–1.3 zoom lens, F1.7–2.0, f
DC 200 W lamp
250:1
RCA Connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω terminated
RCA Connector: AUDIO, 0.5 Vrms more than 22 kΩ (stereo)
4-pin Mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
560 TV lines (video input), 750 TV lines (DTV 720P input, Dot by Dot)
2 W (monaural)
15- D-
PIN MINI SUB CONNECTOR
RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive,
75 Ω terminated
S M : AUDIO, 0.5 Vrms, more than 22 kΩ (stereo)
TEREO INIJACK
H .
ORIZONTAL SYNC SIGNAL
V . : Same as above
ERTICAL SYNC SIGNAL
12–230 MHz
43–200 Hz
15–126 kHz
9-pin Mini DIN female connector (RS-232C Input Port)
8 cm (3 3 ⁄ ) round
32
AC 110–120/220–240 V
3.0 A/1.5 A
50/60 Hz
300 W
5°C to 40°C
20°C to 60°C
Cabinet Plastic
38 kHz
Wave length: 650 nm / Max. output: 1 mW / Class II Laser Product
229 121 310 mm (W
243.5 134 358.4 mm (W
4.8 kg
Remote control, Two AA size batteries, Power cord (1.8 m), Computer RGB cable (3 m),
Computer audio cable (3 m), PS/2 mouse control cable (1 m), USB mouse control cable
(1.5 m), DIN-D-sub RS-232C cable (15 cm), Remote mouse receiver, Extra air filter, Lens
cap (attached), CD-ROM, LCD projector operation manual, LCD projector quick
references, Sharp Advanced Presentation Software operation manual
Lamp unit (Lamp/cage module) (BQC-PGC30XE/1), Remote control (RRMCG1584CESA),
AA size batteries, Power cord, Computer RGB cable (QCNW-5304CEZZ), Computer audio
cable (QCNW-4870CEZZ), PS/2 mouse control cable (QCNW-5113CEZZ), USB mouse
control cable (QCNW-5680CEZZ), DIN-D-sub RS-232C cable (QCNW-5288CEZZ), Remote
mouse receiver (RUNTK0673CEZZ), Air filter (PFILD0076CEZZ), Lens cap
(GCOVH1307CESB), CD-ROM (UDSKA0021CEN1), LCD projector operation manual
(TINS-7046CEZZ), LCD projector quick references (TINS-7048CEZZ, TINS-7152CEZZ,
TINS-7153CEZZ), Sharp Advanced Presentation Software operation manual (TINS-
7047CEZZ)
RGB) TFTs (Thin
Specifications are subject to change without notice.
18.5 [W] mm)
768 [V])
33–43 mm
(INPUT 1, 2):
: TTL level (positive/negative) or composite sync (Apple only)
H D) (main body only)
H D) (including adjustment feet and projecting parts)
This unit has some inactive TFTs within acceptable tolerances which
may result in illuminated or inactive dots on the picture screen. This
will not affect the picture quality or the life expectancy of the unit.
