Air Filter Maintenance

• This projector is equipped with four air filters to ensure the optimal operating condition of the projector.
• The air filters should be cleaned every 100 hours of use. Clean the filters more often when the projector is used
in a dusty or smoky location.
• Have your nearest Sharp Authorised LCD Projector Dealer or Service Centre exchange the filter (PFILD0076CEZZ)
when it is no longer possible to clean it.
Bottom View
Air filters
(not removable)
Cleaning and replacing the bottom air filter
1 Unplug the power
cord.
4
Clean the air filter.
Clean the dust off the air filter
and cover with a vacuum
cleaner extension hose.
• Be sure the filter cover is securely installed. The power will not turn on unless it is correctly installed.
Cleaning the bottom air filters (not removable)
If dust or dirt has collected inside the air filters, clean the filters with a vacuum cleaner extension hose.
Air filter
2 Remove the bottom
filter cover.
Turn over the projector. Press the
tab and lift open the filter cover
in the direction of the arrow.
5
Replace the air filter.
Place the air filter underneath
the tabs on the filter frame.
3 Remove the air filter.
Grasp the air filter between your
fingers and lift it out of the filter
cover.
Tab
6 Replace the filter
cover.
Insert the tab on the end of the
filter cover into the filter cover
opening and press the filter
cover into position.
Tab
46
