Air Cleaner; Fuel System - Cub Cadet LT 2180 Parts Manual

11
10
9
12
3
1
13
8
10
2
3
REF. PART
NO. NUMBER DESCRIPTION
1 BS-691050 Line, Fuel
2 BS-691035 Filter, Fuel
3 BS-806137 Washer, Sealing
4 BS-807084 Screw, Fuel Pump
5 BS-808656 Pump, Fuel
6 BS-691038 Clamp, Hose
7 BS-806660 Screw, Fuel Pump Bracket
8 BS-691559 Bracket, Fuel Pump
9 BS-393815 Hose, Vacuum
10 BS-692094 Solenoid, Fuel
11 BS-806497 Washer

AIR CLEANER

4
5
12
2
6
7

FUEL SYSTEM

5
4
7
-25-
REF. PART
NO. NUMBER DESCRIPTION
1 BS-691561 Base, Air Cleaner
2 BS-692081 Gasket, Air Cleaner
3 BS-394018 Filter, Air Cleaner Cartridge
4 BS-691985 Knob, Air Cleaner
5 BS-692079 Retainer, Air Filter
6 BS-692539 Screw, Cleaner Mounting Strap
7 BS-690872 Screw, Cleaner Mounting Strap
8 BS-692153 Strap, Air Cleaner Mounting
9 BS-691577 Shield, Carburetor
10 BS-272490 Pre Cleaner, Filter
11 BS-692097 Cover, Air Cleaner
12 BS-807084 Screw, Air Cleaner Base
13 BS-690743 Duct, Air
9
8
1
11
QTY.
1
1
1
2
1
4
2
1
1
1
2
QTY.
1
1
1
1
1
1
1
1
1
1
1
2
1
6
6
