Xerox DC230LP Quick Install

Installation Requirements:
To install the DC230LP in a DHCP environment,
exclude the addresses assigned to the
DC230LP at the DHCP server.
Before Installation:
Record the following information for use during
setup at the DC230LP:
TCP/IP Address:________________________
Gateway Address: ______________________
Subnet Mask: __________________________
Broadcast Address: _____________________
Host Name:____________________________
This installation procedure assumes that you
know how to navigate through the menu system
on the DC230LP Control Panel. Refer to the
quick reference card, Using the Menu System,
(701P96834) for assistance.
1.
Connect the DC230LP to your network
outlet or cable.
For assistance, contact your local Xerox Customer Support Center:
USA: 1-800-821-2797 Canada: 1-800-939-3769
DC230LP Windows NT
2.
Access the System Administration menus:
a)
Press [Online] to take the printer off
Printer Off Line
line.
b)
Press [Menu].
c)
Press [ ], then press [ ] or [ ] until
>
System
Administration
d)
Press [ ].
e)
Use the [ ] and [
[2222].
Note: 2222 is the factory default password and
may be changed to suit your needs. Refer to the
DC230LP System Administration Guide,
Network Installation and Troubleshooting .
f)
Press [Enter].
3.
Access the TCP/IP menus:
a)
Press [ ].
b)
Press [ ] until
displays.
c)
Press [ ].
Page 1 of 4
® 4.0 TCP/IP Quick Install
displays.
>
Main Menu
displays.
displays.
>
Enter Password
displays.
] keys to enter
>
System Admin
displays.
>
Port Setup
displays.
>
Network Setup
>
TCP/IP
displays.
IP Address
d)
Press [ ].
(current entry)
4.
IP Address Setup (skip this step if using
RARP):
IP Address
a)
Press [ ].
(current entry)
Note: Use zeros to supplement each address
segment if fewer than 3 digits are used; e.g.,
13.252.25.08 = 013.252.025.008.
b)
Use the [ ] or [ ] key to enter the
first digit of the IP Address.
c)
Press [ ] to move to the next digit.
Repeat this procedure to enter the
entire IP Address.
d)
Press [Enter]. **SAVED** displays
momentarily, followed by
>
IP Address
.
(your entry)
5.
RARP Setup:
Note: If you used a static IP Address, leave the
RARP setting at Disabled .
a)
To change the RARP setting, press
[ ] until the current setting displays
>
RARP
.
(current entry)
>
displays.
=
displays.
*
Over
