Jenn-Air JS48PPDUDB01 Parts List page 18

FREEZER DOOR PARTS
For Model: JS48PPDUDB01
(Stainless Steel)
Illus. Part
No. No. DESCRIPTION
1 W10193495 Freezer Door
(Includes #7)
2 W10153450 Stud, Handle
3 2302879 Hinge, Bottom
4 489282 Screw
5 2266854 Hinge, Top
6 2316804 Spacer−Door,
Top & Bottom
7 2222810 Door Gasket,
Magnetic
8 Handle, Door
12859107 Stainless Steel
9 Spacer, Door−Skin
(Handle Side)
2309060 For Stainless
Steel Model
10 Skin, Door
W10144964 Stainless Steel
11 Screw
8281250 Stainless Steel
12 2005433 Spacer, Door−Skin
(Top)
13 488568 Screw
14 2257386 Spacer, Door−Skin
(Bottom)
15 W10142296 Spacer, Door−Skin
(Hinge Side)
16 308544 Screw, Handle
17 Filler, Door
W10159586 Top
W10159583 Bottom
19 2222777 Bin, Door (3)
20 W10127710 Plate, Door Handle
18
W10242818
