Control Panel - Generac Power Systems 004945-1 Owner's Manual

UTILITY
METER
SOCKET
EXISTING WIRES TO
PANELBOARD
(SEE ABOVE NOTE)
NEUTRAL BAR
DISCONNECT
BONDING
CONNECTION
IN PANELBOARD
GROUND BAR
Transfer Switch Interconnections - Drawing No. 0F0017-A
INSULATED SPLICING
CONNECTOR OR
(NEW WIRES CAN BE
PULLED FROM ATS &
PANELBOARD).
PANELBOARD
Section 5 — Electrical Data
ATS "HS" Type Transfer Switch
IF ATS IS USED AS SERVICE ENTRANCE
DEVICE A BONDING JUMPER WILL NEED
TO BE INSTALLED SIZED TO MEET
NATIONAL & LOCAL CODES.
SERVICE DISCONNECT
ATS
E2
T2
NOTE: INSTALLATION TO BE DONE BY A
E1
22
33
11
44
E1 E2
N1
N2
T1 * *-WIRES T1 & T2 NOT
T2 *
23
194
AC GENERATOR

CONTROL PANEL

LICENSED ELECTRICIAN AND MUST
MEET ALL NATIONAL, STATE AND
LOCAL ELECTRICAL CODES.
FROM
ALTERNATOR
STATOR
USED ON AIR COOLED UNITS
AND SOME LIQUID COOLED UNITS
RETROFIT
9
