• The downdraft vent is shipped with the
Venting
Options
• The blower outlet is sized for 3-1/2" x 10"
Side to side adjustments:
The entire blower mounting plate can be
adjusted 3-1/2" to the left or right. This will
help to align vent discharge to house
ductwork.
30 Rotation
For even more flexibility, the entire blower
can be rotated up to 30 towards the left or
30 towards to right.
Discharge direction
The blower assembly may be removed and
turned 90 for a left or right side discharge.
• A left or right 90 direction adjustment
• Flatten the shipping box to use as a pad.
• Lay the vent on its back onto the pad.
To change to a left or right discharge:
• Remove 4 nuts holding the blower to the
• Remove and turn the blower to the right or
• Reinstall the 4 nuts.
To locate the ductwork holes in the cabinet
floor or side walls:
• Temporarily, place vent into the countertop
• Push the vent all the way to the back of the
• If you are transitioning to 6" round, place
6
discharge outlet pointing straight down and
can be changed to the left or right side.
and can be transitioned to 6" round.
should be performed before dropping into
the countertop opening.
mounting plate. See illustration. One nut is
just inside the blower discharge.
left.
opening.
opening.
transition piece over the discharge outlet.
– Mark the location and remove the
assembly.
– Cut holes and install ductwork
connections.
Ductwork
G a s Downdraf t Cooktop
Loosen Screws to
Adjust Blower
Left to Right
Nut Location
Inside the Blower
Discharge
30" Rotation Left or Right
Discharge Down
(as Supplied)
Discharge Left
Order JXRB57 for installation of the blower and motor
below the floor.
Order JXBC57 for installation of the blower and motor
outdoors.
Loosen Screws to Rotate
30 to Left or 30 to Right
Discharge Right
