P8H61-M PLUS2 specifications summary

CPU
Chipset
Memory
Expansion slots
Storage
LAN
Audio
USB
ASUS unique
features
LGA1155 socket for Intel
i5 / Core™ i3 processors
Supports 32nm CPU
Supports Enhanced Intel
* Refer to www.asus.com for Intel
Intel H61 Express Chipset
®
2 x DIMM, max. 16GB*, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
Supports Intel Extreme Memory Profile (XMP)
®
* The maximum 16GB memory capacity can be supported with
8GB or above DIMMs. ASUS will update the memory QVL once
the DIMMs are available in the market.
** Refer to www.asus.com for the latest Memory QVL (Qualified
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows 32-bit operating system may only recognize less
®
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows
1 x PCI Express 2.0 x16 slot
1 x PCI Express 2.0 x1 slot
1 x PCI slot
Intel H61 Express Chipset:
®
- 4 x Serial ATA 3.0 Gb/s connectors
Realtek 8111E PCIe Gigabit LAN controller
®
Realtek ALC887 8-channel* High Definition Audio CODEC
®
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
Intel H61 Express Chipset:
®
- 10 x USB 2.0/1.1 ports (4 ports at the mid-board, 6 ports at
the back panel)
ASUS ESD Guards
GPU Boost
ASUS Anti-Surge Protection
ASUS Q-Fan 2
ASUS EFI BIOS
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
(continued on the next page)
Second Generation Core™ i7 / Core™
®
SpeedStep Technology (EIST)
®
CPU support list.
®
32-bit operating system.
®
ix
