EarthQuake TNT-T46 Specifications

TNT - T46 Specifications
FEATURES
Low mass poly injection cone
body that delivers precision
sound quality
High flow ventilation stamped
steel basket design
Large butyl rubber surround
for more accurate bass
NOMEX / ROMEX spider
assembly for linear cone
travel and durability
Shallow mount design for
American or foreign cars and
trucks
over 1" (30mm) mylar super
tweeter both of which deliver
a n e x c e p t i o n a l l y h i g h
frequency for all ranges of
music.
Sound That Will Move You
73mm x 121mm - 2-7/8" x 4-3/4"
98mm x 154mm - 3-7/8" x 6-1/16"
SPECIFICATIONS
Model
Diameter (inches)
Diameter (mm)
Description
Impedance
Frequency Response
Sensitivity
Power Handling
INSTALLATION
Grilles
Mounting Diameter (inches)
Mounting Diameter (mm)
Mounting Depth (inches)
Mounting Depth (mm)
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
85mm - 3-3/8"
T46
4" x 6"
98mm x 154mm
2-Way
4-Ohm
100Hz - 20kHz
87dB
300 Watts
Yes
2-7/8" x 4-3/4"
73mm x 121mm
2"
50mm
www.earthquakesound.com
