H2/3

BROWN

This wire MUST be connected to the vehicle's brake light wire. This is the wire

that shows (+) 12V when the brake pedal is depressed. The remote start will be

disabled or shut down any time the brake pedal is depressed.

H2/4

GRAY

This wire MUST be connected to a hoodpin switch. This input will disable or shut

down the remote start when the hood is opened. .

H2/5

BLUE/WHITE

This wire supplies a 200mA output as soon as the module begins the remote

start process. The H2/5 Blue/White wire can also be used to activate the

defogger trigger (latched/pulsed), 10-seconds after the remote start engages.

(See the Feature Descriptions section in this guide for details about programming

this output.)

(+) BRAKE SWITCH INPUT, ZONE 1

(-) HOOD PIN SWITCH INPUT, ZONE 1

(-) STATUS OUTPUT
