Lightolier Calculite 7026AO Specification

Page 1 of 2
Catalog Number
7026AO Matte white housing with specular clear reflector
Features
1. Reflector: 16 ga. Specular clear Alzak
and lamp image .
2. Housing: One piece spun 16 ga. aluminum with returned bottom edge to
seat reflector, no visable hardware.Matte white baked enamel finish.
3. Retaining Springs: Coil steel springs secure reflector to housing.
4. Heat Insulltor: Fiberglass bulk insulation.
5. Socket: Medium base porcelain, nickel plated screw shell.
Options & Accessories
Stem Kit: 7249 Matte white
Permits surface units to be stem mounted. Supplied with 1/2" dia.
and 5 1/2" dia. canopy. 37 5/8" O.A. Length. Stem can be cut to
length at the job site. Self aligning swivel provides up to 41° verti-
cal adjustment.
Other reflector and housing finishes consult factory.
Electrical
Requires 75°C Supply wires. No.18 SF-1 leads to porcelain socket.
Labels
UL Listed for damp locations, I.B.E.W.
Calculite ® Incandescent Surface Cylinder
® aluminum. 50° visual cut-off to lamp
Lamp
PAR38,150W (cool beam)
PAR38, 250W (T.H.)
R40, 300W
BR40, 300W
Alzak ® is a registered trademark of ALCOA.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
7026AO
9" Aperture BR40 / R40 / PAR38
Type:
www.lightolier.com
