SJ300/L300P SERIES
SJ-LW
INSTRUCTION MANUAL
Thank you for purchase of "HITACHI INVERTER". This manual
explains about treatment of "SJ-LW (LonWorks Option)". By reading this
manual and an instruction manual of inverter use practically for
installation, maintenance, and inspection. After reading this manual,
keep it handy for future reference.
Make sure to reach this manual to the end user.
Chapter1
Introduction
Chapter2
Installation method of printed board
Chapter3 Wiring, Connecting
Chapter4
Setting
Chapter5 LonWorks Communication Function
Chapter6
Control from LonWorks
Chapter7 Countermeasure for abnormality
Appendix1 Parameter Object Lists
Appendix2 Trip monitor data address
After reading this manual, keep it at handy for future reference.
Hitachi Inverter
(LonWorks Option)
Table of Contents
1
5
6
7
8
17
21
23
32
NB6 23 X

Advertisement

loading

Related Manuals for Hitachi SJ-LW

Summary of Contents for Hitachi SJ-LW

  • Page 1 SJ-LW (LonWorks Option) INSTRUCTION MANUAL Thank you for purchase of “HITACHI INVERTER”. This manual explains about treatment of “SJ-LW (LonWorks Option)”. By reading this manual and an instruction manual of inverter use practically for installation, maintenance, and inspection. After reading this manual, keep it handy for future reference.
  • Page 2 When Connecting SJ-LW to LON network,XIF file is necessary as external interface file. XIF file is possible to download from the web site below. http://www.hitachi-ds.com General information regarding LonWorks and how to get LonWorks specifications , refer to the web site below.
  • Page 3 SAFTY PRECAUTIONS SAFTY PRECAUTIONS Carefully read this manual and all of the warning labels attached to the inverter before installing, operating, maintaining, inspecting, it. Safety precautions are classified into “Warning” and “Caution” in this manual. Indicates a potentially hazardous situation which, if not avoided, can result in serious WARNING injury or death.
  • Page 4 SAFTY PRECAUTIONS WARNING Wiring: Wiring work shall be carried out by electrical experts. Otherwise, there is a danger of electric shock, fire and/or damage of product. Implement wiring after checking that the power supply is off. Otherwise, there is a danger of electric shock and/or fire. Operating: Be sure not to touch the surface or the terminal of option board while energizing.

  • Page 5: Chapter1 Introduction

    1.2.1 REQUIRE WHILE INQUIRING If inquiry of breakage, question, damage etc. is needed, please tell the following information to the supplier you ordered or the nearest Hitachi Distributor. (1) Type(SJ-LW) (2) Manufacturing number (Item of label, that labeled surface of printed board. SJ-LW XXX )

  • Page 6: Appearance And Names Of Parts

    CHAPTER 1 INTRODUCTION 1.3 Outline of product SJ-LW is LonWorks communication board for SJ300/L300P series inverter. SJ300/L300P series inverter can get to connect another devices via LonWorks when install SJ-LW. SJ-LW is possible to connect for all models of SJ300/L300P series. The SJ-LW option card communicates according to the LonWorks Protocol Standard ANSI/EIA 709.1-A-1999.
  • Page 7 CHAPTER 1 INTRODUCTION 1.5 LonWorks Supported Version SJ-LW can use following Manufacturing number (MFG No) of SJ300/L300P series. After Manufacturing number : XX8KXXXXXXXXXXXX SJ300-0.4-55kW / L300P-11-75kW supported XXEMXXXXXXXXXXXX SJ300-75-132kW / L300P-90-132kW supported (Note) Manufacturing number is written in specifications label on main body of SJ300/L300Pseries. Refer to figure 1-2, figure 1-3.
  • Page 8 CHAPTER 1 INTRODUCTION 1.7 Production specification Bacicaly, the environmental specification of the SJ-LW is in accordance with SJ300/L300P series inverter. Please refer the instruction manual of SJ300/L300P series. But only application temperature of SJ-LW is different. Please note. application temperature : 0 to 50 degree...

  • Page 9: Chapter2 Installation Method Of Printed Board

    CHAPTER 2 INSTALLATION METHOD OF PRINTED BOARD 2.1 Mounting method of option board Figure 2-1 describes how to mount the option board to the option port 1 or 2. There are four holes on the option board, match the two of them with the screw holes on the option port 1 or 2. and mount the other two holes with the guide posts which are located on the option port 1 and 2.
  • Page 10 CHAPTER 3 WIREING,CONNECTING 3.1 Connection for LonWorks connector The SJ-LW connects to the LonWorks network with a 3-pin connector. For the pin layout, refer to Figure 3-1. Maker Type Phoenix contact co, Ltd. MC 1.5/3-ST-3.81 Pin No. Dimension 7.62 Dimension in mm 15.5 12.22 Signal mark...

  • Page 11: Chapter4 Setting

    4.1 Setting of controlling frequency and start/stop commands The Hitachi SJ300/L300P inverters can be configured to take reference set-points and commands from several different locations. Refer to the table below for information of how to configure the inverter so that the Lonworks controls frequency and the commands.

  • Page 12: Chapter5 Lonworks Communication Function

    CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.1 Operating the drive via LonMark profile A LonMark profile defines a functional profile for a node communicating with others. A LonMark profile specifies which SNVT’s and SCPT’s to be used and also a semantic meaning about the information being communicated.
  • Page 13 Lon Network, not controled. No message containing a WRITE_DEMAND_CODE (0x02) in the FrameType field of the Hitachi high-speed serial protocol will be communicated to the inverter from the option card. All messages with other FrameType codes will be sent to the inverter.
  • Page 14 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION Setting ratio Request speed AUTO(Invalid) Stop state Initial value AUTO(Invalid) Stop state Note: Requested speed will not be greater then the value defined by nciMaxSpeed (Refer to chapter 5.4.8) or less then the value defined by nciMinSpeed (Refer to chapter 5.4.7). nviDrvSpeedScale = 100, Direction: Forward = -100, Direction: Reverse When a value in nviDrvSpeedScale is set any value except for 100 and –100, it...
  • Page 15 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION Example (2) : nviInvSetFreq = 0 to 400 When nviInvSetFreq is at 60Hz and nviDrvSpeedScale is 100%, the inverter is in forward run at 60Hz. Valid Range: -163.84 to163.83% Default Value: Is defined by nciDrvSpeedScale (Refer to 5.4.14). Scaling: See chapter 6.1.4 5.2.5 Emergency Override (SNVT_hvac_emerg nviEmergOverride) When EMERG_SHUTDOWN command is inputted, the inverter executes the deceleration stop and also the...
  • Page 16 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.3 Output Network Variables - nvo’s 5.3.1 Node Object Status (SNVT_obj_status nvoObjStatus) This nvo reports node object status. It will be updated every time status change. See chap. 5.1.1 for different requests. Identifier Status Invalid_request The node has been asked for an unsupported request.
  • Page 17 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.3.3 Drive Current (SNVT_amp nvoDrvCurnt) This output network variable provides the drive output current in Amps. 5.3.4 Drive Speed (SNVT_level_percent nvoDrvSpeed) This output network variable provides the speed of the drive as a percentage of the nominal speed. Since nominal speed and nominal frequncy are tightly connected to eachother, the out value is calculated on the nominal (base) frequency and the running (out) frequency.
  • Page 18 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.4 Configuration Properties - nci’s If an nci has a corresponding parameter in the inverter it will be written to with the value of the nci at some occations, apart from when nci is update from network. These occations are when: -Node is brought online -Inverter is power-cycled -Inverter is tripped and error is reset from LonWorks option card...
  • Page 19 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.4.6 Nominal Frequency (SNVT_freq_hz nciNmlFreq) This configuration property is used to provide the nominal frequency of the motor. This value is necessary to determine the minimum and maximum frequency. Default value: 50 Hz 5.4.7 Minimum Speed (SNVT_lev_percent nciMinSpeed) This configuration property is used to define the minimum speed of a motor.
  • Page 20 CHAPTER 5 LONWORKS COMMUNICATION FUNCTION 5.4.12 Parameter value, Write (UNVT_sj300 nciWriValue) This nci is used as a value input for the user selected parameter nciWriAdr. The SCPT uses the following format: struct{ unsigned long int lowWord; //Used for byte and word data unsigned long int highWord;...

  • Page 21: Chapter6 Control From Lonworks

    CHAPTER 6 CONTROL FROM LONWORKS 6.1 Conditions for operating This section will decsribe what conditions there are for performing some common actions and how the combination of SNVTs and SCPTs will affect the operation of the SJ300/L300P inverter. 6.1.1 General Communication and configuation of LonWorks optionboard and SJ300/L300P must be set up and function properly.
  • Page 22 CHAPTER 6 CONTROL FROM LONWORKS (2) In case of nviInvSetFreq = 0 to 400 NviSpeedStpt NviSetFreq NviSpeedScale Frequency setting Operation command value State 50Hz 100% nviInvSetFreq Stop command 30Hz 100% nviInvSetFreq Forward command 60Hz 100% nviInvSetFreq Forward command 50Hz nviInvSetFreq Reverse command 100% 60Hz...
  • Page 23 CHAPTER 6 CONTROL FROM LONWORKS 6.1.6 Read value from an address The address set in nciRdAdr will be polled and result will be written to nvoParam as often as value on address changes or the workload on the host application and nciMinOutTime allows. If nciRdAdr is set to 0x0070 it will not load the network with information not wanted or needed for the moment.
  • Page 24 CHAPTER 6 CONTROL FROM LONWORKS 6.4 How to switch to operation command and frequency command Table below indicates how to switch to operation command and frequency command by using the commands in nviObjRequest. (Refer to chapter 4.1, 5.2.1 and 5.3.1) nviObjRequest Command setting data Control and frequency setting...

  • Page 25: Chapter7 Countermeasure For Abnormality

    CHAPTER 7 COUNTERMEASURE FOR ABNORMALITY 7.1 Trip display When the inverter is in a tripped state, the inverter displays an error code (See table below). The trip history monitor (d081 to d086) also displays the same error code as the inverter. Trip code Inverter’s running condition of trip detected 7.2 Protection function list...
  • Page 26 CHAPTER 7 COUNTERMEASURE FOR ABNORMALITY 7.4 LED display and Countermeasure Following states are indicated by three LED's. Color Function Countermeasure Green Power on and CPU running Red flashing Flash or RAM error Hardware error(if flashing red Need to change the SJ-LW. Power/ together with...
  • Page 27 APPENDIX PARAMETER OBJECT LISTS APPENDIX1 Parameter cross-reference list Setting operator Address Size magn. Contents L300P range code H'08000000 4 0 400.00Hz *100 1st setting Multispeed frequency 0 A020 H'08000004 4 0 400.00Hz *100 2nd setting Multispeed frequency 0 A220 H'08000008 4 0 400.00Hz *100 3rd setting Multispeed frequency 0...
  • Page 28 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code operation at Instantaneous power failure H'080000D4 4 0 400.00Hz *100 Arrival frequency at acceleration1 C042 H'080000D8 4 0 400.00Hz *100 Arrival frequency at deceleration1 C043 H'080000DC 4 0 400.00Hz *100 Arrival frequency at acceleration2 C045...
  • Page 29 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code H'08000170 2 20.0 120.0 Level of 1st Electronic thermal protection b012 H'08000172 2 20.0 120.0 Level of 2nd Electronic thermal protection b212 H'08000174 2 20.0 120.0 Level of 3rd Electronic thermal protection b312 2 0 400Hz H'08000176...
  • Page 30 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code (PI control) H'080001DE 2 0 1000.0(%) 2nd Proportional gain of speed control (PI control) No H250 H'080001E0 2 0 1000.0(%) 1st Integral gain of speed control (PI control) H051 H'080001E2 2 0 1000.0(%)
  • Page 31 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code H'08000244 1 0 100% End rate of O terminal A014 H'08000245 1 00,01 code Selection of starting function of O terminal A015 1 1 30times H'08000246 Sampling number of fetching data from “O”na A016 H'08000247 1 -100 100%...
  • Page 32 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code 1 00 03 H'0800027A code Selection of method of overload restriction2 b024 H'0800027B 1 00 03,10 code Selection of method of Software lock b031 H'0800027C 1 00 02 code Selection of Display b037...
  • Page 33 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code input 6 H'080002A7 1 00,01 code Selection of a(NO) or b(NC) contact in Intelligent C017 input 7 H'080002A8 1 00,01 code Selection of a(NO) or b(NC) contact in Intelligent C018 input 8 H'080002A9...
  • Page 34 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code 1 00 03 H'080002D3 code Selection of method of Pulse lines input P013 H'080002D4 1 00,01 code Set of Orientation direction P016 H'080002D5 1 00,01 code Selection of location of electric gear P019 H'080002D6 1 00,01...
  • Page 35 APPENDIX PARAMETER OBJECT LISTS Setting operator Address Size magn. Contents L300P range code Note 1 4 0 4294836225s Accumulated time during running of Trip5 Note 1 4 0 4294836225s Accumulated time during power ON of Trip5 Note 1 4 00 H'FF Factor and Status of Trip6 4 0 400.00Hz Note 1...
  • Page 36 APPENDIX PARAMETER OBJECT LISTS APPENDIX 2 Trip monitor data address Trip monitor data address is decided Trip monitor No. and Trip pointer(H'08000363). Following table is Trip monitor data address. Choiceing Last occurred trip cause(d081) . if trip pointer equal 1,data address equal H'08000378. if trip pointer equal 4,data address equal H'080003B4.
