Lightolier Lytecaster 1024 Specification

Page 1 of 2
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1024
1001LED
Cratere
1000LEDREM
L56LED
Frame-In Kit
1002P1
1003R
1000P1
1000IC
1000AICM
1004ICX/n
1004IC/n
1004ICR
1004SIC/n
1004SICR
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); Anobrite
processed) semi-specular finish for permanent reflectivity.
2. Diffuser: Textured, double-etched glass; twists tightly to reflector trim.
Neoprene gasket (captive on flange of reflector) seals unit under pressure
of twist lock. Concealed wire-hinge supports glass enclosure for quick, safe
relamping.
3. Frame-In Kit: (1002P1 standard frame shown) Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
Meets nEC requirements for spas and hot tubs.
®
Options & Accessories
Retaining Clips: 1955 - For installing in existing ceiling
Labels
UL (Suitable for Wet Locations - Covered Ceiling Only), I.B.E.W.
Lytecaster
1024/1002P1 Series
Standard Incandescent
LED
Installation Type Lamping Height
Non-IC LED 6 3/4""
Non-IC Remodeler LED 6 3/4"
Non-IC Retrofit LED 6 3/4"
Incandescent
Ceiling Type Lamping Height
Non-IC 75W A19 6 3/4"
Non-IC
6 3/4"
Remodeler
Non IC 6 7/8"
IC 40W A19 7 5/16"
AirSeal IC 7 5/16"
®
AirSeal IC 7 1/4"
®
Non-IC 40W A19 7 1/2"
Non-IC 7 1/2"
Remodeler
5 1/2"
Shallow Non-IC
Shallow-Non-IC
5 1/2"
Remodeler
(anodic-
®
Recessed Downlighting
®
5" Aperture Cratere Dome Diffuser Reflector Trim
6 3/4"
1024/1003R
0
Remodeler
7 1/2"
7 1/2"
Fluorescent
Frame-In Kit Ceiling Type
1001F13U Series UniFrame Non-IC
™
1001F18U Series UniFrame Non-IC
™
1001F26U Series UniFrame Non-IC
™
1004F13 Series IC
1004F18 Series IC
1004F26 Series IC
1001F13ICU/n Performance IC
1001F18ICU/n Performance IC
1001F26ICU/n Performance IC
1001FDICMX1/n
Performance IC
Advance Mark 10
Dimming 120V
1001FDICMX2/n
Performance IC
Advance Mark 10
Dimming 277V
1910XFH1 Conversion Kit
NEC is a registered trademark of the National Fire Protection Association.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • K1007
7 1/2"
1024/1004ICR
0
Non-IC
™
Convertible
Remodeler
Non-IC only
1024/1004IC/n
0
Convertible
™
Non-IC only
Lamping Height
(1) Quad/Triple 13W (GX24q-1) 5 7/8"
(1) Quad/Triple 18W (GX24q-2) 5 7/8"
(1) Quad/Triple 26W (GX24q-3) 5 7/8"
(1) Quad/Triple 13W (GX24q-1) 7 1/2"
(1) Quad/Triple 18W (GX24q-2) 7 1/2"
(1) Quad/Triple 26W (GX24q-2) 7 1/2"
(1) Quad/Triple 13W (GX24q-1) 7 1/4"
(1) Quad/Triple 18W (GX24q-2) 7 1/4"
(1) Quad/Triple 26W (GX24q-3) 7 1/4"
(1) Quad/Triple 26W (GX24q-3) 7 1/4"
(1) Quad/Triple 26W (GX24q-3) 7 1/4"
(1) Quad 13W (GX23-2) 6 3/4"
Type:
www.lightolier.com
1024
™
