N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SJCAAB15.eps N58TAAAAA7.eps N58CAAAAC10.eps N58XDAAAA1.eps
N58YBAAAA4.eps N58I1151-1.eps W241970401.eps S241970401.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS26RC3JS3
Color
stainless
Volts
115
Wiring Diagram
241970401
Owner's Guide
241856000
Market
North America
Energy Guide
241935516
Service Data Sheet 240389636
Publication No.
5995532198
09/01/30
(EN/SERVICE/KHB)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26RC3J
©
2009 Home Pr
oducts, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS26RC3J
Summary of Contents for Frigidaire FRS26RC3J
- Page 1 Product No. FRS26RC3JS3 Color stainless Volts Wiring Diagram 241970401 Owner's Guide 241856000 Market North America Energy Guide 241935516 Service Data Sheet 240389636 SIDE-BY-SIDE N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps REFRIGERATOR N58SJCAAB15.eps N58TAAAAA7.eps N58CAAAAC10.eps N58XDAAAA1.eps N58YBAAAA4.eps N58I1151-1.eps W241970401.eps S241970401.eps x Major Appliances Model No. North &...
-
Page 2: Freezer Door
Publication No: 5995532198 FRS26RC3JS3 FREEZER DOOR N58FCCBBB2 01/09... - Page 3 FRS26RC3JS3 Publication No: 5995532198 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241786006 Gasket-frzr door, black, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 241615159 Door-frzr, stainless, complete assy 240581906 Door Stop, black, frzr 241934305 Handle-door, black 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 240521304...
-
Page 4: Refrigerator Door
Publication No: 5995532198 FRS26RC3JS3 REFRIGERATOR DOOR N58RCCBBB5 01/09... - Page 5 FRS26RC3JS3 Publication No: 5995532198 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241786005 Gasket-refr door, black, magnetic 240323001 Bin-door, pseudo, bottom 240326203 Door-dairy 240581905 Door Stop, black, ref 241629332 Door-refr, stainless, complete assy 241934302 Handle-door, black 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 240521304...
- Page 6 Publication No: 5995532198 FRS26RC3JS3 CABINET 01/09...
- Page 7 FRS26RC3JS3 Publication No: 5995532198 CABINET POS. NO PART NO. DESCRIPTION 240435912 Cover-air duct 241719711 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special...
- Page 8 Publication No: 5995532198 FRS26RC3JS3 SHELVES N58SJCAAB15 01/09...
- Page 9 FRS26RC3JS3 Publication No: 5995532198 SHELVES POS. NO PART NO. DESCRIPTION 241657602 Shelf, flip up, wire 241657502 Shelf, fixed, freezer 241657504 Shelf, fixed, upper, freezer 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625 240355208 Shelf-"Spill-Safe", fixed 240350702 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240350902...
- Page 10 Publication No: 5995532198 FRS26RC3JS3 CONTROLS N58TAAAAA7 01/09...
- Page 11 FRS26RC3JS3 Publication No: 5995532198 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg 241854601 Motor-evap fan 241517701 Clip, evap fan motor 241555401 Light Bulb 16 # 241513901 Socket-light 240383301 Box-control, front...
- Page 12 Publication No: 5995532198 FRS26RC3JS3 SYSTEM N58CAAAAC10 01/09...
- Page 13 FRS26RC3JS3 Publication No: 5995532198 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 6* # 241537804 Harness-wiring, control box 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2) 21 #...
-
Page 14: Ice And Water Dispenser
Publication No: 5995532198 FRS26RC3JS3 ICE & WATER DISPENSER 01/09... - Page 15 FRS26RC3JS3 Publication No: 5995532198 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976419 Tube-water inlet, valve to door 218976420 Tube-water inlet, inlet valve, to filter 218976915 Tube-water inlet, inlet valve, to filter 240561701 Seal-water inlet, inlet valve, to ice maker 241679003 Cover-module, black 241680507...
-
Page 16: Ice Container
Publication No: 5995532198 FRS26RC3JS3 ICE CONTAINER 37A 34 34 33 N58YBAAAA4 01/09... - Page 17 FRS26RC3JS3 Publication No: 5995532198 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241716101 Auger-ice 241685201 Cam-drive 241734001 Container-ice, bucket only 241685101 Drum-ice disp 241734201 Front-ice container 241726501 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501 Drive Blade 18 # 241676201 Motor-auger 241578401 Wiring Harness, auger motor...
-
Page 18: Ice Maker
Publication No: 5995532198 FRS26RC3JS3 ICE MAKER A R M A R M L O C L O C K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 01/09... - Page 19 FRS26RC3JS3 Publication No: 5995532198 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976419 Tube-water inlet, valve to door 218976420 Tube-water inlet, inlet valve, to filter 218976915 Tube-water inlet, inlet valve, to filter 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ice maker 5304456657...
- Page 20 Publication No: 5995532198 FRS26RC3JS3 ICE MAKER A R M A R M L O C L O C K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 01/09...
- Page 21 FRS26RC3JS3 Publication No: 5995532198 ICE MAKER POS. NO PART NO. DESCRIPTION 5304456686 Bracket-leveling, ice maker 5304456687 Screw-IM brkt mtg, pan hd phillips, 8-32T x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 241642601 Harness-wiring Svo 241806601 Connector-water, straight 5304456666 Screw, M 3x20 #2, (6) 5304456688 Terminal...
-
Page 22: Wiring Schematic
Publication No: 5995532198 FRS26RC3JS3 WIRING SCHEMATIC 01/09... -
Page 23: Wiring Diagram
FRS26RC3JS3 Publication No: 5995532198 WIRING DIAGRAM 01/09 # Functional Parts * Non-Illustrated Parts...
