Frigidaire FRS26R4C Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26R4C:
Table of Contents

Advertisement

Quick Links

Download this manual
N58L00001.eps N58FACBBB4.eps N58RACBBB6.eps N58BAAAAA0.eps
N58SJCAAB1.eps N58TAAAAA4.eps N58CAAAAA3.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRS26R4CB2 FRS26R4CQ2 FRS26R4CW2
Series
R134a
Color
black
Volts
115
Wiring Diagram
241526901
Owner's Guide
240581300
Market
North America North America North America
Energy Guide
240572130
Service Data Sheet 240389616
Publication No.
5995410494
04/05/25
(EN/SERVICE/KHB)
357
R134a
R134a
bisque
white
115
115
241526901
241526901
240581300
240581300
240572130
240572130
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26R4C
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26R4C

Summary of Contents for Frigidaire FRS26R4C

  • Page 1 Product No. FRS26R4CB2 FRS26R4CQ2 FRS26R4CW2 Series R134a R134a R134a Color black bisque white Volts Wiring Diagram 241526901 241526901 241526901 Owner's Guide 240581300 240581300 240581300 Market North America North America North America Energy Guide 240572130 240572130 240572130 Service Data Sheet 240389616 240389616 240389616 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995410494 FRS26R4C FREEZER DOOR 05/04...
  • Page 3 FRS26R4C Publication No: 5995410494 FREEZER DOOR Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 240390606 A - - Gasket-frzr door, black, magnetic 240390602 - B C Gasket-frzr door, white, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C...

  • Page 4: Refrigerator Door

    Publication No: 5995410494 FRS26R4C REFRIGERATOR DOOR 05/04...
  • Page 5 FRS26R4C Publication No: 5995410494 REFRIGERATOR DOOR Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 240390605 A - - Gasket-refr door, black, magnetic 240390601 - B C Gasket-refr door, white, magnetic 240323001 A B C Bin-door, pseudo, bottom 240326203 A B C...
  • Page 6 Publication No: 5995410494 FRS26R4C CABINET 05/04...
  • Page 7 FRS26R4C Publication No: 5995410494 CABINET Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 240435906 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 240505801 A B C Switch, light/lamp...
  • Page 8 Publication No: 5995410494 FRS26R4C SHELVES 05/04...
  • Page 9 FRS26R4C Publication No: 5995410494 SHELVES Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 240338802 A B C Shelf-freezer, flip-up 240338702 A B C Shelf-freezer, fixed wire 240338704 A B C Shelf-freezer, fixed wire 240355208 A B C Shelf-"Spill-Safe", fixed...
  • Page 10 Publication No: 5995410494 FRS26R4C CONTROLS 05/04...
  • Page 11 FRS26R4C Publication No: 5995410494 CONTROLS Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 5300157666 A B C Bushing-motor mtg, (2) 5303292396 A B C Bracket-motor mtg, front 13 # 240369701...
  • Page 12 Publication No: 5995410494 FRS26R4C SYSTEM 05/04...
  • Page 13 FRS26R4C Publication No: 5995410494 SYSTEM Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241527401 A B C Harness-wiring, machine compt...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995410494 FRS26R4C ICE & WATER DISPENSER 05/04...
  • Page 15 FRS26R4C Publication No: 5995410494 ICE & WATER DISPENSER Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No: 5995410494 FRS26R4C ICE CONTAINER 05/04...
  • Page 17 FRS26R4C Publication No: 5995410494 ICE CONTAINER Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 218815400...

  • Page 18: Ice Maker

    Publication No: 5995410494 FRS26R4C ICE MAKER 05/04...
  • Page 19 FRS26R4C Publication No: 5995410494 ICE MAKER Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976907 A B C...
  • Page 20 Publication No: 5995410494 FRS26R4C ICE MAKER 05/04...
  • Page 21 FRS26R4C Publication No: 5995410494 ICE MAKER Model Index: A FRS26R4C (FRS26R4CB2) B FRS26R4C (FRS26R4CQ2) C FRS26R4C (FRS26R4CW2) POS. NO PART NO. DESCRIPTION 218709100 A B C Screw, hex head, 10-32 x 0.500 240363601 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C...

  • Page 22: Wiring Schematic

    Publication No: 5995410494 FRS26R4C WIRING SCHEMATIC 05/04...

  • Page 23: Wiring Diagram

    FRS26R4C Publication No: 5995410494 WIRING DIAGRAM 05/04 # Functional Parts * Non-Illustrated Parts...
