Related Manuals for AEG LAVAMAT 16820
Summary of Contents for AEG LAVAMAT 16820
-
Page 1: Instruction Booklet
LAVAMAT 16820 Washer-dryer Instruction Booklet PERFEKT IN FORM UND FUNKTION... - Page 2 Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recom- mend that you keep this instruction booklet for future reference and pass it on to any future owners. The warning triangle and/or the key words (Warning!, Caution!) empha- size information that is particularly important for your safety or correct functioning of the appliance.
-
Page 3: Table Of Contents
Contents Safety instructions ..........6 Disposal . - Page 4 Contents Preparing the drying cycle ........23 Load .
- Page 5 Contents Technical data ..........43 Service and Spare Parts .
-
Page 6: Safety Instructions
Safety instructions Your safety is of paramount importance, please ensure you read this instruction book before installing or using this appliance. General safety • Repairs to the machine must be carried out only by qualified person- nel. Repairs carried out by inexperienced persons could cause injury or serious malfunctioning. -
Page 7: Child Safety
Child safety • This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or play with the appliance. • Pets and children have been known to climb into washing machines. Please check the drum before use. •... -
Page 8: Disposal
Disposal Packaging materials The materials marked with the symbol >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Machine Use authorised disposal sites for your old appliance. Help to keep your country tidy! Tips for environmental protection To save water, energy and to help protect the environment, we recommend... -
Page 9: Main Features Of Your Washer-Dryer
Main features of your washer-dryer • Programme and temperature setting using the programme selector. • Stain programme for effectively treating stained washing. • Energy saving programme (Economy) for normally soiled cotton items. • Speed for the final spin can be reduced to 1200, 900 or 700 rpm. •... -
Page 10: Description Of The Appliance
Description of the appliance Front view... -
Page 11: Control Panel
Description of the appliance Control panel A = Option buttons B = START/PAUSE button C = Spin speed button D = Electronic drying button E = Drying time button F = Delay start button G = Display H = Programme progress display J = Programme selector dial Programme selector dial The programme selector determines the type of washing cycle (e.g. -
Page 12: Programme Option Buttons
Description of the appliance Position 40°C Easy iron. In this position the laundry is gently washed and spun to avoid any creasing. In this way ironing is easier. Position COLD = cold wash Programme Option buttons Depending on the programme, different functions can be combined. These must be selected after choosing the desired programme and before depressing the START/PAUSE button. -
Page 13: Start/Pause Button
Description of the appliance START/PAUSE button This button has two functions: a) Start After having selected the required programme, press this button to start the machine. If you have selected the DELAY TIMER option, the machine starts its hourly countdown. b) Pause To interrupt a programme which is running, press the START/PAUSE button: the information on the display remains lit and the... -
Page 14: Electronic Drying Button
Description of the appliance ELECTRONIC DRYING button This button enables you to choose the required degree of drying for cottons and synthetics: Extra dry (not for easy cares) Cupboard dry Iron dry (not for easy cares) The drying time is automatically adjusted by the machine: the laundry will be dried to the selected degree of dryness. -
Page 15: Programme Progress Display
• When the programme has finished, a steadily lit zero is displayed. • Delayed start, (23 hours max.) programmed using the special button. The countdown is updated every hour. • Alarm code indicating a fault in the machine operation (see page 38). Programme progress display By selecting the wash programme, the pilot lights corre- sponding to the various phases making up the programme... -
Page 16: Opening The Door After The Programme Has Started
Description of the appliance Opening the door after the programme has started To open the door set the machine to PAUSE by pressing the START/PAUSE button. The DOOR light on the control panel beside the START/PAUSE button indicates if the door can be opened: •... -
Page 17: Detergent Dispenser Drawer
Detergent dispenser drawer Compartment for prewash or stain remover. The prewash detergent is added at the beginning of the wash programme. The stain remover is added dur- ing the STAIN-Action phase in the main wash. Compartment for powder or liquid detergent used for main wash. It is emptied at the beginning of the wash cycle. -
Page 18: Preparing The Wash Cycle
Preparing the wash cycle Sorting out and preparing the laundry • Sort out the laundry according to type of fabrics and care labels (see “Types of fabric and care labels”). • Empty pockets. • Remove any metal parts (safety pins, clips, etc.). •... -
Page 19: Weight Of Laundry
Weight of laundry Bathrobes Work shirts Quilt covers Sheets Blouses Hand towels Tea towels Shirts Pillowcases Night-gowns/Pyjamas Tablecloths Underwear Types of fabric and care labels The labels on garments help you to select the most suitable wash pro- gramme. The laundry should be sorted out according to the type of fab- ric and the instructions indicated on care labels. - Page 20 Preparing the wash cycle Delicates Microfibres, synthetics or curtains marked with these symbols require a very gentle treatment. The DELICATES programme is suitable for this type of fabric. Woollens and particularly delicate items Fabrics such as wool, wool mix or silk marked with this symbol are par- ticularly sensitive to machine washing.
-
Page 21: Detergents And Additives
Detergents and additives Which detergent?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 22: And In Which Form
Preparing the wash cycle And in which form? Not only are there different types of detergent, but they are also available in different forms. Whether you chose a powder or liquid in traditional or compact form is your own personal choice. TRADITIONAL POWDERS Pour the powder directly into the dispenser drawer. -
Page 23: Preparing The Drying Cycle
Preparing the drying cycle As a dryer, the machine works on the condensation principle. Therefore, the water tap must be open and the drain hose must drain water into a sink or into the drain pipe, even during the dry- ing cycle. -
Page 24: Drying Symbols On Garment Labels
Preparing the drying cycle Drying symbols on garment labels Always look at the garment label to check whether garments can be machine dried. The following symbols refer to drying: Machine drying is usually possible Normal drying (normal temperature) Gentle drying (reduced temperature) Do not machine dry Duration of the drying cycle The drying time can vary according to... -
Page 25: How To Wash
How to wash Max. load - cottons - easy cares and delicates - wool, silk and (handwash) Load the laundry Open the door. Place the laundry in the drum, one item at a time. Distribute laundry as evenly as possible. Close the door. Add detergent and additive Pull the drawer out until it stops. -
Page 26: Selection Of The Desired Wash Programme
How to wash Selection of the desired wash programme Turn the programme selector dial to the desired position: the lights corresponding to the different phases making up the selected programme light up. The display shows the duration of the programme. Selection of the desired options The options available depend on the degree of soiling of the laundry. -
Page 27: Selection Of The Extra Rinse
EXTRA RINSE This appliance is designed for saving water. However, for people with a very delicate skin (allergic to detergents) it may be necessary to rinse the laundry using an extra quantity of water (extra rinse). The extra rinse is available only with the cotton, easy care and deli- cates. -
Page 28: Starting The Programme
How to wash Starting the programme 1. Check that the water tap is open. 2. Press START/PAUSE to start the programme. If the Delay Start option has been selected the programme will start at the end of the countdown. At the start of the programme, if the “END” light blinks for few min- utes, the acoustic signal sounds and on the display appears E40, that indicates that the door is open. -
Page 29: At The End Of The Programme
How to wash At the end of the programme The machine stops automatically. A zero appears on the display. The END light comes on in the programme progress display, the START/PAUSE light is off and the DOOR light is green. If the OVER DOSING light comes on it indicates that too much deter- gent has been used. -
Page 30: Automatic Washing And Drying (Non-Stop Programme)
How to wash Automatic washing and drying (NON-STOP programme) Warning! For NON-STOP programmes, it is also essential not to exceed the maximum load sizes of 3 kg for cotton and 2 kg for easy cares. Load the laundry. Add detergent and additive. Do not use a dosing device when carrying out automatic washing and drying programme. -
Page 31: Programme Charts: Wash And Special Programmes
Programme chart Wash programmes Wash Temp. programme Cotton and linen, for example nor- White mally soiled work 95°-60° Cottons garments, sheets, household linen, underwear, towels. Cotton and linen, for example normally to ECONOMY 60° lightly soiled sheets and household linen. 60°- Coloured cotton or 40°-30°... -
Page 32: Special Programmes
Programme chart Special programmes Descrip- Programme tion This pro- gramme can be used for Rinse rinsing hand washed gar- ments. Hand washed garments to Softeners be starched or softened. For emptying out the last rinse water in Drain programmes with the Rinse Hold option Separate spin Spin... -
Page 33: Programme Chart Timed Drying
Programme chart Timed Drying Degree of drying Extra dry Ideal for towelling materials Cupboard dry (*) Suitable for items to put away without ironing Iron dry Suitable for ironing (*) The CUPBOARD DRY drying programme for cotton is the reference pro- gramme for the Energy Label data, in compliance with standard EEC 92/75. -
Page 34: Consumption Data For Timed Drying
Consumption data for timed drying The values shown in the chart have been obtained in laboratory tests. They may vary when the appliance is used at home, but they can be used as a guide. Degree of drying Cotton Extra dry Cotton Cupboard dry Easy cares... -
Page 35: Cleaning And Maintenance
Cleaning and maintenance After each wash At the end of the wash programme, pull the dispenser drawer out a lit- tle to let it dry. Leave the door ajar to allow air to circulate. If the machine is not used for a prolonged period: Close the water tap and unplug the appliance. -
Page 36: Drain Pump
Cleaning and maintenance To facilitate cleaning, the top part of the additive compartment can be removed. Detergent can also accumulate inside the drawer recess: clean it with an old tooth- brush. Refit the drawer after cleaning. Door seal Regularly check to see, if there are deposits or foreign objects in the rubber seal behind the door and remove them. -
Page 37: Water Inlet Filter
Cleaning and maintenance Remove any objects from the pump impeller by rotating it. Put the cap back on the emergency emptying hose and place the latter back in its seat. Screw the pump fully in. Close the pump door. Water inlet filter If you notice that the machine is taking longer to fill, check that the filter in the water inlet hose is not blocked. -
Page 38: Frost Precautions
Frost precautions If the machine is installed in a place where the temperature could drop below 0°C, proceed as follows: • Close the water tap and unscrew the water inlet hose from the tap. • Place the end of the emergency emptying hose and that of the inlet hose in a bowl placed on the floor and let water drain out. - Page 39 Problem The main electrical fuse or Replace the fuse. the fuse in the plug has blown. The door is not properly closed (E40). The machine does not work The plug is not connected. Insert the plug. The START button has not been pressed.
- Page 40 Something not working? Problem There is water on the floor The machine vibrates or is noisy The door will not open The display shows the alarm code EF Possible cause Too much detergent has been used. An unsuitable detergent has been used that creates too much foam.
- Page 41 Problem The unbalance detection device that prevents excessive vibration during spinning has cut in. Spinning starts late or the machine does not spin The water tap is not open (E10). The drain pump is clogged. Clean the pump. The drying time or degree of Select the required function. dryness has not been selected.
-
Page 42: Unsatisfactory Washing Results
Something not working? Unsatisfactory washing results If the laundry looks grey and lime scale is found in the drum • Too little detergent has been used. • An unsuitable detergent has been used. • Stubborn stains have not been treated prior to washing. •... -
Page 43: Technical Data
Technical data Height x Width x Depth Depth with door opened Height adjustment Net weight Load (depending on programme) Drum speed during washing Drum speed during spinning Water pressure This appliance complies with the following EC directives: 73/23/EEC of 19.2.1973 “Low voltage directive”, including directive 93 / 68 / EEC 89/336/EEC of 3.5.1989 “Electromagnetic Compatibility Directive”. -
Page 44: Service And Spare Parts
Service Force, please visit the website at www.serviceforce.co.uk. For Customer Service in The Republic of Ireland please contact us at the address below: Electrolux Group (Ire) Ltd Long Mile Road Dublin 12 Republic of Ireland Tel: + 353 (0) 1 4090754... - Page 45 Help us to help you Please determine your type of enquiry before telephoning. When you contact us we need to know: 1.Your name, address and post code. 2.Your telephone number. 3.Clear and concise details of the fault. - What is the fault? - When does the fault occur? - Does the multi-display issue an error-message (E and a number)? 4.The model, production number and production identification number.
-
Page 46: Standard Guarantee Conditions
Standard Guarantee Conditions We, AEG, undertake that if within 12 months of the date of the pur- chase this AEG appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our dis- cretion repair or replace the same FREE OF CHARGE for labour, materi- als or carriage on condition that: •... -
Page 47: European Guarantee
European Guarantee If you should move to another country within Europe then your guar- antee moves with you to your new home subject to the following qual- ifications: • The guarantee starts from the date you first purchased your product. •... -
Page 48: Instructions For Installation And Electrical Connection
Instructions for installation and electrical connection Safety instructions for the installer • This appliance is heavy, care should be taken when moving it. • When unpacking the appliance, check that it is not damaged. If in doubt, do not use it and contact the retailer. •... -
Page 49: Dimensions Of The Appliance
Dimensions of the appliance Front view and side view Rear view... -
Page 50: Installation
Installation Unpacking All transit bolts and packing must be removed before using the appliance. Using a spanner, unscrew and remove the 2 rear bottom screws. Slide out the 2 plastic pins. Lay the machine on its back, taking care not to squash the hoses. -
Page 51: Positioning
Set the machine upright and remove the remaining rear screw. Slide out the relevant pin. Plug the open holes with the plugs which you will find in the plastic bag containing the instruction booklet. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. -
Page 52: Water Inlet
Installation Water inlet (cold water connection only) Connect the hose to a tap with a 3/4” thread. Installation should comply with local water authority and building regulations’ require- ments. The inlet hose is provided with a water stop device, which protects against damage caused by water leaks in the hose which could develop due to natural ageing of the hose. - Page 53 Installation When discharging into a standpipe ensure that the top of the standpipe is no more than 90 cm (35.4'') and no less than 60 cm (23.6'') above floor level. The drain hose may be extend- ed to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Force Centre.
-
Page 54: Electrical Connection
Installation In the interest of the environment Washing machines and dish- washers should be connected to the FOUL drainage system, the water will then be taken to a sewage works for treat- ment before being discharged safely into a river. It is essential that these appli- ances are not connected to the surface water drainage system... -
Page 55: Permanent Connection
Installation If you fit your own plug, the colours of the wires in the mains lead of your appliance may not correspond with the markings identifying the terminals in your plug, proceed as follows: Connect the green and yellow (earth) wire to the terminal in the plug which is marked with the letter «E»... - Page 56 132.988.621-01-0804 From the Electrolux Group. The world’s No. 1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
