N58L00001.eps N58FAAAAB4.eps N58RAAABB4.eps N58BAAAAA0.eps
N58SACACB22.eps N58TAAAAA4.eps N58CAAAAA3.eps N58XCAAAA0.eps
N58YCAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRS26R2AQ7 FRS26R2AW7
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
241526901
Owner's Guide
240389311
Market
North America North America
Service Data Sheet 240389616
Publication No.
5995410395
04/05/25
(EN/SERVICE/DCS)
357
R134a
white
115
241526901
240389311
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26R2A
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS26R2A
Summary of Contents for Frigidaire FRS26R2A
- Page 1 Product No. FRS26R2AQ7 FRS26R2AW7 Series R134a R134a Color bisque white Volts Wiring Diagram 241526901 241526901 Owner's Guide 240389311 240389311 Market North America North America Service Data Sheet 240389616 240389616 SIDE-BY-SIDE N58L00001.eps N58FAAAAB4.eps N58RAAABB4.eps N58BAAAAA0.eps REFRIGERATOR N58SACACB22.eps N58TAAAAA4.eps N58CAAAAA3.eps N58XCAAAA0.eps N58YCAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps ELECTROLUX HOME PRODUCTS, INC.
-
Page 2: Freezer Door
Publication No: 5995410395 FRS26R2A FREEZER DOOR 05/04... - Page 3 FRS26R2A Publication No: 5995410395 FREEZER DOOR Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 240390602 Gasket-frzr door, white, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 240451808 Door-frzr, bisque, complete assy 240451802 Door-frzr, white, complete assy 240537104 Door Stop, bisque, frzr 240537102 Door Stop, white, frzr...
-
Page 4: Refrigerator Door
Publication No: 5995410395 FRS26R2A REFRIGERATOR DOOR 05/04... - Page 5 FRS26R2A Publication No: 5995410395 REFRIGERATOR DOOR Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 240390601 Gasket-refr door, white, magnetic 240323001 Bin-door, pseudo, bottom 240326203 Door-dairy 240537103 Door Stop, bisque, ref 240537101 Door Stop, white, ref 240451906 Door-refr, bisque, complete assy 240451902...
- Page 6 Publication No: 5995410395 FRS26R2A CABINET 05/04...
- Page 7 FRS26R2A Publication No: 5995410395 CABINET Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 240435906 Cover-air duct 240475907 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw, #8 truss hd, 10-32CA x 0.500 240457701 Plate-door closer 240402701...
- Page 8 Publication No: 5995410395 FRS26R2A SHELVES 05/04...
- Page 9 FRS26R2A Publication No: 5995410395 SHELVES Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 241510604 Trim-basket 240338802 Shelf-freezer, flip-up 240338702 Shelf-freezer, fixed wire 240338704 Shelf-freezer, fixed wire 240355208 Shelf-"Spill-Safe", fixed 240350702 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240350902 Cover-crisper pan, lower 240351007...
- Page 10 Publication No: 5995410395 FRS26R2A CONTROLS 05/04...
- Page 11 FRS26R2A Publication No: 5995410395 CONTROLS Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 13 # 240369701 Motor-evap fan 215474201 Washer, "slinger", nylon, evap fan shaft 5303292397 Bracket-motor mtg, rear 240436702...
- Page 12 Publication No: 5995410395 FRS26R2A SYSTEM 05/04...
- Page 13 FRS26R2A Publication No: 5995410395 SYSTEM Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241527401 Harness-wiring, machine compt 240449601 Harness-wiring 241537802 Harness-wiring, control box 14 # 5303918253 Defrost Heater Kit 15 #...
-
Page 14: Ice And Water Dispenser
Publication No: 5995410395 FRS26R2A ICE & WATER DISPENSER 05/04... - Page 15 FRS26R2A Publication No: 5995410395 ICE & WATER DISPENSER Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve, to ice maker 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 5304429705 Cover-module, bisque 5304428805...
-
Page 16: Ice Container
Publication No: 5995410395 FRS26R2A ICE CONTAINER 05/04... - Page 17 FRS26R2A Publication No: 5995410395 ICE CONTAINER Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice, bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 240433701 Receptacle, E27A lampholder, 250 V 5304404345...
-
Page 18: Ice Maker
Publication No: 5995410395 FRS26R2A ICE MAKER 05/04... - Page 19 FRS26R2A Publication No: 5995410395 ICE MAKER Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve, to ice maker 218976903 Tube-water inlet, inlet valve, to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304420650...
- Page 20 Publication No: 5995410395 FRS26R2A ICE MAKER 05/04...
- Page 21 FRS26R2A Publication No: 5995410395 ICE MAKER Model Index: A FRS26R2A (FRS26R2AQ7) B FRS26R2A (FRS26R2AW7) POS. NO PART NO. DESCRIPTION 240363601 Screw-shoulder 240542901 Cap-water valve 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 218721500 Bracket-leveling, ICE MAKER 218737900 Screw-IM brkt mtg, hex washer head, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 218888001...
-
Page 22: Wiring Schematic
Publication No: 5995410395 FRS26R2A WIRING SCHEMATIC 05/04... -
Page 23: Wiring Diagram
FRS26R2A Publication No: 5995410395 WIRING DIAGRAM 05/04 # Functional Parts * Non-Illustrated Parts...
