Frigidaire FGGF3076K Factory Parts Catalog
30-inch freestanding gas range
Hide thumbs
Also See for FGGF3076K:
- Installation instructions manual (8 pages) ,
- Specifications (2 pages) ,
- Use and care manual (36 pages)
Advertisement
Quick Links
FGGF3076KBA.eps CFGGF3056KFA.eps BFGGF3054KBA.eps VFGGF3056KFA.eps
TFGGF3056KFA.eps DLGGF3033KBA.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FGGF3076KBA FGGF3076KWA
Series
30" f/s gas
Color
black
Market
North America
Owner's Guide
316901201
Installation Instructions 316259343
Service Data Sheet
316904001
Publication No.
5995539466
09/05/05
(EN/SERVICE/ECL)
369
30" f/s gas
white
North America
316901201
316259343
316904001
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGGF3076K
©
Copyright
2009 Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FGGF3076K
Summary of Contents for Frigidaire FGGF3076K
- Page 1 Product No. FGGF3076KBA FGGF3076KWA Series 30" f/s gas 30" f/s gas Color black white Market North America North America Owner's Guide 316901201 316901201 Installation Instructions 316259343 316259343 Service Data Sheet 316904001 316904001 30-INCH FREE- FGGF3076KBA.eps CFGGF3056KFA.eps BFGGF3054KBA.eps VFGGF3056KFA.eps STANDING GAS TFGGF3056KFA.eps DLGGF3033KBA.eps RANGE Electrolux Major Appliances...
- Page 2 Publication No: 5995539466 FGGF3076K BACKGUARD CFGGF3056KFA 05/09...
- Page 3 FGGF3076K Publication No: 5995539466 BACKGUARD Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 316557600 Shield, rear wall 316497600 Shield, backguard, inner 316546704 Cap, backguard, white, RH end 316546702 Cap, backguard, black, RH end 316546705 Cap, backguard, white, LH end 316546703 Cap, backguard, black, LH end 316572400...
- Page 4 Publication No: 5995539466 FGGF3076K BURNER BFGGF3054KBA 05/09...
- Page 5 FGGF3076K Publication No: 5995539466 BURNER Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 316551202 Manifold, pipe 5303935233 Valve, 17K burner, w/mtg screw 2A # 5303935235 Valve, 5K burner, w/mtg screw 2B # 5303935236 Valve, 14K burner, w/mtg screw 2C # 5303935234 Valve, 9.5K burner, w/mtg screw...
- Page 6 Publication No: 5995539466 FGGF3076K BODY NOTE: Oven Liner N/A Ass. du four N/A VFGGF3056KFA 05/09...
- Page 7 FGGF3076K Publication No: 5995539466 BODY Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 316401600 Back, main 316021109 Screw, 8-18 x 0.5, chrome 316437100 Brace, oven top 316021132 Screw, 8-18 X 11/16, black, (3) 316400116 Panel, bodyside, white, RH 316400117 Panel, bodyside, white, LH 316400118...
- Page 8 Publication No: 5995539466 FGGF3076K BODY NOTE: Oven Liner N/A Ass. du four N/A VFGGF3056KFA 05/09...
- Page 9 FGGF3076K Publication No: 5995539466 BODY Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 316418900 Screw, sims lp, #8-32 x 5/16", black 316401201 Bracket, harness 316232700 Rod, auto latch 89 # 316464300 Motor-latch 316401100 Shield, main front 316401000 Shield, front, burner 316404100...
- Page 10 Publication No: 5995539466 FGGF3076K TOP/DRAWER TFGGF3056KFA 05/09...
- Page 11 FGGF3076K Publication No: 5995539466 TOP/DRAWER Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 316408901 Drawer, warmer 316021110 Screw, 8-18 x 0.5, black 316403203 Liner, black, drawer 316403405 Panel, drawer, white, front 316403406 Panel, drawer, black, front 316415000 Glide, warmer, inner RH 316415001...
- Page 12 Publication No: 5995539466 FGGF3076K DOOR DLGGF3033KBA 05/09...
- Page 13 FGGF3076K Publication No: 5995539466 DOOR Model Index: A FGGF3076K (FGGF3076KWA) B FGGF3076K (FGGF3076KBA) POS. NO PART NO. DESCRIPTION 5303935326 Trim kit-door, 3 sided, white, w/tape 5303935324 Trim kit-door, 3 sided, black, w/tape 316566400 Glass Assembly, outer, white, w/badge 316566401 Glass Assembly, outer, black, w/badge 316402306 Shield, wool 316021109...
