OWNER'S MANUAL
MODEL:
WARNING
• Do not modify any parts of the engine.
• This engine is designed to be used to Radio
controlled products.
• In case any modification by customer,
ZENOAH shall not bear any responsibility from
the damage caused by such modification.
• Keep ignition system well maintained.
G800BPU
G800BPU-1
848H6393A3 (009)
September 2010
Advertisement
Table of Contents
Related Manuals for Zenoah G800BPU
Summary of Contents for Zenoah G800BPU
- Page 1 • This engine is designed to be used to Radio controlled products. • In case any modification by customer, ZENOAH shall not bear any responsibility from the damage caused by such modification. • Keep ignition system well maintained. September 2010...
- Page 2 1. Safety Precautions • This manual describes the engine. For its mounting and control, see the instruction manual for a radio controlled airplane. • This engine is designed for use on the radio controlled airplane. If it is used for any other purpose, we cannot be responsible for its reliability or safety.
- Page 3 [ NOTE ] 1. Be sure to use a gasoline-resistant fuel piping. (Do not use any silicon rubber tube). 2. Never use any alcohol fuel or alcohol added fuel, or the rubber part in the carburetor will be damaged. 5. Operation 1.
- Page 4 counterclockwise decreases the idling R.P.M Low Speed Needle: This is the fuel adjust screw (not the air screw). Turning this needle clockwise makes the mixture gas leaner and turning it counterclockwise makes it richer. High Speed Needle: Turning this needle clockwise makes the mixture gas leaner and turning it counterclockwise richer.
- Page 5 2. Put the stopper (P/N.2670-96220) into a sparkplug hole (Fig.1) of the cylinder(✽) which is located closer to the rotor than other cylinder when viewed from intake manifold side (Fig.2). (✽) Stopper Fig. 2 Fig. 1 3. Turn the rotor counterclockwise until piston touches the stopper. 4.
- Page 6 10. Specifications Model ..........G800BPU · G800BPU-1 Type ..........Air cooled two stroke cycle opposed cylinder type gasoline engine Displacement ........79.9cc (4.88cu. in) Bore x Stroke x Number of cylinder ..40.5mm x 31mm x 2 (1.60 in x 1.22 in x 2 ) Compression ratio ......8.1 : 1 Maximum output ......5.52kW/10000rpm [4.41kW/10000rpm with Muffler] Operating engine speed ....1800 ~ 10000rpm...
- Page 7 G800BPU, G800BPU-1 Q' ty Q' ty Index Index Parts No. Description Parts No. Description /unit /unit T2080-12110 Cylinder 2670-21250 • Elbow T2080-14110 Manifold 1065-81100 • Pipe 2850-14123 Gasket, inlet 2898-21310 Gasket, crankcase 3310-72150 Bolt 01252-30520 Bolt 2898-81000 Carburetor assy, WJ-64 T2002-41110 Piston 3304-81441 •...
- Page 8 5) Exempt from Warranty Zenoah shall not warrant this engine even if the fault has been caused during the period of terms of Warranty, in case that. 1. Any faults, failures caused from neglect of proper operation and maintenance described in OWNER’S MANUAL.
