Summary of Contents for Electrolux ERES3500
- Page 1 INSTRUCTION BOOKLET ERES3500, ERES3500X 818 38 23--00/7...
-
Page 2: Table Of Contents
. In order to ensure reliable functioning, only an Electrolux Cylinder may be used. Do not keep explosive gases or liquids in the · refrigerator or freezer compartment. They may explode and cause injury and material damage. -
Page 3: Description Of The Appliance
Switches the refrigerator on and off. B. Temperature display Shows the average temperature inside the refrigerator. C. Temperature adjustment buttons/thermostat Used to set the temperature in the refrigerator. D. ACTION COOL button Used to switch the Action Cool feature on and off. Modell ERES3500/ERES3500X grid... -
Page 4: Control Panel (Water Dispenser)
Check that the drain hose is located over the drip bowl behind the refrigerator. Also ensure that the drain hose is connected to the box. See the illustration. Before inserting the power plug into the socket and ·... -
Page 5: Temperature Inside The Fridge
When this function has been activated forced air will chill the groceries, and the temperature in the cabinet reset to +2°C. After 6 hours the Quick chill automatically shuts off and the temperature gradually goes back to its normal setting. ACTION COOL Electrolux 8183823-00/7 ACTION COOL... - Page 6 The lighting then goes on with about 50 % of its full intensity. To switch off the lighting: 1. Ensure that the water dispenser is unlocked. 2. Then hold the button for ordinary water (J) pressed in for about three seconds until the lighting goes out. Electrolux 8183823-00/7...
-
Page 7: Switching Off
The wire baskets The refrigerator is fitted with two wire baskets, which can be lifted out and provide space in front of the service cover. The wire baskets can al so be used for bottles/foods- tuffs or as "breakfast baskets". -
Page 8: Hints And Tips
· labelled and used in date order to ensure that food is consumed at its best. Remove suspect food from you refrigerator and clean, refer to cleaning and maintenance. Normal Operating Sounds You may hear faint gurgling or bubbling sounds ·... -
Page 9: Maintenance And Cleaning
When moving the cabinet, lift it by the front edge to avoid scratching the floor. When the refrigerator is to be used again, rinse the system through thoroughly by draining off at least three litres (5 pints) of water. Before re-fitting the filter, all its parts must be thoroughly thawed out. -
Page 10: Service During Operation
See the section "When starting the water system for the first time". The water connection does not need to be switched off when changing the filter. Replacement filters can be ordered from Electrolux Service Force Centre. See the section "Service and spare parts". -
Page 11: Something Not Working
Set a lower temperature. Put food products in the right place inside the refrigerator. See the chapter "Temperature inside the refrigerator". Distribute the food products to allow cold air to circulate around them. -
Page 12: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. Customer Care Department For general enquiries concerning your Electrolux appliance or further information on Electrolux products, you are invited to contact our Customer Care Department by letter or phone as follows or visit our website at www.electrolux.co.uk... -
Page 13: Technical Specification
Technical Specification Model ERES3500/ERES3500X Volume Refrigerator 311 l Width 595 mm Height 1800 mm Depth 650 mm Energy consumption 175 kWh/år Energy class Rated power 70 W Permissible water pressure ensure reliable function) The total flow in the system can vary, depending on local water conditions and/or water pressure. -
Page 14: Cleaning
If you require a longer water hose than that supplied, then a VDE-approved 150 38 85-02/0 supply hose should be used. Before the refrigerator is taken into use in its final location, ensure that the water connection has been correctly carried out, that there is no leakage at the... -
Page 15: Electrical Cord
Check that the drain hose at the rear of the appliance discharges into the drip tray. The power plug must be accessible after installation of the appliance. Electrolux 8183823-00/7 50mm... -
Page 16: When The Water System Is Started For The First Time
Open the tap on the water connection and start up the refrigerator. The water system main valve opens and the system starts to fill up. Wait for five minutes. -
Page 17: Electrical Connection
The wire coloured brown must be connected to the terminal marked "L" or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cord clamp must be secure over the outer sheath. Electrolux 8183823-00/7... - Page 18 Electrolux 8183823-00/7...
- Page 19 Electrolux 8183823-00/7...
- Page 20 MARIESTAD DT-AV...
