Appendix C
Preshared Key
6. This new Preshared key will be displayed. Click the
Apply button to continue, if it appears on your screen;
otherwise, proceed to the next step.
New Preshared Key
7. Select the Tunnel Setting tab, and click The tunnel
endpoint is specified by this IP Address radio button.
Then, enter the Router's WAN IP Address.
Tunnel Setting Tab
8. Select the Connection Type tab, and click All network
connections. Then, click the OK or Close button to
finish this rule.
4-Port Gigabit Security Router with VPN
Configuring IPSec with a Windows 2000 or XP Computer
Tunnel 2: Router->win
9.
10.
11.
Connection Type Tab
In the new policy's Properties screen, make sure
that win -> Router is selected and deselect the Use
Add Wizard check box. Then, click Add to create the
second IP filter.
Properties Screen
Go to the IP Filter List tab, and click the filter list
Router->win.
IP Filter List Tab
Click the Filter Action tab, and select the filter action
Require Security. Then, click Edit. On the Security
Methods tab, verify that the Negotiate security
option is enabled, and deselect the Accept unsecured
communication, but always respond using IPSec
check box. Select Session key Perfect Forward
Secrecy, and click OK.
