- Page 1 SW8000 SW8000 SW8000 SW8000 SW8000 • Professional Reference Sub-Woofer Monitor • User’s Manual www.esi-pro.com END USER WARRANTY...
- Page 2 The purchaser must contact EGO SYSTEMS INC. or its regional representative to receive prior approval before returning a faulty unit. To obtain warranty service, the buyer or his authorized dealer must send an email to techsupport@esi-pro.com before returning the product. EGO SYSTEMS INC. will then issue an authorization number.
-
Page 3: Table Of Contents
Contents ..........................3 Contents Introduction ........................4 ....................... 5 SW8000 Features Subwoofer ........................ 5 Sub-frequency Port ..................... 5 Enclosure ........................5 Network & POWER AMPLIFIERS ................5 .......................... 6 Installation Precautions ....................... 6 ........................6 Handling ....................... 6 Connection XLR BALANCED Connection ..................6 TRS Balanced/Unbalanced Connection ................ -
Page 4: Introduction
Introduction Thank you for choosing SW8000, neo-standard reference sub-woofer monitor speaker. ESI has been building excellent reputation for digital interfaces and near Field monitor speaker manufacturer. Now, after long research and development, SW8000 is born to change the concept of reference sub-woofer monitoring. -
Page 5: Sw8000 Features
SW8000 Features 1. S UBWOOFER Subwoofer unit is 8 inch in diameter with mineral filled polypropylene cone with high temperature voice coil and damped rubber surround. It is designed to deliver balanced subwoofer response. Polypropylene is used to react against the input signal accurately and to deliver even minimal input precisely minimizing distortion. -
Page 6: Installation
Installation For optimal performance of SW8000, read below thoroughly and carefully before start installation. 1. P RECAUTIONS Handling Do not grab the speaker driver unit: SW8000 is packaged in box fitted tight, so your attention is required when taking speakers out of the box. To avoid the possible damage to the speaker driver unit, hold both sides of the speaker to pull out of the box. -
Page 7: Trs Balanced/Unbalanced Connection
3. TRS B ALANCED NBALANCED ONNECTION Assure that power switch of SW8000 is turned off and Volume Control of SW8000 is turned to minimum. Connect the Male side of TRS balanced or unbalanced cables to the TRS input of SW8000. Refer to the following diagram. -
Page 8: Connecting To The Satellite Speakers
5. C ONNECTING TO THE SATELLITE SPEAKERS Subwoofer SW8000 can be connected to your Professional Audio system in two different ways: a. Connect SW8000 Left or Right Input to Subwoofer output of Professional Audio Console with Bass Management. Professional Audio Console (With Base Management) Satellite-L Subwoofer... -
Page 9: Position Of The Subwoofer In The Studio
6. P OSITION OF THE UBWOOFER IN THE TUDIO In theory, the best position for Subwoofer is midway between the satellite speakers, with its front facing forward and in the same plane as the fronts of the satellite speakers. Subwoofer SW8000 may, however, due to the very low distortion by design, so there is no directional sound field from SW8000, in practice be moved quite far from this position without any detrimental effect on the sound reproduction. - Page 10 Moving the turntable or the speakers may remedy this problem. Or try placing an anti- vibration pad under the turntable. a. Level setting With the “Level” control the volume of the subwoofer is set to properly match the satellite speakers. You can start with setting at 12 O’clock position of Level Control. If the Subwoofer is placed on the floor against one wall in a normal room, the Subwoofer sound pressure could be increased 3dB than placed on the freestanding floor.
- Page 11 management, the Satellites control should be set together with upper frequency limit of Subwoofer Control. If your satellites are properly damped at the bass response, the control should be selected to the same frequency for Satellites control and Subwoofer Control. If your satellite speakers are under-damped (“Boomy”), the control should be set to a higher frequency and if they are over-damped (“dry”), a lower setting is best.
-
Page 12: Technical Specifications
Technical Specifications - Type: Powered Subwoofer -Subwoofer Driver: 8" mineral filled polypropylene curved cone with high temperature voice coil and damped rubber surround. - Frequency Response: 30Hz - 180Hz, Adjustable 50Hz – 180Hz - Amplifier Power: 100W@100Hz, 4 ohm, 0.1% THD - Dynamic Power: 120W - S/N Ratio: >... -
Page 13: Block Diagram
SW8000 SW8000 SW8000 SW8000 SW8000 Suite 1003, Shinhan Bldg. 45-11 Yoido-dong, Youngdungpo-gu Seoul, Korea Tel: +82 2 780 4451 ~ 3 Fax: +82 2 780 4454 Web site : www.esi-pro.com...
