Summary of Contents for Electrolux EDB 876
- Page 1 Model EDB 876...
-
Page 2: Important Safety Information
Never place plastic or any other material which may melt in or on the oven. Do not stand too close to the oven or grill while in use as warm air will exhaust from the grill cavity and the vents on the front frame of the appliance. -
Page 3: Table Of Contents
The Grill Pan and Handle Hints and Tips Grilling Chart The Top Oven Uses of the Top Oven Preheating How To Light the Top Oven Things To Note To Fit the Top Oven Shelf Hints and Tips Top Oven Cooking Chart The Main Oven... -
Page 4: Description Of The Appliance
WARNING: THIS APPLIANCE MUST BE EARTHED AND PROTECTED BY A 3 AMP FUSE Top Oven / Grill Your built in appliance comprises of a gas oven and grill in the top compartment. The top oven is convenient and economical for mid-week use because of its size. -
Page 5: Getting To Know Your Oven
GETTING TO KNOW YOUR OVEN The Control Panel Electronic Timer Grill / Top Oven Control Main Oven Control... -
Page 6: The Cooling Fan For The Controls
The cooling fan will come on immediately when the top oven or grill is switched on and after a short time when the main oven is in use. The cooling fan may run on after the ovens or grill are turned off for a period of time to cool the appliance down. -
Page 7: Before Using The Appliance
If the fuse keeps failing there is a fault in the oven which must be put right. Do not use a fuse with a rating higher than 3 amps. Do not carry out other electrical work. Unplug the oven and tell your installer. -
Page 8: Condensation And Steam
'Hints and Tips' in the appropriate oven section. If using a baking tray larger than 30cm x 25cm (12" x 9") in the top oven you may need to turn it round during cooking. -
Page 9: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of oven furniture have been supplied with the appliance. 1 grill pan 1 grill pan handle 1 grill pan grid 1 meat tin 2 shelves for main oven cooking 1 shelf for grilling and... -
Page 10: The Electronic Timer
Please note that this is a 24 hour clock, for example 2pm is shown as 14.00. If the oven is switched off on the wall or there is loss of power the clock will stop and you will not be able to use the appliance. When you first switch the electricity supply on, the timer display will flash. - Page 11 09.00 hours (9.00am) the latest 'Stop' time will be 08.59 (8.59am) the next day. 5. Turn the oven control to mark 9 then to the required setting. The clock will work out what time the oven will switch itself on and will switch the oven off at the end.
-
Page 12: Returning The Appliance To Manual
AUTOMATIC PROGRAMME Once automatic cooking is complete an alarm will sound and the Auto symbol will flash to remind you that the oven needs to be set for manual operation. 1. To do this press buttons After a few seconds the timer will show the time of day. -
Page 13: The Grill
HOW TO LIGHT THE GRILL 1. Open the Grill / Top Oven door. 2. Push in the grill / top oven control and turn it clockwise to the highest setting. This is shown by a large flame symbol. -
Page 14: The Grill Shelf
The shelf should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. When using the grill pan in positions 2 and 3 the shelf must be withdrawn before the pan can be located or removed. -
Page 15: Hints And Tips
The grill compartment can be used to warm plates when the main oven is on. Do not place plates to warm under the grill when it is lit as this may damage the plates. -
Page 16: Grilling Chart
Place food towards the centre of the grilling grid. If food is outside this area it may require rotating during cooking. Food such as tomatoes and mushrooms requiring gentle heat should be placed towards the edge of the grid. Place foods such as Shepherds pie and cauliflower cheese on the grill shelf to brown. -
Page 17: The Top Oven
HOW TO LIGHT THE TOP OVEN 1. Open the grill / top oven door. 2. Push in and turn the top oven / grill control to the left to Gas mark 8. When the burner has lit there will only be small flames at first. -
Page 18: To Fit The Top Oven Shelf
TO FIT THE TOP OVEN SHELF There are 3 shelf positions in the top oven. Shelf positions are counted from the top downwards. The shelf should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. -
Page 19: Top Oven Cooking Chart
TOP OVEN COOKING CHART The Gas mark settings are intended as a guide only. It may be necessary to increase or decrease the settings to suit individual preferences and requirements. Note: Shelf positions are counted from the top downwards. FOOD... -
Page 20: The Main Oven
HOW TO LIGHT THE MAIN OVEN 1. Open the oven door. 2. Push in the main oven control and turn it to gas mark 9. 3. Adjust the control to the required gas mark setting. -
Page 21: To Fit The Main Oven Shelves
TO FIT THE MAIN OVEN SHELVES There are 14 shelf positions in the main oven. Shelf positions are counted from the top downwards. The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. - Page 22 For economy leave the door open for the shortest possible time, particularly when placing food into a pre-heated oven. ROASTING For best results we recommend open roasting using minimal fat or oil to prevent splashing. It is not necessary to cover meat or poultry or...
-
Page 23: Main Oven Cooking Chart
The Gas mark settings are intended as a guide only. It may be necessary to increase or decrease the settings to suit individual preferences and requirements. Note: Shelf positions are counted from the top of the oven downwards. FOOD Viennese Biscuits... -
Page 24: Slowcook Feature
HOW TO USE SLOWCOOK 1. Open the main oven door. 2. Push in the main oven control and turn it to gas mark 9. When the burner has lit there will only be small flames at first. - Page 25 Cook stuffing separately. Do not Slowcook more than one 2lb (1kg) meat stew in the oven at the same time when slow cooking. Thicken after cooking with a little cornflour and water if desired. All frozen meat/poultry should be thoroughly thawed before preparing for slow cooking.
- Page 26 PASTA AND RICE Cook pasta on the hob and add to the dish at the end of the cook time. Rice should be the 'easy cook' type. Use 250ml (½ pint) stock to 100g (4oz) rice. Cooking time up to 6 hours. DRIED BEANS AND FRUIT Soak overnight prior to cooking.
-
Page 27: Care And Cleaning
Regularly wipe over the control panel and oven doors using a soft cloth well wrung out in warm water to which a little washing up liquid has been added. -
Page 28: Cleaning The Outer And Inner Door Glass Panels
TO REMOVE THE OUTER 1. Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. 2. Loosen the two screws using a Pozidrive screwdriver. -
Page 29: Cleaning Inside The Ovens
2. Holding the door glass with your left hand, use your right hand to open the oven door. Bring the door gently towards the glass panel ensuring the screw location holes line up. -
Page 30: To Remove The Wirework Runners
The grill pan and meat tin can be cleaned using a soap impregnated steel wool pad. All items of grill and oven furniture are dishwasher safe with the exception of the grill pan handle. CARE OF STAYCLEAN SURFACES The top and sides of both ovens are coated with a Stayclean finish. -
Page 31: The Oven Cleaning Cycle
THE OVEN CLEANING CYCLE 1. Remove oven shelves, wirework runners and bakeware from oven. 2. Push in and turn the oven control to mark 5 for 30 minutes. 3. Turn the temperature up to mark 7 for 2 hours or until the oven is presentably clean. -
Page 32: Replacing An Oven Light Bulb
Edison Screw. 1. Make sure the appliance is cool before you replace a bulb. 2. Open the oven door and remove the shelves and wirework runners. Instructions on how to remove the wirework runners are given on page 30. -
Page 33: Something Not Working
Check that there has not been a power failure. If the electricity supply has been interrupted or you have switched the oven off at the wall, the grill may have cut out before the cooling fan has cooled the appliance down. Switch the appliance on at the wall until the cooling fan has cooled it down. - Page 34 The oven light bulb may need replacing see page 32. If the Main Oven is set for automatic cooking the light will illuminate when the cook time begins. Check that the recommended Gas mark settings and shelf positions are being used.
-
Page 35: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department... -
Page 36: Guarantee Conditions
GUARANTEE CONDITIONS Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will,... -
Page 37: Technical Details
TECHNICAL DETAILS Loading Info: Grill Burner Heat Input Injector Marking Top Oven* Heat Input Injector Marking Flame Supervision Device Thermostat Thermostat By-Pass Marking Main Oven Heat Input Injector Marking Flame Supervision Device Thermostat Thermostat By-Pass Marking Oven Light: Control Cooling Fan... -
Page 38: Things You Need To Know
This appliance must be earthed. Do not remove the screws from the earth tab extending from the oven mains terminal block (Fig. 1). Before connecting the appliance make sure that the gas type and the voltage of your electricity supply is the same as that indicated on the rating plate. -
Page 39: Getting Things Ready
The adjacent cabinets must be stable and firmly secured to the wall or floor. If necessary, make arrangements to ensure the work surface below which the oven will rest is level. Mark the centre of the aperture into which the appliance is to be fitted onto the plinth board. -
Page 40: Flexible Pipe Installation
INSTALLATION INSTRUCTIONS FLEXIBLE PIPE INSTALLATION FITTING THE APPLIANCE AND CABINET It is recommend that a /8", 1100mm long angled flexible hose (BFS), and a ½" straight socket (BFS) be used for the installation. However, any approved hose of the right length can be used. -
Page 41: Making The Electrical Connections
INSTALLATION INSTRUCTIONS CONNECTION TO ELECTRICITY SUPPLY WARNING: This appliance must be earthed, do not earth this appliance to the gas supply piping. This appliance must be connected to a isolated 220V-240V a.c. 50Hz incorporates a 3 ampere fuse. If any other type of plug is used it should incorporate a 5 ampere fuse in either the plug or adapter or at the distribution board. -
Page 42: Checking Electrical Connections
CHECKING ELECTRICAL CONNECTIONS Confirm the appliance is correctly connected by switching on and observing the various oven functions . The electronic timer will flash on and off. NOTE: HOUSE CIRCUIT Earth leakage / continuity tests must be carried out before the appliance is connected to the mains supply and re-checked after fitting. -
Page 43: Pressure Testing
3 When the oven burner lights up the sparking should cease, there should be a low gas rate at first to the oven burner which is the flame supervision device (F.S.D.) by pass rate. 4 When the F.S.D. phial has heated up it opens the F.S.D. - Page 44 N O T E S...
- Page 45 N O T E S...
- Page 46 N O T E S EDB876 - 311461706...
- Page 47 N O T E S...
- Page 48 This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. ELECTROLUX 55 - 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ TELEPHONE 0870 5 950950 Part Number: 311461706 © Electrolux Household Appliances Limited 2001...
