- Page 1 CVHF – Powered SUbwooFerS For HoMe User Manual...
- Page 2 First off, you have great taste in loudspeakers. At In order to obtain warranty service, contact your original Cerwin-Vega!, deep bass and great highs are a way of life. dealer or distributor, or an Authorized Cerwin-Vega! Service Nice to know there are a few people out there who share our Center.
-
Page 3: Important Safety Instructions
iMPortant SyMbolS and SaFety inStrUCtionS Explanation of Graphic Symbols Important Safety Instructions Read and keep these instructions. The exclamation point within an equilateral triangle is intended to alert the users to the presence of Heed all warnings and follow instructions. important operating and maintenance (servicing) instructions in the literature accompanying the Do not use this apparatus near water. -
Page 4: Table Of Contents
Built-in Amplifier Precautions Do not attempt to service this unit beyond instructions contained in this manual. Refer all servicing to a Cerwin-Vega! / Stanton Authorized Service Center. Servicing is required when the apparatus has been damaged in any way, such as power-supply input connector is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. -
Page 5: Overview Of Controls
Cerwin-Vega! CVHF - Powered Subwoofers for Home oVerView oF ControlS (Figure 2.1) indiCatorS: Illumination of LED indicates status of amplifier. - Power = electric current is live and present in the system - Limit = the system is being driven to its maximum capacity... -
Page 6: Placing The Subwoofer
Cerwin-Vega! CVHF - Powered Subwoofers for Home PlaCing tHe SUbwooFer (Figure 3.1) Proper placement of your subwoofer will result in the best musical and home theater experience. Thankfully, subwoofer placement is not difficult. Subwoofers reproduce low-frequency audio. Low frequencies are not as directional as high frequency signals, so unlike placing high-frequency speakers subwoofers can usually be placed anywhere in the room. -
Page 7: Wiring The Subwoofer
Cerwin-Vega! CVHF - Powered Subwoofers for Home wiring tHe SUbwooFer option 1: lFe (Figure 4.1) From AV Receiver From Amp LFE Out Speakers Left Line Level Input Figure 4.1 option 2: line level input (no lFe) (Figure 4.2) From Amp Line Level Out L/R... - Page 8 Cerwin-Vega! CVHF - Powered Subwoofers for Home option 3: adding and additional sub (Figure 4.3) Connect Link Out Left Input Figure 4.3 note: XLR connections can be used in place of the RCA.
-
Page 9: Troubleshooting
Cerwin-Vega! CVHF - Powered Subwoofers for Home troUbleSHooting Symptoms Causes Solutions Bass sounds distorted Amplifier is at maximum output Lower volume or receiver level control Receiver tone controls are set too high Set bass flat; use tone controls sparingly Distortion with volume control near... -
Page 10: Specifications
Cerwin-Vega! Powered Subwoofers for Home SPeCiFiCationS Subwoofer CVHF-a21S CVHF-a18S description 21 inch Active Subwoofer 18 inch Active Subwoofer Frequency response 35 Hz - 120 Hz 36 Hz - 120 Hz Frequency range (-10 dB) 1: 28 Hz – 150 Hz (-10 dB) 1: 28 Hz –... - Page 11 Cerwin-Vega! Powered Subwoofers for Home noteS .......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
