Audiovox AS9233ST Owner's Manual

Remote Start Alarm Keyless Entry
Congratulations on your purchase of this automotive Remote Start / Alarm Keyless Entry
Upgrade System. This system is a state - of - the - art system is designed to arm and disarm
when it receives a lock or unlock command from your existing Factory Keyless Entry
Transmitter. Taking a few moments to read this manual will help to ensure that your vehicle
is protected at all times.
NOTE:
The system has the ability to beep the vehicle's horn, sound a siren, or both. Where a beep
or chirp is mentioned, consider either or both may sound.
Also All functions of the system will be controlled by the factory transmitter, including the start
sequence however for optimum range, it is suggested that the one button transmitter supplied
be used for starting, and unlocking while running under control of the the remote start.
ARMING THE SYSTEM: ( ACTIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. Press and release the Lock button on the keychain transmitter.
3. The siren and or horn will beep one time, the parking lamps will flash one time,
and the LED found on the glass mounted receiver will begin to slowly flash, indicating that
the system is ARMED.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection. If the siren "chirped"
three times, sometime after arming, the exclusive delayed dome light learn circuit
has been programmed and the system detected a open entry point after the
learned delay expired. Again, closing the hood, trunk, or doors will correct the
problem and you do not need to disarm the system to make the correction. If the
siren/horn did not sound when arming, then the chirps have been turned off, and
you should refer to the section titled " ELIMINATING THE ARM / DISARM CHIRPS "
in this manual.
4. Any time the door lock switch in the vehicle is used to lock the doors while
the ignition key is turned off, the system will immediately arm. To lock the doors
after entering the vehicle, make sure the ignition key is switched on first.
Turning the ignition key on first will stop the system from arming.
ARMING THE SYSTEM: ( PASSIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. The LED will begin to flash rapidly, indicating that the system
is automatically ( passively ) arming. As an added convenience, the 30
second automatic passive arming will not begin until all doors are closed,
allowing passengers to exit the vehicle at their convenience.
3. In 30 seconds, you will hear a single short chip from the siren, and the vehicle's
parking lamps will flash one time, indicating that the system has ARMED. At
this time, the dash mounted PRLED will begin to flash slowly, providing a
visual indication that the system is fully armed.
4. It is possible to program the system, that when the alarm is allowed to
automatically passive arm, there will be a 15 second delay after a door is
opened before the alarm will sound. However, if the system is programmed
for instant trigger there will be no delay. Check with your installer for the setting
of this feature.
Model AS9233ST
OWNER'S MANUAL
Upgrade System
128-8604
1 of 8
