- Page 1 - f r e e z e r INSTRUCTION BOOK ERN 2820 2222 032-56...
- Page 3 Before use Setting the temperature The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes Fresh food refrigeration Normal operating sounds Movable shelves Positioning the door shelves Internal cleaning When the appliance is not in use External cleaning...
- Page 4 (where applicable). In the event of a power cut the food in the freezer will not be affected if the power cut is short and if the freezer is full. Do not open the door. Should the food begin to thaw, it must be consumed quickly and must not be re-frozen.
- Page 5 Ice Iollies, if consumed immediately after removal from the freezer, can cause low temperature skin burns. Do not remove items from the freezer if your hands are damp/wet, as this could cause skin abrasions or “frost/freezer burns”. Frozen food, prior to being used, can be thawed in the fridge or at room temperature depending on the time available.
- Page 6 The walls of the refrigerator have runners so that the shelves can be positioned as desired . For better use of space, the front half-shelves can lie over the rear ones. D338 To permit storage of food packages of various sizes, the door shelves can be adjusted in height.To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows...
- Page 7 Remove suspect food from your refrigerator and clean, refer to ‘Maintenance and Cleaning’. • Ensure that food placed in the freezer is dated and labelled and used in date order to ensure that food is consumed at its best. •...
- Page 8 Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. When the appliance is not in use for long periods, disconnect from the electricity supply, empty all foods and clean the appliance, leaving the doors ajar to prevent unpleasant smells.
- Page 9 «OFF» position (O) or disconnect the appliance from the mains. Remove any food from inside the freezer and fridge, wrap it in several sheets of newspaper and store in a cool,dry place.
- Page 10 Service Force Centre, check the following points: No power to the appliance The light does not come on The temperature in the fridge or freezer section is too high The freezer door will not open The compressor runs continously...
- Page 11 During a normal night time period of approximately 8 hours a traditional fridge freezer can normally maintain the frozen food temperature but if the appliance is left for longer period in a low ambient the freezer will defrost . If, after the above checks, there is still a fault, call your local Service Force Centre.
- Page 12 We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
- Page 13 This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 160 W 1.10 kWh Fridge 173 l Freezer 110 l Fridge 170 l Freezer 92 l...
- Page 14 IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
- Page 15 The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Electrolux Service Force Centre. This appliance complies with the following E.E.C. Directives: (Low Voltage Directive) and subsequent modifications;...
- Page 16 1. Unscrew the upper pin and remove the spacer 2. Remove the upper door 3. Unscrew the middle hinge and the brackets and refit them on the opposite side 4. Refit the upper door, the upper pin and the spacer on the opposite side 5.
- Page 17 Push appliance into housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 18 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied.
- Page 19 PR168 PR167/1 D734...
