Summary of Contents for Electrolux ER 8133 I
- Page 1 - f r e e z e r INSTRUCTION BOOK ER 8133 I 2222 345-75...
-
Page 2: Important Safety Information
¥ Do not place carbonated or fizzy drinks in the freezer. ¥ Do not remove items from the freezer if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns. ¥ Ice lollies can cause Ôfrost/freezer burnsÕ if con- sumed straight from the freezer. -
Page 3: Table Of Contents
CONTENTS Instructions for the User Important Safety Information Description of the Appliance Operation Before use Setting the temperature The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes Fresh food refrigeration Normal operating sounds Movable shelves Positioning the door shelves... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A - Thermostat control for fridge and freezer compartments B - Dairy compartment C - Can storage shelves D - Can storage shelves E - Bottle storage shelf F - Compartments for frozen food storage G - Compartment for freezing fresh foods... -
Page 5: Operation
Caution In the event of a power cut do not open the door. The food in the freezer will not be affected if the power cut is short and if the freezer is full. Should the food begin to thaw, it must be consumed quickly and must not be re-frozen . -
Page 6: Thawing
The appliance is provided with one or more trays for ice-cubes trays. Fill the tray(s) 3/4 full to give the ice space to expand and place them in the freezer compartment. To release the ice cubes simply give the tray a slight twist. -
Page 7: Movable Shelves
Movable shelves The walls of the refrigerator have runners so that the shelves can be positioned as desired . For better use of space, the front half-shelves can lie over the rear ones. D338 Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height.To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows... -
Page 8: Hints And Tips
Remove suspect food from your refrigerator and clean, refer to ÔMaintenance and CleaningÕ. ¥ Ensure that food placed in the freezer is dated and labelled and used in date order to ensure that food is consumed at its best. ¥... -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX... - Page 10 ÇOFFÈ position (O) or disconnect the appliance from the mains. Remove any food from inside the freezer and fridge, wrap it in several sheets of newspaper and store in a cool,dry place. Leave the door openand insert the ice scraper under the channelin the centre of the lower part of the appliance;...
-
Page 11: Something Not Working
Before contacting your local Service Force Centre, check the following points: Symptom No power to the appliance The light does not come on The temperature in the fridge or freezer section is too high The freezer door will not open The compressor runs continously... -
Page 12: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 13: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 14: Technical Specification
This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 160 W 1.10 kWh Fridge 214 l Freezer 76 l Fridge 210 l Freezer 70 l... -
Page 15: Installation
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 16: Electrical Connection
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Electrolux Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression. -
Page 17: Door Reversal
Instructions for totally built-in appliances Door reversal The appliance is supplied with the right or left door opening. To change the opening direction of the door proceed as in the following instructions before installing it. 1. Unscrew the upper pin and remove the spacer 2. - Page 18 Push appliance into housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 19 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, in the upper and lower position as shown in the figure and mark the position of external holes. Having drilled the holes, fix the guide with the screws supplied.
- Page 20 Should adjustment of the furniture door be necessary, use the clearance of slots as required. At the end of operations, it is necessary to check if the door of the furniture closes properly. Fix cover (D) on guide (B) until it clips into place. If the appliance is fixed to the side of the kitchen unit, simply slacken the screws in fixing brackets (D), move the brackets as shown in the figure and re-...
- Page 24 © Electrolux Household Appliances Limited 2002...
