GA-M61PM-S2
AMD Socket AM2 Processor Motherboard
User's Manual
Rev. 1001
12ME-M61PMS2-1001R
* The WEEE marking on the product indicates this product must not be disposed of with user's other household waste
and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!
* The WEEE marking applies only in European Union's member states.

Advertisement

Table of Contents
loading

Related Manuals for AMD GA-M61PM-S2

Summary of Contents for AMD GA-M61PM-S2

  • Page 1 GA-M61PM-S2 AMD Socket AM2 Processor Motherboard User's Manual Rev. 1001 12ME-M61PMS2-1001R * The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!
  • Page 3 Copyright © 2006 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved. The trademarks mentioned in the manual are legally registered to their respective companies. Notice The written content provided with this product is the property of Gigabyte. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without Gigabyte's prior written permission.

  • Page 4: Table Of Contents

    Table of Contents Item Checklist ......................... 6 Optional Accessories ...................... 6 GA-M61PM-S2 Motherboard Layout ................7 Block Diagram ........................ 8 Chapter 1 Hardware Installation ..................9 Considerations Prior to Installation ..............9 Feature Summary ..................10 Installation of the CPU and CPU Cooler ............12 1-3-1 Installation of the CPU ..................
  • Page 5 Chapter 3 Drivers Installation ..................45 Install Chipset Drivers ..................45 Software Applications ..................46 Driver CD Information ..................46 Hardware Information ..................47 Contact Us ..................... 47 Chapter 4 Appendix ....................49 Unique Software Utilities ................49 4-1-1 EasyTune 5 Introduction ..................49 4-1-2 Xpress Recovery2 Introduction .................

  • Page 6: Item Checklist

    Item Checklist IDE Cable x 1 & FDD Cable x 1 SATA 3Gb/s Cable x 2 I/O Shield * The items listed above are for reference only, and are subject to change without notice. Optional Accessories 2 Ports USB 2.0 Cable (Part Number: 12CR1-1UB030-51/R) 4 Ports USB 2.0 Cable (Part Number: 12CR1-1UB030-21/R) 2 Ports IEEE 1394 Cable (Part Number: 12CF1-1IE008-01R) COM Port Cable (Part Number: 12CF1-1CM001-31/R)

  • Page 7: Ga-M61Pm-S2 Motherboard Layout

    GA-M61PM-S2 Motherboard Layout KB_MS ATX_12V Socket AM2 CPU_FAN IT8716 BIOS F_AUDIO AUDIO GA-M61PM-S2 PCIE_16 RTL8211 CLR_CMOS PCIE_1 SATAII2_3 BATTERY nVIDIA ® PCI1 GeForce 6100/ SATAII0_1 nForce 430 CD_IN F_USB2 PCI2 TSB43AB23 F_USB1 CODEC F_USB3 SYS_FAN F_PANEL F1_1394 F2_1394 COMB SPDIF_IO PWR_LED - 7 -...

  • Page 8: Block Diagram

    Block Diagram PCIe CLK CPU CLK+/-(200 MHz) (100 MHz) DDRII 800/667/533/400 MHz DIMM Socket AM2 Dual Channel Memory Hyper Transport Bus PCI Express x16 PCI Express x1 Bus 4 SATA 3Gb/s ATA33/66/100/133 nVIDIA ® PCIe CLK IDE Channel GeForce 6100/ (100 MHz) nForce 430 BIOS...

  • Page 9: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Considerations Prior to Installation Preparing Your Computer The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please follow the instructions below: 1.

  • Page 10: Feature Summary

    Feature Summary Socket AM2 for AMD Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon 64 / Sempron processor Front Side Bus 2000 MHz Chipset nVIDIA ® GeForce 6100/nForce 430 chipset Realtek RTL8211 (10/100/1000 Mbit) Audio Onboard Realtek ALC883 CODEC chip...
  • Page 11 Rear Panel I/O 1 PS/2 keyboard port 1 PS/2 mouse port 1 parallel port 1 VGA port 1 COMA port 4 USB 2.0/1.1 ports 1 IEEE 1394a port 1 RJ-45 port 6 audio jacks (Line In / Line Out / MIC In/Surround Speaker Out (Rear Speaker Out)/Center/Subwoofer Speaker Out/Side Speaker Out) I/O Control IT8716 chip...

  • Page 12: Installation Of The Cpu And Cpu Cooler

    Installation of the CPU and CPU Cooler Before installing the CPU, please comply with the following conditions: 1. Please make sure that the motherboard supports the CPU. 2. Please take note of the pin 1 marking (the small triangle) on the CPU. If you install the CPU in the wrong direction, the CPU will not insert properly.

  • Page 13: Installation Of The Cpu Cooler

    1-3-2 Installation of the CPU Cooler Fig.1 Before installing the CPU cooler, please first add an even layer of heat paste on the surface of the CPU. Install all the CPU cooler components (Please refer to the cooler manual for detailed installation instructions). Fig.2 Please connect the CPU cooler power connector to the CPU_FAN con- nector located on the motherboard so that the CPU cooler can properly...

  • Page 14: Installation Of Memory

    Installation of Memory Before installing the memory modules, please comply with the following conditions: Please make sure that the memory used is supported by the motherboard. It is recommended that memory of similar capacity, specifications and brand be used. Before installing or removing memory modules, please make sure that the computer power is switched off to prevent hardware damage.
  • Page 15 Dual Channel Memory Configuration The GA-M61PM-S2 supports the Dual Channel Technology. After operating the Dual Channel Technology, the bandwidth of Memory Bus will double. Due to CPU limitation, if you wish to operate the Dual Channel Technology, follow the guidelines below: 1.

  • Page 16: Installation Of Expansion Cards

    Installation of Expansion Cards You can install your expansion card by following the steps outlined below: 1. Read the related expansion card's instruction document before install the expansion card into the computer. 2. Remove your computer's chassis cover, screws and slot bracket from the computer. 3.

  • Page 17: I/O Back Panel Introduction

    I/O Back Panel Introduction PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. COMA (Serial Port) Connects to serial-based mouse or data processing devices.

  • Page 18: Connectors Introduction

    Line Out (Front Speaker Out) The default Line Out (Front Speaker Out) jack. Stereo speakers, earphone or front surround speakers can be connected to Line Out (Front Speaker Out) jack. MIC In The default MIC In jack. Microphone must be connected to MIC In jack. In addition to the default speakers settings, the audio jacks can be reconfigured to perform different functions via the audio software.
  • Page 19 1/2) ATX_12V/ATX (Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.
  • Page 20 3/4) CPU_FAN / SYS_FAN (Cooler Fan Power Connector) The cooler fan power connector supplies a +12V power voltage via a 3-pin/4-pin (only for CPU_FAN) power connector and possesses a foolproof connection design. Most coolers are designed with color-coded power connector wires. A red power connector wire indicates a positive connection and requires a +12V power voltage.
  • Page 21 6) IDE (IDE Connector) An IDE device connects to the computer via an IDE connector. One IDE connector can connect to one IDE cable, and the single IDE cable can then connect to two IDE devices (hard drive or optical drive).
  • Page 22 8) F_AUDIO (Front Audio Connector) This connector supports either HD (High Definition) or AC97 front panel audio module. If you wish to use the front audio function, connect the front panel audio module to this connector. Check the pin assignments carefully while you connect the front panel audio module. Incorrect connection between the module and connector will make the audio device unable to work or even damage it.
  • Page 23 9) F_PANEL (Front Panel Jumper) Please connect the power LED, PC speaker, reset switch and power switch etc. of your chassis front panel to the F_PANEL connector according to the pin assignment below. Speaker Connector Message LED/ Power Power/ Switch Sleep LED Reset Switch IDE Hard Disk Active LED...
  • Page 24 10) CD_IN (CD In Connector) Connect CD-ROM or DVD-ROM audio out to the connector. Pin No. Definition CD-L CD-R 11) PWR_LED The PWR_LED connector is connected with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. Pin No.
  • Page 25 12) F_ USB1 / F_USB2 / F_USB3 (Front USB Connector) Be careful with the polarity of the front USB connector. Check the pin assignment carefully while you connect the front USB cable, incorrect connection between the cable and connector will make the device unable to work or even damage it.
  • Page 26 14) COMB (COMB Connector) Be careful with the polarity of the COMB connector. Check the pin assignments while you connect the COMB cable. Please contact your nearest dealer for optional COMB cable. Pin No. Definition NDCDB- NSINB NSOUTB NDTRB- NDSRB- NRTSB- NCTSB- NRIB-...
  • Page 27 16) CLR_CMOS (Clear CMOS) You may clear the CMOS data to its default values by this header. To clear CMOS, temporarily short the two pins. Default doesn't include the jumper to avoid improper use of this header. Open: Normal Short: Clear CMOS 17) CI (Chassis Intrusion, Case Open) This 2-pin connector allows your system to detect if the chassis cover is removed.
  • Page 28 18) BATTERY Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. If you want to erase CMOS... 1. Turn off the computer and unplug the power cord. 2.

  • Page 29: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup BIOS (Basic Input and Output System) includes a CMOS SETUP utility which allows user to configure required settings or to activate certain system features. The CMOS SETUP saves the configuration in the CMOS SRAM of the motherboard. When the power is turned off, the battery on the motherboard supplies the necessary power to the CMOS SRAM.

  • Page 30: The Main Menu (For Example: Bios Ver. : D1)

    <F12> : Boot Menu Select boot sequence for onboard (or add-on cards) device. Award Modular BIOS v6.00PG, An Energy Star Ally Copyright (C) 1984-2006, Award Software, Inc. M61PM-S2 D1 <F12>: Boot Menu <DEL>:BIOS Setup/Q-Flash, <F9>: Xpress Recovery2, <F12>: Boot Menu 08/04/2006-NV-MCP61-6A61KG02C-00 Use <...
  • Page 31 Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Integrated Peripherals This setup page includes all onboard peripherals. Power Management Setup This setup page includes all the items of Green function features.

  • Page 32: Standard Cmos Features

    Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Standard CMOS Features Date (mm:dd:yy) Thu, Jun 17 2006 Item Help Time (hh:mm:ss) 22:31:24 Menu Level IDE Channel 0 Master [None] Change the day, month, IDE Channel 0 Slave [None] year IDE Channel 2 Master [None]...
  • Page 33 Access Mode Use this to set the access mode for the hard drive. The two options are: Large/Auto(default:Auto) Capacity Capacity of currently installed hard drive. Hard drive information should be labeled on the outside drive casing. Enter the appropriate option based on this information.

  • Page 34: Advanced Bios Features

    F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults AMD K8 Cool&Quiet control Auto AMD Cool'n'Quiet driver manages clock and VID to best serve the thermal, performance and power requirements. (Default value) Disabled Disable this function. Hard Disk Boot Priority Select boot sequence for onboard(or add-on cards) SCSI, RAID, etc.
  • Page 35 Password Check System The system can not boot and can not access to Setup page will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt.

  • Page 36: Integrated Peripherals

    Integrated Peripherals CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Integrated Peripherals Serial-ATA RAID Config [Press Enter] Item Help On-Chip IDE Channel0 [Enabled] Menu Level On-Chip MAC Lan [Auto] NV Serial-ATA Controller [All Enabled] IDE Prefetch Mode [Enabled] USB Memory Type [SHADOW] Onboard Audio Function [Auto]...
  • Page 37 NV SATA 2 Primary RAID Enabled Enable RAID function for the first channel of the second SATA 3Gb/s controller. (Default value) Disabled Disable this function. NV SATA 2 Secondary RAID Enabled Enable RAID function for the second channel of the second SATA 3Gb/s controller. (Default value) Disabled Disable this function.
  • Page 38 Onboard Serial Port 2 Auto BIOS will automatically setup the port 2 address. 3F8/IRQ4 Enable onboard Serial Port 2 and address is 3F8/IRQ4. 2F8/IRQ3 Enable onboard Serial Port 2 and address is 2F8/IRQ3. (Default value) 3E8/IRQ4 Enable onboard Serial Port 2 and address is 3E8/IRQ4. 2E8/IRQ3 Enable onboard Serial Port 2 and address is 2E8/IRQ3.

  • Page 39: Power Management Setup

    Power Management Setup CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Power Management Setup ACPI Suspend Type [S1(POS)] Item Help Soft-Off by Power button [Instant-Off] Menu Level PME Event Wake Up [Enabled] Modem Ring On [Enabled] USB Resume from Suspend [Disabled] Power-On by Alarm [Disabled] x Day of Month Alarm...

  • Page 40: Pnp/Pci Configurations

    Power On By Mouse Disabled Disabled this function. (Default value) Double-Click Double click on PS/2 mouse left button to power on the system. Power On By Keyboard Disabled Disabled this function. (Default value) Keyboard 98 If your keyboard have "POWER Key" button, you can press the key to power on the system.

  • Page 41: Pc Health Status

    PC Health Status CMOS Setup Utility-Copyright (C) 1984-2006 Award Software PC Health Status Reset Case Open Status [Disabled] Item Help Case Opened Menu Level Vcore DDR18V [Disabled] +3.3V Don’t reset case +12V open status Current System Temperature Current CPU Temperature [Enabled] Current CPU FAN Speed 3245 RPM...

  • Page 42: Load Fail-Safe Defaults

    CPU Smart FAN Mode This option is available only when CPU Smart FAN Control is enabled. Auto BIOS autodetects the type of CPU fan you installed and sets the optimal CPU Smart FAN control mode for it. (Default value) Voltage Set to Voltage when you use a CPU fan with a 3-pin fan power cable.

  • Page 43: Set Supervisor/User Password

    Set Supervisor/User Password CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Standard CMOS Features Load Fail-Safe Defaults Advanced BIOS Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup Enter Password: PC Health Status Exit Without Saving Esc: Quit...

  • Page 44: Save & Exit Setup

    2-10 Save & Exit Setup CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Standard CMOS Features Load Fail-Safe Defaults Advanced BIOS Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Save to CMOS and EXIT (Y/N)? Y Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 45: Chapter 3 Drivers Installation

    Chapter 3 Drivers Installation Pictures below are shown in Windows XP. Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the Run.exe.

  • Page 46: Software Applications

    Software Applications This page displays all the tools that Gigabyte developed and some free software, you can choose anyone you want and press "install" to install them. Driver CD Information This page lists the contents of software and drivers in this CD-title. GA-M61PM-S2 Motherboard - 46 -...

  • Page 47: Hardware Information

    Hardware Information This page lists all device you have for this motherboard. Contact Us Please see the last page for details. - 47 - Drivers Installation...
  • Page 48 GA-M61PM-S2 Motherboard - 48 -...

  • Page 49: Chapter 4 Appendix

    Chapter 4 Appendix Unique Software Utilities (Not all model support these Unique Software Utilities, please check your MB features.) 4-1-1 EasyTune 5 Introduction EasyTune 5 presents the most convenient Windows based system performance enhancement and manageability utility. Featuring several powerful yet easy to use tools such as 1) Overclocking for enhancing system performance, 2) C.I.A.

  • Page 50: Xpress Recovery2 Introduction

    4-1-2 Xpress Recovery2 Introduction Xpress Recovery2 is designed to provide quick backup and restora- tion of hard disk data. Supporting Microsoft operating systems including Windows XP/2000/NT/98/Me and DOS, and file systems including FAT16, FAT32, and NTFS, Xpress Recovery2 is able to back up data on hard disks on PATA and SATA IDE controllers.
  • Page 51 The Main Screen of Xpress Recovery2 1. RESTORE: Restore the backed-up data to your hard disk. (This button will not appear if there is no backup file.) 2. BACKUP: Back up data from hard disk. 3. REMOVE: Remove previously-created backup files to release disk space.

  • Page 52: Flash Bios Method Introduction

    4-1-3 Flash BIOS Method Introduction Method 1 : Q-Flash Utility Q-Flash is a BIOS flash utility embedded in Flash ROM. With this utility, users only have to stay in the BIOS menu when they want to update BIOS. Q-Flash allows users to flash BIOS without any utility in DOS or Windows.
  • Page 53 Entering the Q-Flash utility: Step1: To use Q-Flash utility, you must press Del in the boot screen to enter BIOS menu. CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Select Language Advanced BIOS Features Load Fail-Safe Defaults Integrated Peripherals Load Optimized Defaults Power Management Setup Set Supervisor Password...
  • Page 54 Using the Q-Flash utility: This section tells you how to update BIOS using the Q-Flash utility. As described in the "Before you begin" section above, you must prepare a floppy disk having the BIOS file for your motherboard and insert it to your computer.
  • Page 55 3. Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be displayed. Please do not take out the floppy disk when it begins flashing BIOS. 4.
  • Page 56 Press Del to enter BIOS menu after system reboots. When you are in BIOS menu, move to Load Optimized Defaults item and press Enter to load BIOS Optimized Defaults. Normally the system redetects all devices after BIOS has been upgraded. Therefore, we highly recommend reloading the BIOS defaults after BIOS has been upgraded.
  • Page 57 Exploring the Q-Flash utility screen The Q-FlashBIOS utility screen consists of the following key components. Q-Flash utility bar Q-Flash Utility V1.30 Flash Type/Size.........SST 49LF003A 256K Keep DMI Data Enable Task menu for Update BIOS from Floppy Q-Flash utility Save BIOS to Floppy Action bar Enter : Run :Move...
  • Page 58 Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be shown at the same time. Q-Flash Utility V1.30 Flash Type/Size.........SST 49LF003A 256K Keep DMI Data Enable Do not turn off power or Updating BIOS Now...
  • Page 59 Method 2 : @BIOS Utility If you do not have a DOS startup disk, we recommend that you use the new @BIOS utility. @BIOS allows users to update their BIOS under Windows. Just select the desired @BIOS server to download the latest version of BIOS.
  • Page 60 III. Save BIOS In the very beginning, there is "Save Current BIOS" icon shown in dialog box. It means to save the current BIOS version. IV. Check out supported motherboard and Flash ROM: In the very beginning, there is "About this program" icon shown in dialog box. It can help you check out which kind of motherboard and which brand of Flash ROM are supported.

  • Page 61: Configuring Sata Hard Drive(S)

    4-1-4 Configuring SATA Hard Drive(s) To configure SATA hard drive(s), follow the steps below: (1) Install SATA hard drive(s) in your system. (2) Configure SATA controller mode and boot sequence in BIOS Setup. (3) Configure RAID set in RAID BIOS. (Note ) (4) Make a floppy disk containing the SATA controller driver.
  • Page 62 (2) Configuring SATA controller mode and boot sequence in BIOS Setup Make sure to configure the SATA controller mode correctly in system BIOS Setup and set the first boot device. Step 1: Turn on your computer and press Del to enter BIOS Setup during POST (Power-On Self Test). In BIOS Setup, go to Integrated Periperals -->...
  • Page 63 To boot from Windows installation CD-ROM, set First Boot Device under the Advanced BIOS Features menu to CDROM (Figure 3). CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Advanced BIOS Features AMD K8 Cool&Quiet control [Auto] Item Help Hard Disk Boot Priority...
  • Page 64 (3) Configuring RAID set in RAID BIOS Enter the RAID BIOS setup utility to configure a RAID array. Skip this step if you do not want to create RAID. Step 1: After the POST memory test begins and before the operating system boot begins, look for a message which says "Press F10 to enter RAID setup utility"...
  • Page 65 Step 5: Next, select the hard drives which you wish to be included in the disk array. The Free Disks section displays the information about the currently installed SATA hard drives. Press the TAB key to move to the Free Disks section. Select the target hard drives using the UP or DOWN ARROW key and use the RIGHT ARROW key to add the hard drives to the Array Disks section (Figure 6).
  • Page 66 After that, the Array List screen displaying the RAID array you created will appear (Figure 8). (Note: BBS stands for BIOS Boot Specification. This indicates that the boot device is defined in the BIOS.) MediaShield Utility May 22 2006 - Array List - Boot Status Vendor...
  • Page 67 (4) Making a SATA Driver Disk To install operating system onto RAID disks successfully, you need to install the SATA RAID driver during OS installation. Without the driver, the hard disk may not be recognized during the Windows setup process. Skip this step if you do not want to create RAID. First of all, copy the driver for the SATA controller from the motherboard driver CD-ROM to a floppy disk.
  • Page 68 (5) Installing SATA controller driver during OS installation Now that you have prepared the SATA driver disk and configured BIOS settings, you are ready to install Windows 2000/XP onto your SATA hard drive with the SATA driver. The following is an example of Windows XP installation.
  • Page 69 Step 3: If Setup correctly recognizes the driver in the floppy disk, a controller menu similar to Figure 15 below will appear. Use the ARROW keys to select NVIDIA RAID CLASS DRIVER (Figure 15) and press ENTER. Later, when a screen similar to Figure 16 appears, you must press S to select additional driver.
  • Page 70 Step 4: When the next screen (Figure 17) appears, press ENTER to continue the SATA driver installation from the floppy disk. Windows Setup Setup will load support for the following mass storage device(s): NVIDIA RAID CLASS DRIVER (required) NVIDIA nForce Storage Controller (required) * To specify additional SCSI adapters, CD-ROM drives, or special disk controllers for use with Windows, including those for which you have a device support disk from a mass storage device...

  • Page 71: 4- / 6- / 8- Channel Audio Function Introduction

    4-1-5 2- / 4- / 6- / 8- Channel Audio Function Introduction The default speaker settings for the 6 audio jacks are as shown in the picture to the right. The jack Center/Subwoofer retasking capability supported by HD Audio allows Line In Speaker Out users to change the function for each audio jack by...
  • Page 72 STEP 2: In the Audio Control Panel, click the Audio I/O tab. In the upper left list, click 2CH Speaker. STEP 3: After a speaker or headphone is plugged into the rear Line Out jack, a small window will pop up and ask you what type of equipment is connected.
  • Page 73 STEP 3: After plugging in 4-channel speakers to the rear speaker jacks, a small window will pop up and ask you what type of equipment is connected. Choose a device depending on the type of speaker connected (4-channel audio consists of Front Speaker Out (Line Out) and Rear Speaker Out) and then click OK.
  • Page 74 8 Channel Audio Setup STEP 1 : After installation of the audio driver, you should find an Audio Manager icon in your system tray (you can also find the icon in Control Panel). Double- click the icon to open the Audio Control Panel. STEP 2: In the Audio Control Panel, click the Audio I/O tab.
  • Page 75 Sound Effect Configuration: At the Sound Effect menu, users can adjust sound option settings as desired. AC'97 Audio Configuration: To enable the front panel audio connector to sup- port AC97 Audio mode, go to the Audio Control Panel and click the Audio I/O tab. In the ANA- LOG area, click the Tool icon and then select the Disable front panel jack detection check box.

  • Page 76: Troubleshooting

    Troubleshooting Below is a collection of general asked questions. To check general asked questions based on a specific motherboard model, please log on to GIGABYTE's website. Question 1: I cannot see some options that were included in previous BIOS after updating BIOS. Why? Answer: Some advanced options are hidden in new BIOS version.
  • Page 77 - 77 - Appendix...
